Product Type	Remote Control Off-Road Buggy
Brand	NINCO
Model	Tremor NH93074
Scale	1:16
Length	30 cm (approx.)
Width	20 cm (approx.)
Height	15 cm (approx.)
Weight	0.8 kg (approx.)
Vehicle Power Source	Rechargeable Ni-MH battery pack (7.2V, 700mAh)
Transmitter Power Source	4 x AA batteries (not included)
Frequency	2.4 GHz
Range	Up to 50 meters
Drive System	4-wheel drive (4WD)
Suspension	Independent front and rear
Speed	Up to 20 km/h
Functions	Forward, reverse, left, right, turbo boost (varies with controller)
Cleaning Instructions	Wipe with a dry cloth; avoid water and solvents
Safety Warnings	Not for children under 3 years; small parts; CHOKING HAZARD; use under adult supervision
Spare Parts Availability	Spare parts available from NINCO authorized dealers; refer to manual for part numbers
Repairability	Modular design; most components replaceable; professional repair recommended for electronics
Certifications	CE, FCC compliant
Manual Languages	English (PDF download available online)

Frequently Asked Questions - Tremor NH93074 NINCO

What batteries does the NINCO Tremor NH93074 require?

The vehicle uses a rechargeable 7.2V Ni-MH battery pack (700mAh). The transmitter requires 4 x AA batteries (not included).

How do I charge the vehicle battery?

Use the included charger. Plug the charger into a wall outlet and connect the battery. Charging time is approximately 4-5 hours. Do not overcharge.

What is the operating range of the remote control?

The 2.4GHz transmitter has a maximum range of up to 50 meters in open area. Obstacles may reduce range.

My Tremor won't move. What should I check?

First, ensure the battery is charged and connected. Check that the transmitter has fresh batteries. Confirm the power switch on the vehicle is ON. If still not working, try re-binding the transmitter (refer to manual).

Can I use different frequency radios?

This model uses a fixed 2.4GHz frequency, which avoids interference. It cannot be changed.

Is the NINCO Tremor waterproof?

No, it is not waterproof. Avoid running in water, mud, or snow to prevent damage to electronics.

How do I clean the Tremor after use?

Use a dry or slightly damp cloth to wipe the body. For dirt on wheels and chassis, use a soft brush. Avoid solvents and submerging in water.

What spare parts are available?

Common spare parts include wheels, tires, suspension arms, gears, and battery packs. Contact NINCO or visit their website for part numbers and availability.

My car runs slowly or stops. Why?

Check the battery charge level. A low battery will reduce speed. Also, check for debris in the drivetrain or binding in the wheels. If the motor is hot, allow it to cool down.

Can I modify the Tremor for more speed?

You can upgrade the battery to a higher capacity or change the motor, but this may affect reliability. Always follow safety guidelines and use compatible parts.

USER MANUAL Tremor NH93074 NINCO

Two black and red NINCO TTMM-TREMOR electric motors with visible tires, parked side by side (no text or symbols on the vehicles themselves)

1/16 4WD RC ELECTRIC CARS

TREMOR

MANUAL DEL USUARIO

USER HANDBOOK

MANUAL DO USUARIO

HANDBUCH

MANUEL DE L'UTILISATEUR

MANUALE D'USO

CONTENIDO - CONTENT - CONTEÚDO - INHALT - CONTENU - CONTENUTO

Black handheld electronic device with a rotary dial and antenna, mounted on a base (no visible text or symbols)

Two toy vehicles: a black T-1800-TREMOR electric vehicle and a black 7.2V battery (no visible text or symbols on the vehicle body)

Electric power adapter with black body, black cable, and red terminal tag (no visible text or symbols)

The following items, not included in the kit, are required for assembling your model:

EMISORA - TRANSMITTER - EMISOR - SENDER - ÉMETTEUR - TRASMETTITORE

1. Botón asociación Binding Button Botão de ligação Verbindungstaste Bouton de liaison Pulsante vincolante

1. Indicador de potencia Power indicator Indicador de alimentação Betriebsanzeige Indicateur de puissance Indicatore di alimentazione
2. Interruptor de encendido ON-OFF switch Botão ON-OFF An/Aus Schalter Interrupteur ON-OFF Interruttore ON-OFF
3. Trim dirección Steering trim Direcção trim Steuerungs Feineinstellung Trim de direction Regolatore dello sterzo
4. Trim acelerador Throttle trim Acelerador trim Gas Feineinstellung Trim d'accélération Regolatore acceleratore
5. Gatillo - Trigger Gatilho - Drücker Gâchette - Grilletto
6. Gatillo - Trigger Gatilho - Drücker Gâchette - Grilletto
   LED encendido ON-OFF indicator Indicador ON-OFF Status LED Indicateur ON-OFF Indicatore ON-OFF
7. Control dirección Control wheel Control direcção Steuerungsrad Molette de contrôle Manopola di controllo

Cómo conducir - How to drive - Como conduzir - Fahranleitung - Comment conduire - Come guidare

1. NEUTRAL (coche parado) NEUTRAL (car stopped) NEUTRAL (carro parado) NEUTRAL (Auto anhielt) NEUTRAL (voiture arrêtée) NEUTRAL (auto fermo)

2. Adelante Forward Avançar Vorwärts Avancer Avanti


1. Desaceleración Decelerate Desaceleração Gas wegnehmen Décélérer Rallentare
2. Freno Brake Freio Bremse Frein Freno

1. Dejar de nuevo en NEUTRAL (activa el variador) Release the trigger to NEUTRAL Deixar de novo em NEUTRAL (activa o variador) Loslassen des Abzugs NEUTRAL Position Relâchez la gâchette pour retour au NEUTRAL Rilascere il grilleto e ritornare alla posizione NEUTRAL

2. Marcha atrás Forward Avançar Vorwärts Avancer Avanti


Close-up of a mechanical component with numbered parts (7, 8) and no visible text or symbols

1. Izquierda 8. Derecha Left Right Esquerda Direita Links Rechts Gauche Droite Sinistra Destra

SINCRONIZACIÓN (COCHE - EMISORA) / BINDING PROCESS (CAR - TRANSMITTER)

SINCRONIZAÇÃO (CAR - TRANSMISSOR) / BINDEVORGANG (AUTO - SENDER)

SYNCHRONISATION (VOITURE - ÉMETTEUR) / SINCRONIZZAZIONE (AUTO - EMITTENTE)

1-Mantener pulsado el botón BIND Ⓐ al mismo tiempo que ponemos en marcha la emisora: ON Ⓑ
-Press and hold "BIND" buttonⒶ while we turn on the transmitter.(B)
-Pressione e segure o botão "BIND" A enquanto ligamos o transmissor. B
-Halten Sie die Taste "BIND" -Taste(A) während wir Sie den Sender an schalten.(B)
-Appuyez et maintenez le bouton "BIND"① alors que nous activons l'émetteur.⑧
-Tenere premuto il pulsante "BIND"① mentre si accende il trasmettitore.②

Close-up of a black plastic electrical connector with red and black wires, labeled C and D (no text or symbols on the component itself)

-Press and hold "BIND" button© while we turn on the car.⑭

-Turn on transmitter and car...binding process is already done!

-Charge the battery for 8-10 hours for the first time usage. Do not charge the battery unattended. Following charges 4-6 h.

-When the car is blocked, do not continue to pull/push the trigger, this will cause the ESC to overheat and damage the ESC

PT

• Length: 225mm
- Width: 190mm
• Height : 124mm
• R/C 2.4 Ghz
• Control range: <100m
- Playing time: 10 min
• Wheelbase: 155mm
• Gear ratio 1:10.3
• Weight: 568 gr
• Ground clearance: 25mm
- Wheel diameter: 65mm
- Wheel width: 38mm
- Motor: RC370

TRANSMITTER BATTERY REQUIEREMENTS:

Batteries included: 8 x 1,5V alkaline

CAR BATTERY REQUIREMENTS:

Battery needed: 1 x 7.4V 1100 mAh Ni-MH rechargeable (included).

SAFETY PRECAUTIONS:

Warning: Do not manipulate the car electronic equipment.

1. Do not touch any rotating part (gear, propeller...) when running to avoid any injuries or damage.
2. Switch off the car and the transmitter when not being in use.
3. Take off the batteries when not being in use.
4. It is recommended the use of alkaline batteries.
5. The vehicle must be always under supervision when operating.
6. Replace the batteries as soon any malfunctioning is detecting.
7. Save this manual for further references.
8. Please follow strictly this manual when operating.
9. The transmitter charger has been designed to operate with its own model batteries. Do not use it to charge other kind of batteries

BATTERY CAUTIONS

1. Not rechargeable batteries must not be chargeable.
2. Take off the batteries from the transmitter before charging.
3. Charging process must be done by an adult.
4. Do not mix different batteries or new and old batteries.
5. It is recommended the use of the same type of batteries.
6. Check the correct position and respect the polarity.
7. Take off the old batteries.

VEHICLE FEATURED WITH NI-MH BATTERY RECHARGEABLE.

PLEASE READ CAREFULLY THESE SECURITY GUIDELINES:

Please, read through the whole instruction manual and keep for further reference.

1. Do not dispose of the battery into fire or heat.
2. Do not use or leave the battery near a heat source, such as fire or a heater.
3. Do not strike the battery or throw it against a hard surface.
4. Do not immerse the battery into water. Keep the battery cool and dry.
5. When recharging the battery, use only the charger designed for that purpose.
6. Do not over-discharge the battery.
7. Do not connect the battery to an electrical outlet.
8. Do not directly solder the battery or pierce it with a nail or other sharp object.
9. Do not transport or store the battery together with metal objects such as necklaces, hairpins, etc.
10. Charge the battery every six months.
11. Turn off your equipment power switch after use.
12. Recycle used batteries after covering the battery terminals with insulation tape or inserting the battery into an individual polybag.

SPECIAL WARNING FOR ADULTS

1. Check regularly the product to avoid injuries. In case of damage, do not use again the toy until it will be totally repaired.
2. Toy not recommended for children under 14 years of age.
3. Always use the charger provided. Do not use this charger for other type of batteries.
4. It is recommended the substitution of batteries is done by an adult.
5. In certain environments (electrostatics) the vehicle could have a malfunctioning.

MAINTENANCE

1. Take off the batteries from the transmitter if the vehicle has not been used for a long period of time.
2. Clean the surface of the vehicle with a soft cloth.
3. Never leave the vehicle under a direct hot source.
4. Do not sink the vehicle under water.

Please read carefully the instructions before using the car.

Always use fresh batteries to avoid losing control of the model.

Check the neutral throttle trigger position.

Do not run on a public street.

This could cause serious accidents, personal injuries and/or property damages.

WARNING

Not recommended for children under 14 years of age.

Contains small parts likely to be swallowed or inhaled.

it is recommended to play under the guidance of an adult.

Use of this model is your responsibility.

NINCO4RC

MANUAL DE INSTRUÇÕES PORTUGUÊS

1

ESPECIFICAÇÕES:

This is a sophisticated hobby product and not a toy. Children under the age of 14 are forbidden. It must be operated with caution and common sense and requires some basic mechanical ability. Failure to operate this product in a safe and responsible manner could result in injury or damage to the product or other property. This product in not intended for use by children without direct adult supervision. The product manual contains instructions for safety, operation and maintenance. It is essential to read and follow all the instructions and warnings in the manual, prior to assembly, setup or use, in order to operate correctly and avoid damage or injury.

PORTUGUES

NINCO DESARROLLOS S.L. hereby declares that this radio control system is in accordance with the basic requirements of the corresponding European Directives. The original Declaration of Conformity can be obtained clicking the download area in the following web address: www.ninco.com

Español [Spanish]:

Hereby, NINCO DESARROLLOS S.L., declares that this Radio Control Equipment is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.

NINCO4RC is brand of NINCO DESARROLLOS S.L.

Cira, de l'Hospilalet 32

08940 Cornella Barcelona Spain

CIF B-60307725
