A3309AASWW - Refrigerator Americana - Free user manual and instructions

Product Type	Refrigerator
Brand	Americana
Model	A3309AASWW
Dimensions (H x W x D)	Approx. 66 x 28 x 30 inches
Weight	Approx. 180 lbs
Power Supply	115 V, 60 Hz, 15 A
Energy Consumption	Approx. 350 kWh/year
Defrost Type	Auto defrost
Temperature Control	Adjustable thermostat (range: 34°F to 46°F)
Storage Capacity	Approx. 18 cu. ft.
Shelves	4 adjustable glass shelves
Door Storage	Two adjustable bins and gallon door storage
Crisper Drawers	Two humidity-controlled crisper drawers
Ice Maker	Optional ice maker capable
Lighting	Interior LED light
Door Finish	White textured steel
Door Reversibility	Reversible door hinge
Leveling Legs	Two adjustable front leveling legs
Climate Class	SN, N, ST (suitable for ambient temperatures 50°F to 100°F)
Energy Star Certified	Yes (typical)
Safety Features	Child lock, anti-tip bracket (optional)
Maintenance	Clean interior with mild soap; replace water filter every 6 months if equipped
Parts Availability	Common replacement parts available online
Repairability	Modular design for easy servicing

Frequently Asked Questions - A3309AASWW Americana

What is the recommended temperature setting for the refrigerator?

The recommended temperature for fresh food is 37-40°F (3-4°C). Freezer should be at 0°F (-18°C).

How do I adjust the door hinge to reverse the door opening?

Refer to the manual: remove hinge covers, unscrew hinges, swap door brackets, and reassemble. Mind the wiring for the ice maker.

Why is my refrigerator making unusual noises?

Normal noises include gurgling from refrigerant, clicking from compressor, and fan sounds. Ensure the fridge is level and not touching walls.

How often should I clean the condenser coils?

Every 6 to 12 months. Use a vacuum or coil brush to remove dust. Dirty coils reduce efficiency.

Can I install an ice maker in this model?

Yes, the A3309AASWW is ice maker ready. You need to purchase an installation kit and connect to a water line.

What should I do if the refrigerator is not cooling?

Check power supply, temperature setting, and door seal. Also ensure condenser coils are clean and air vents inside are not blocked.

How do I replace the interior light bulb?

Unplug the fridge, remove the light cover (usually snaps off), replace with LED bulb of same type (check manual for part number). Reassemble.

Is there a water filter and how do I change it?

If equipped, the water filter is located at the top of the fridge compartment or grille. Replace every 6 months or when indicator lights up. Twist to remove and install.

What is the warranty period for this refrigerator?

Typical warranty is 1 year for parts and labor, and 5 years for sealed system (compressor, condenser). Check your purchase papers.

How can I save energy with my refrigerator?

Keep it away from heat sources, set temperature to recommended levels, avoid overfilling, and ensure door seals are airtight. Clean coils regularly.

USER MANUAL A3309AASWW Americana

Connecting Electricity ..... 3

Extension Cords 2

Safety Precautions....2

Operating Instructions

Care and Cleaning ..... 7, 8

Shelves 5,6

Storage Drawer ....6

Temperature Controls .....4

Write the model and serial numbers here:

Model # ____

Serial # ____

You can find them on a label on the lower left side of the fresh food compartment.

Installation Instructions

Preparing to Install the Refrigerator ....9 Reversing the Door Swing ... 10–13

Troubleshooting Tips

Before You Call For Service .....15, 16 Normal Operating Sounds .....14

Consumer Support

Consumer Support 20

Product Registration ..... 17, 18

Warranty 19

Owner's Manual and Installation Instructions

www.AmericanaAppliances.com

Model Americana A3309

IMPORTANT SAFETY INFORMATION. READ ALL INSTRUCTIONS BEFORE USING.

⚠ WARNING!

Use this appliance only for its intended purpose as described in this Owner's Manual.

SAFETY PRECAUTIONS

When using electrical appliances, basic safety precautions should be followed, including the following:

This refrigerator must be properly installed and located in accordance with the Installation Instructions before it is used.

Do not allow children to climb, stand or hang on the shelves in the refrigerator. They could damage the refrigerator and seriously injure themselves.

Do not touch the cold surfaces in the freezer compartment when hands are damp or wet. Skin may stick to these extremely cold surfaces.

Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.

- Keep fingers out of the "pinch point" areas; clearances between the doors and between the doors and cabinet are necessarily small. Be careful closing doors when children are in the area.

In refrigerators with automatic icemakers, avoid contact with the moving parts of the ejector mechanism, or with the heating element that releases the cubes. Do not place fingers or hands on the automatic icemaking mechanism while the refrigerator is plugged in.

■ Unplug the refrigerator before cleaning and making repairs.

NOTE: We strongly recommend that any servicing be performed by a qualified individual.

■ Turning the control to the 0 position does not remove power to the light circuit.

Do not refreeze frozen foods which have thawed completely.

▲ DANGER! RISK OF CHILD ENTRAPMENT

PROPER DISPOSAL OF THE REFRIGERATOR

Child entrapment and suffocation are not problems of the past. Junked or abandoned refrigerators are still dangerous...even if they will sit for "just a few days." If you are getting rid of your old refrigerator, please follow the instructions below to help prevent accidents.

Before You Throw Away Your Old Refrigerator or Freezer:

Take off the doors.

Leave the shelves in place so that children may not easily climb inside.

Refrigerants

All refrigeration products contain refrigerants, which under federal law must be removed prior to product disposal. If you are getting rid of an old refrigeration product, check with the company handling the disposal about what to do.

USE OF EXTENSION CORDS

Because of potential safety hazards under certain conditions, we strongly recommend against the use of an extension cord.

However, if you must use an extension cord, it is absolutely necessary that it be a UL-listed, 3-wire grounding type appliance extension cord having a grounding type plug and outlet and that the electrical rating of the cord be 15 amperes (minimum) and 120 volts.

⚠ WARNING!

HOW TO CONNECT ELECTRICITY

Do not, under any circumstances, cut or remove the third (ground) prong from the power cord. For personal safety, this appliance must be properly grounded.

The power cord of this appliance is equipped with a 3-prong (grounding) plug which mates with a standard 3-prong (grounding) wall outlet to minimize the possibility of electric shock hazard from this appliance.

Have the wall outlet and circuit checked by a qualified electrician to make sure the outlet is properly grounded.

Where a standard 2-prong wall outlet is encountered, it is your personal responsibility and obligation to have it replaced with a properly grounded 3-prong wall outlet.

The refrigerator should always be plugged into its own individual electrical outlet which has a voltage rating that matches the rating plate.

This provides the best performance and also prevents overloading house wiring circuits which could cause a fire hazard from overheated wires.

Never unplug your refrigerator by pulling on the power cord. Always grip plug firmly and pull straight out from the outlet.

Repair or replace immediately all power cords that have become frayed or otherwise damaged. Do not use a cord that shows cracks or abrasion damage along its length or at either end.

When moving the refrigerator away from the wall, be careful not to roll over or damage the power cord.

READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.

SAVE THESE INSTRUCTIONS

About the temperature control dial.

Turning the dial to 0 stops cooling in both compartments—fresh food and freezer. It does not shut off power to the refrigerator.

Control Settings

Temperature Control Dial

The temperature control dial has nine settings plus 0.1 is the warmest. 9 is the coldest. At first, set the dial at 5.

After using the refrigerator, adjust the dial if necessary.

Insert a coin into the slot in the middle of the dial and you can turn the dial to the setting that's best suited to your needs.

Allow 24 hours for the refrigerator to get cold.

Shelf supports at various levels allow you to custom-space your shelves. Not all features are on all models.

Full-Width Shelves

The wire sliding shelves can be moved to another place in the fresh food compartment.

The full-width shelf has rear stop-locks. When placed correctly on the shelf supports, the shelf will not tilt when you place food on it or remove food from it.

To remove the full-width shelves, fully open the fresh food door, lift the rear of the shelf and pull forward.

About the freezer compartment shelf.

Freezer Shelf

The freezer shelf is adjustable to either upper or lower position.

The full-width shelf has rear stop-locks. When placed correctly on the shelf supports, the shelf will not tilt when you place food on it or remove food from it.

To remove the full-width shelf, fully open the freezer door, lift the rear of the shelf and pull forward.

About the storage drawer.

Not all features are on all models.

Fruit and Vegetable Drawer

Excess water that may accumulate in the bottom of the drawer should be emptied and the drawer wiped dry.

About storage drawer and cover removal.

Not all features are on all models.

Drawer and Cover Removal

Drawer can be removed easily by grasping the sides and lifting up slightly while pulling.

Full-Width Drawer with Cover

To remove the cover, pull it straight out of the side supports.

To replace the cover, align it with the side supports and carefully slide it toward the back of the compartment.

Cleaning the Outside

The door handles and trim (on some models). Clean with a cloth dampened with soapy water. Dry with a soft cloth.

Keep the outside clean. Wipe with a clean cloth lightly dampened with kitchen appliance wax or mild liquid dish detergent. Dry and polish with a clean, soft cloth.

The stainless steel panels and door handles

(on some models) can be cleaned with a commercially available stainless steel cleaner. Do not use appliance wax or polish on the stainless steel.

Do not wipe the refrigerator with a soiled dish cloth or wet towel. These may leave a residue that can erode the paint. Do not use scouring pads, powdered cleaners, bleach or cleaners containing bleach because these products can scratch and weaken the paint finish.

Cleaning the Inside

To help prevent odors, leave an open box of baking soda in the fresh food and freezer compartments.

Unplug the refrigerator before cleaning.

If this is not practical, wring excess moisture out of sponge or cloth when cleaning around switches, lights or controls.

Use warm water and baking soda solution—about a tablespoon (15 ml) of baking soda to a quart (1 liter) of water. This both cleans and neutralizes odors. Rinse and wipe dry.

After cleaning the door gaskets, apply a thin layer of petroleum jelly to the door gaskets at the hinge side. This helps keep the gaskets from sticking and bending out of shape.

Avoid cleaning cold glass shelves (on some models) with hot water because the extreme temperature difference may cause them to break. Handle glass shelves carefully. Bumping tempered glass can cause it to shatter.

Do not wash any plastic refrigerator parts in the dishwasher.

Care and cleaning of the refrigerator.

Behind the Refrigerator

Be careful when moving the refrigerator away from the wall. All types of floor coverings can be damaged, particularly cushioned coverings and those with embossed surfaces.

Turn the leveling legs at each front corner of the refrigerator counterclockwise until the rollers support the refrigerator. Pull the refrigerator straight out and return it to position by pushing it straight in. Moving the refrigerator in a side direction may result in damage to the floor covering or refrigerator.

When pushing the refrigerator back, make sure you don't roll over the power cord.

After rolling the refrigerator back into place, turn the front leveling legs clockwise until the legs again bear the weight of the refrigerator.

Light Bulb Replacement

To replace a burned-out bulb, unplug the refrigerator from its electrical outlet, unscrew the bulb when cool and replace it with an appliance bulb of the same or lower wattage.

Turning the control to the 0 position does not remove power to the light circuit.

Preparing for Vacation

For long vacations or absences, remove food and unplug the refrigerator. Move the temperature control dial to the 0 position, and clean the interior with a baking soda solution of one tablespoon (15 ml) of baking soda to one quart (1 liter) of water. Leave the doors open.

Preparing to Move

Secure all loose items such as grille, shelves and drawer by taping them securely in place to prevent damage.

Be sure the refrigerator stays in an upright position during moving.

Installation Instructions

Refrigerator

Model 8.8

If you have questions, call 1.800.432.2737

BEFORE YOU BEGIN

Read these instructions completely and carefully.

• IMPORTANT – Save these instructions for local inspector's use.
• IMPORTANT – Observe all governing codes and ordinances.
• Note to Installer – Be sure to leave these instructions with the Consumer.
• Note to Consumer – Keep these instructions for future reference.
• Skill level – Installation of this appliance requires basic mechanical skills.
• Completion time – Refrigerator Installation 15 minutes

Reversing the Door Swing 1 hour

• Proper installation is the responsibility of the installer.
• Product failure due to improper installation is not covered under the Warranty.

REFRIGERATOR LOCATION

• Do not install the refrigerator where the temperature will go below 60°F (16°C) because it will not run often enough to maintain proper temperatures.
  • Install it on a floor strong enough to support it fully loaded.

CLEARANCES

Allow the following clearances for ease of installation, proper air circulation and plumbing and electrical connections.

• Sides 3 / 4'' (19 mm)
• Top 1'' (25 mm)
• Back 1" (25 mm)

Leveling legs near each front corner of the refrigerator are adjustable. They firmly position the refrigerator and prevent it from moving when the doors are opened. Leveling legs should be set so the front of the refrigerator is raised just enough that the doors close easily when opened about halfway.

Turn the leveling legs clockwise to raise the refrigerator, counterclockwise to lower it.

Rollers next to the leveling legs allow you to move the refrigerator away from the wall for cleaning.

Turn the legs counterclockwise until the weight of the refrigerator is transferred from them to the rollers. After rolling the refrigerator back into place, turn the legs clockwise until the legs again bear the weight of the refrigerator.

1 REVERSING THE DOOR SWING

IMPORTANT NOTES

When reversing the door swing:

• Read the instructions all the way through before starting.
• Handle parts carefully to avoid scratching paint.
• Set screws down by their related parts to avoid using them in the wrong places.
• Provide a non-scratching work surface for the doors.

IMPORTANT: Once you begin, do not move the cabinet until door-swing reversal is completed.

These instructions are for changing the hinges from the right side to the left side—if you ever want to change the hinges back to the right side, follow these same instructions and reverse all references to left and right.

1.2 Empty all door shelves, including the dairy compartment.

CAUTION: Do not let either door drop to the floor. To do so could damage the door stop.

TOOLS REQUIRED

Phillips screwdriver

Masking tape

5/16"hex-head socket driver

T20 or T25 Torxdriver, (needed for some models)

Putty knife or thin-blade screwdriver

5/16"open-end wrench

1 BEFORE YOU START

1.1 Unplug the refrigerator from its electrical outlet.

2 REMOVE THE FREEZER DOOR

2.1 Tape the door shut with masking tape.

2.2 Remove the hinge cap from the top hinge with a putty knife or a thin-blade screwdriver. With a 5/16"hex-head socket driver, remove the screws that hold the top hinge to the cabinet.

② REMOVE THE FREEZER DOOR (CONT.)

2.3 Lift the hinge (and the shim glued to it) straight up to free the hinge pin from the socket in the top of the door and set it aside, along with its screws.

3.2 Using a 5/16" hex-head socket screwdriver and a 5/16" open-end wrench, remove the two screws holding the center hinge (and the shim glued to it) to the cabinet. Lift the center hinge to free its pin from the socket in the top of the door, and set hinge and screws aside. Be careful not to lose the center hinge spacer and washer.

2.4 Remove the tape and tilt the door away from the cabinet. Lift it off the center hinge pin.

3.3 Remove the tape and tilt the door away from the cabinet. Lift the door from the pin in the bottom hinge bracket. (If the washer sticks to the door bottom, put it back on the hinge.)

2.5 Set the door on a non-scratching surface with the outside up.

3.4 Set the door outside-up on a non-scratching surface.

2.6 Transfer the 2 screws from the opposite side of the cabinet to the screw holes vacated by the top hinge removal. Transfer the two plug buttons to the holes where the screws were removed.

3.5 Transfer the two screws from the opposite side of the cabinet to the screw holes vacated by the center hinge removal. Transfer the three plug buttons to the holes where the screws were removed.

③ REMOVE THE FRESH FOOD DOOR

3.1 Tape the door shut with masking tape.

1 REVERSING THE DOOR SWING (CONT.)

4 REVERSING THE HARDWARE

4.1 Remove the bottom hinge bracket and washer from the right side. Install the supplied left hinge on the left side. Transfer the three plug buttons to the holes where the screws were removed.

5.1.2 Insert the pin on the center hinge into the socket in the top of the door. Place the spacer, then the washer, on the hinge pin.

4.2 Transfer fresh food and freezer door stops

Remove the door stop from the right side of the doors. Install them on the left side of both doors.

5.1.3 Tilt the door toward the cabinet. As the door is brought into position, slide the hinge under the head of the screw which earlier had been partly driven into the outermost hole. Insert the remaining screw, then tighten both screws securely.

5 REHANGING THE DOORS

5.1 Rehang the fresh food door

5.1.1 Lower the fresh food door onto the bottom hinge pin. Be sure the washer is in place on the pin.

5 REHANGING THE DOORS (CONT.)

5.2 Rehang the freezer door

5.2.1 Lower the freezer door onto the center hinge pin. Be sure the washer and spacer are in place on the pin.

5.2.4 Make sure the door is slightly above the top of the cabinet and the gap between the doors is even across the front. Tighten the top hinge screws. Do not overtighten these screws—tighten them until they are just snug, then turn them another one-half turn.

5.2.2 Tilt the door toward the cabinet, lifting the top hinge so the pin fits into the socket on the top of the door.

5.2.5 Install the hinge cap onto the top hinge by snapping it into place.

5.2.3 Interchange hinge (and the shim glued to it) and screws at top right with screws at top left of cabinet. Do not tighten screws on hinge side at this time.

Installing the hinge on the left

Installing the hinge on the right

NOTES:

- Some hinges have four holes. Which holes you use for installing the hinge depends on which side you install the hinge.

- The outer edge of the hinge should be parallel to the edge of the case for correct installation.

Normal operating sounds.

Newer refrigerators sound different from older refrigerators. Modern refrigerators have more features and use newer technology.

Do you hear what I hear? These sounds are normal.

HUMMM... WHOOSH...

■ The new high efficiency compressor may run faster and longer than your old refrigerator and you may hear a high-pitched hum or pulsating sound while it is operating.
■ You may hear a whooshing sound when the doors close. This is due to pressure equalizing within the refrigerator.

WHIR!

■ You may hear the fans spinning at high speeds. This happens when the refrigerator is first plugged in, when the doors are opened frequently or when a large amount of food is added to the refrigerator or freezer compartments. The fans are helping to maintain the correct temperatures.

CLICKS, POPS, CRACKS and CHIRPS

■ You may hear cracking or popping sounds when the refrigerator is first plugged in. This happens as the refrigerator cools to the correct temperature.
■ The compressor may cause a clicking or chirping sound when attempting to restart (this could take up to 5 minutes).
■ Expansion and contraction of cooling coils during and after defrost can cause a cracking or popping sound.

WATER SOUNDS

■ The flow of refrigerant through the freezer cooling coils may make a gurgling noise like boiling water.
■ Water dropping on the defrost heater can cause a sizzling, popping or buzzing sound during the defrost cycle.
A water dripping noise may occur during the defrost cycle as ice melts from the evaporator and flows into the drain pan.
■ Closing the door may cause a gurgling sound due to pressure equalization.

Troubleshooting Tips

Save time and money! Review the charts on the following pages first and you may not need to call for service.

Problem Possible Causes What To Do
Refrigerator does not operate	Refrigerator in defrost cycle.	·Wait about 30 minutes for defrost cycle to end.
	Temperature control dial in 0 position. setting.	·Move the temperature control dial to a temperature
	Refrigerator is unplugged.	·Push the plug completely into the outlet.
	The fuse is blown/circuit breaker is tripped.	·Replace fuse or reset the breaker.
Vibration or rattling (slight vibration is normal)	Roller screws or leveling legs need adjusting.	·See Rollers and Leveling Legs.
Motor operates for long periods or cycles on and off frequently. (Modern refrigerators with more storage space and a larger freezer require more operating time. They start and stop often to maintain even temperatures.)	Normal when refrigerator is first plugged in.	·Wait 24 hours for the refrigerator to completely cool down.
	Often occurs when large amounts of food are placed in refrigerator.	·This is normal.
	Door left open.	·Check to see if package is holding door open.
	Hot weather or frequent door openings.	·This is normal.
	Temperature control dial set at the coldest setting.	·See About the temperature control dial.
	Grille and condenser need cleaning.	·See Care and cleaning.
Fresh food or freezer compartment too warm	Temperature control dial not set cold enough.	·See About the temperature control dial.
	Warm weather or frequent door openings.	·Set the temperature control dial one step colder. See About the temperature control dial.
	Door left open.	·Check to see if package is holding door open.
	Package blocking air duct in freezer compartment.	·Check to see if package is blocking air duct in freezer compartment.
Frost or ice crystals on frozen food (frost within package is normal)	Door left open.	·Check to see if package is holding door open.
	Too frequent or too long door openings.

Before you call for service...

Troubleshooting Tips

Problem Possible Causes What To Do
Moisture forms on cabinet surface periods of high humidity. one setting colder. between the doors	Not unusual during	• Wipe surface dry and reset temperature control dial
Moisture collects inside Too frequent or too (in humid weather, air long door openings. carries moisture into refrigerator when doors are opened)
Refrigerator has odor	Foods transmitting odor to refrigerator.	• Foods with strong odors should be tightly wrapped.• Keep an open box of baking soda in the refrigerator; replace every three months.
	Interior needs cleaning.	• See Care and cleaning.

GE Service Protection Plus™

GE, a name recognized worldwide for quality and dependability, offers you Service Protection Plus™—comprehensive protection on all your appliances—No Matter What Brand!

Benefits Include:

• Backed by GE
• All brands covered
  • Unlimited service calls
• All parts and labor costs included
  • No out-of-pocket expenses
  • No hidden deductibles
  • One 800 number to call

We'll Cover Any Appliance. Anywhere. Anytime.*

You will be completely satisfied with our service protection or you may request your money back on the remaining value of your contract. No questions asked. It's that simple.

Protect your refrigerator, dishwasher, washer and dryer, range, TV, VCR and much more—any brand! Plus there's no extra charge for emergency service and low monthly financing is available. Even icemaker coverage and food spoilage protection is offered. You can rest easy, knowing that all your valuable household products are protected against expensive repairs.

Place your confidence in GE and call us in the U.S. toll-free at 800.626.2224 for more information.

*All brands covered, up to 20 years old, in the continental U.S.

Cut here

Please place in envelope and mail to:

General Electric Company

Warranty Registration Department

P.O. Box 34980

Louisville, KY 40232-4980

Consumer Product Ownership Registration

Dear Customer:

Thank you for purchasing our product. Registration for Americana™ is provided by GE.

Thank you for placing your confidence in us. We are proud to have you as a customer!

Follow these three steps to protect your new appliance investment:

Complete and mail

your Consumer

Product Ownership

Registration today.

Have the peace of

mind of knowing we

can contact you in

the unlikely event of a

safety modification.

After mailing the

registration below,

store this document

in a safe place. It

contains information

you will need should

you require service.

Our service number in

the USA is: 800 GE

CARES (800.432.2737).

Read your Owner's

Manual carefully.

It will help you

operate your new

appliance properly.

Model Number Serial Number

Important: If you did not get a registration card with your product, detach and return the form below to ensure that your product is registered.

Consumer Product Ownership Registration

Model Number Serial Number

GE Consumer & Industrial

Appliances

General Electric Company

Louisville, KY 40225

ge.com

* Please provide your e-mail address to receive, via e-mail, discounts, special offers and other important communications from GE Appliances (GFA).

□ Check here if you do not want to receive communications from GEA's carefully selected partners.

FAILURE TO COMPLETE AND RETURN THIS CARD DOES NOT DIMINISH YOUR

WARRANTY RIGHTS.

For information about GEA's privacy and data usage policy, go to ge.com and click on "Privacy Policy" or call 800.626.2224.

Americana

www.AmericanaAppliances.com

Refrigerator Warranty.

All warranty services for Americana ^™ are provided by GE Factory Service Centers, or an authorized Customer Care ^® technician. To schedule service, call 800.432.2737.

Staple your receipt here. Proof of the original purchase date is needed to obtain service under the warranty.

For The Period Of: We Will Replace:

Six Months

From the date of the

Any part of the refrigerator which fails due to a defect in materials or workmanship.

During this limited six-month warranty, GE will also provide, free of charge, all labor

original purchase and related service to replace the defective part.

What Is Not Covered:

■ Service trips to your home to teach you how to use the product.

Improper installation, delivery or maintenance.

Failure of the product if it is abused, misused, or used for other than the intended purpose or used commercially.

Loss of food due to spoilage.

Damage caused after delivery.

Products which are not defective, broken, or which are working as described in the Owner's Manual.

■ Replacement of house fuses or resetting of circuit breakers.

■ Replacement of light bulbs.

Damage to the product caused by accident, fire, floods or acts of God.

■Incidental or consequential damage caused by possible defects with this appliance.

EXCLUSION OF IMPLIED WARRANTIES—Your sole and exclusive remedy is product repair as provided in this Limited Warranty. Any implied warranties, including the implied warranties of merchantability or fitness for a particular purpose, are limited to one year or the shortest period allowed by law.

This warranty is extended to the original purchaser and any succeeding owner for products purchased for home use within the USA. In Alaska, the warranty excludes the cost of shipping or service calls to your home.

Some states do not allow the exclusion or limitation of incidental or consequential damages. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. To know what your legal rights are, consult your local or state consumer affairs office or your state's Attorney General.

Warrantor: General Electric Company. Louisville, KY 40225

Schedule Service

Expert GE repair service is only one step away from your door. Schedule service at your convenience by calling 800.432.2737 during normal business hours.

In Canada, call 1.800.361.3400

Extended Warranties

Purchase a GE extended warranty and learn about special discounts that are available while your warranty is still in effect. You can purchase it by calling 800.626.2224 during normal business hours. GE Consumer Home Services will still be there after your warranty expires. In Canada, call 1.888.261.2133

Parts and Accessories

Individuals qualified to service their own appliances can have parts or accessories sent directly to their homes (VISA, MasterCard and Discover cards are accepted). Order by phone at 800.626.2002 during normal business hours.

Instructions contained in this manual cover procedures to be performed by any user. Other servicing generally should be referred to qualified service personnel. Caution must be exercised, since improper servicing may cause unsafe operation.

Customers in Canada should consult the yellow pages for the nearest Camco service center, or call 1.888.261.3055.

Contact Us www.AmericanaAppliances.com

If you are not satisfied with the service you receive from GE, send a letter to GE. Please include your phone number. Write to: General Manager, Customer Relations

GE Appliances, Appliance Park

Louisville, KY 40225

In Canada: Write to: Director, Consumer Relations, Camco, Inc.

Suite 310, 1 Factory Lane

Moncton, N.B. E1C 9M3

Congelador superior

Refrigeradores

Estantes completos

1 CÓMO INVERTIR EL VAIVÉN DE LA PUERTA

NOTAS IMPORTANTES

2 RETIRE LA PUERTA DEL CONGELADOR (CONT.)

3 RETIRE LA PUERTA DE ALIMENTOS FRESCOS

5 CÓMO VOLVER A COLGAR LAS PUERTAS

Garantidor: General Electric Company. Louisville, KY 40225

Escribanos a: General Manager, Customer Relations GE Appliances, Appliance Park Louisville, KY 40225
