Product Type	Subwoofer
Brand	SPL
Model	APW-12
Driver Size	12 inches
Impedance	8 ohms
Power Handling (RMS)	400 W
Power Handling (Peak)	800 W
Frequency Response	30 Hz - 200 Hz
Sensitivity	96 dB
Dimensions (W x H x D)	16.5 x 18.5 x 17.7 inches (42 x 47 x 45 cm)
Weight	40.7 lbs (18.5 kg)
Enclosure Type	Bass reflex (ported)
Input Connectors	Speakon NL4
Grille	Powder-coated steel
Recommended Amplifier Power	400 - 800 W @ 8 ohms
Usage	Professional audio, PA systems
Cleaning Instructions	Wipe with a dry cloth; avoid moisture
Safety Warnings	Keep away from water; do not overload
Spare Parts Availability	Contact SPL support for replacement drivers
Repairability	Designed for easy driver and grille replacement

Frequently Asked Questions - APW-12 SPL

What is the power handling of the SPL APW-12 subwoofer?

The SPL APW-12 has a power handling of 400 W RMS and 800 W peak.

What is the impedance of the APW-12?

The impedance is 8 ohms, suitable for most professional amplifiers.

What type of enclosure does the APW-12 use?

It features a bass reflex (ported) enclosure for enhanced low-frequency output.

Can the APW-12 be used outdoors?

It is designed for indoor use but can be used outdoors if protected from direct moisture. Always cover when not in use.

How to clean the SPL APW-12 subwoofer?

Use a dry, soft cloth to wipe the cabinet. Do not use water or cleaning solvents. The grille can be vacuumed gently.

What amplifier should I use with the APW-12?

Use an amplifier delivering 400-800 W at 8 ohms per channel for optimal performance.

What is the frequency response of the APW-12?

The frequency response is 30 Hz to 200 Hz, ideal for deep bass reproduction.

How to connect the APW-12 to an amplifier?

Use a Speakon NL4 cable. Connect the amplifier's output to the input of the subwoofer. Ensure proper polarity.

Is the APW-12 compatible with 70V line systems?

No, it is a low-impedance (8 ohms) subwoofer and not designed for 70V systems without a transformer.

What to do if the subwoofer stops producing sound?

Check the amplifier and cables. Ensure the speaker is not overloaded. If the driver is damaged, contact SPL for a replacement.

USER MANUAL APW-12 SPL

Thank you for choosing SPL woofers. Designed and engineered in the USA, this product combines innovative technology with the finest materials to consistently deliver Absolutely State of the Art performance, sound quality, reliability, and value. This SPL product reflects our commitment to offer you unparalleled performance and quality for years of dependable service and listening enjoyment.

Features, Parameters, & Dimensions

Polypropylene Cone High-Roll Rubber Surround 2.0" 4-layer VC on Aluminum Former Nickel Plated 8ga. Compression Terminals

Vented T-Yoke Back-plate Polpropylene Molded Dust Cap Textured Basket with Voice Coil Cooling Poly-Cotton Suspension Spider

APW-10

APW-12

IMPEDANCE 4OHM 4OHM
RE 3.9382 3.95OHMS
Fs 27.96 29.3065
QES 0.5208 0.5643
QMS 5.7312 5.2366
QTS 0.4774 0.5094
LE 2.6122 2.8161MH
DIAMETER 10INCH	12INCH
SD	78.5398 IN^2	113.0973 IN^2
VAS	100.5855 L	285.7628 L
BL 12.49 10.03
MMS	117.4198 G	78.0570 G
CMS	275.7757 uM/N	377.8344 uM/N
SEN	88.06 92.8DB
RMS/MAX	240/600	360/900
MOUNTING DEPTH	4 7/8 INCH	5.75INCH
CUTOUT DIAM	9.6INCH	11.6INCH

Enclosure Dimensions

Included in this manual are a number of different enclosure suggestions. These are by no means the only enclosures to use, but they provide a starting point to determine the correct enclosure for your needs many factors must be addressed (amount of power, vehicle, placement, crossovers, etc) Therefore, as always, SPL recommends that your subwoofer be installed by an authorized SPL dealer.

Enclosure Construction

All enclosures should be made of .75" (3/4") material only. When possible, make the baffle 1.5" (1 12 ) thick and add .75" (3/4") to the depth of the enclosure to compensate. All volumes INCLUDE vent/port and subwoofer displacements. DO NOT change the volume unless you plan on adding a substantial amount of bracing. For added performance, applying a coat of fiberglass resin to the interior walls will greatly improve sealing the enclosure. Adding a thin layer of poly-fill will improve response by smoothing out reflections within the enclosure.

Enclosure Recommendations

	APW-10 APW-12
Sealed
Min .75 cu ft.	1.0 cu ft.
Recommended	1.0 cu ft. 1.25	cu ft.
Ported
Min 1 cu ft. 1.5	cu ft.
Port Length Dx	3"x4.5" 5"x4.5"
F3 Hz 48 65
Recommended	1.5 cu ft.	1.75 cu ft.
Port Length Dx	4"x8.5"	5"x4"
F3 Hz 40 60
