Product Type	Halogen Heater
Model	KHH3607
Brand	Kunft
Power Supply	220-240V ~ 50/60Hz
Power Consumption	400W / 800W / 1200W (3 settings)
Heating Elements	3 Halogen tubes (upper, middle, lower)
Oscillation	Yes, manual press of turn button
Safety Features	Tip-over switch, overheat protection
Assembly Required	Yes, attach base with butterfly nuts
Cleaning	Unplug, cool down, wipe with dry soft cloth
Warranty	2 years on manufacturing defects
User Serviceable Parts	None; contact qualified technician
Control Type	Mechanical switches (orange power switch, two tube switches, oscillation button)
Power Cord	Approx. 1.5 m (estimate)

Frequently Asked Questions - KHH3607 Kunft

How do I assemble the Kunft KHH3607 halogen heater?

Remove the butterfly nuts from the base. Pull the power cord through the base plate and place it in the cable channel. Position the base plate firmly and screw the butterfly nuts back on tightly.

How do I clean the KHH3607 heater?

Unplug the heater and allow it to cool completely. Use a dry soft cloth to wipe the exterior. Do not use water or wet cloth to avoid electric shock.

What should I do if the heater does not turn on?

Check that the power cord is plugged into a working outlet. Ensure the main power switch (orange) is set to ON. If it still doesn't work, contact Worten Customer Support for assistance. Do not attempt to repair yourself.

What safety features does the KHH3607 have?

It includes a tip-over safety switch that automatically turns off the heater if it falls over, and overheat protection. Always place on a stable, flat surface.

How do I adjust the heat settings?

The heater has three power settings: 400W (lower tube only), 800W (lower + middle/upper?), actually: The orange power switch enables upper and middle tubes. Then separate switches for lower tube and upper tube. You can combine them to achieve 400W, 800W, or 1200W. Refer to the manual for exact combination.

How do I use the oscillation function?

Press the 'TURN' button to start oscillation. The heater will rotate left and right to distribute heat. Press again to stop.

What is the warranty period for the Kunft KHH3607?

It comes with a 2-year warranty against manufacturing defects from the date of purchase. If a problem occurs, contact the store where you purchased it or Worten Equipamentos para o Lar.

Can I use the heater in a bathroom or humid area?

No, do not use in humid places. The heater must not be exposed to water or moisture. Keep away from sinks, baths, showers, etc.

What type of heater is the KHH3607?

It is a halogen heater with three quartz halogen tubes. It provides instant, directional heat, suitable for indoor use.

Can I replace the halogen tubes myself?

No, the interior contains no user-serviceable parts. Tube replacement must be done by a qualified technician. Unauthorized repairs void the warranty.

USER MANUAL KHH3607 Kunft

White Kuwait air conditioner with mesh grille and 'kunft' branding (no additional text or symbols visible)

halogen heater

is perfectly enough

KHH3607

kunft.®

Dear client,

We thank you for purchasing this product.

This appliance was submitted to several laboratorial tests, which certify its quality. To simplify the use of this appliance, this instruction manual has been provided.

The instructions must ensure a quick and safe use.

Please read carefully the instructions and safety measures described in this manual.

We wish our clients great satisfaction in using their new appliance.

2

INDEX

1. SAFETY INSTRUCTIONS .... 4

1.1. Power Supply 5
1.2. Power Cord and Other Cables 6
1.3. Humidity and Water 6
1.4. Cleaning 6
1.5. General Precautions ...... 6

1. UTILIZATION AND FUNCTIONING 8

2.1. Product Description ...... 8
2.2. Assembly 8
2.3. Operation 8

1. TECHNICAL SPECIFICATIONS ...... 9

2. POST-SALE SERVICE 9

3. ENVIRONMENTAL PROTECTION 9

kunft.®

1. SAFETY INSTRUCTIONS

	WARNING
	Risk of Electric ShockDo Not Open
Warning: to avoid the risk of electric shock, do not remove the cover.The interior does not contain any parts that can be repaired by the user. Ask for assistance by qualified personnel.

Important Warnings

Before using your appliance read this instructions manual carefully and keep it in a safe place as you may need to consult it in the future.

Before turning on your appliance, and to ensure a safe and correct operation, do not use if:

• It has fallen to the ground;
• You notice any evidence of damage;
• Any anomaly occurs during its operation.

To avoid hazards or deterioration of your appliance through incorrect use it is advisable to read these instructions thoroughly.

Your appliance may not be used for other purposes than the ones intended and solely for household use. Any damage resulting from using the appliance outside this scope, any incorrect use, as well as any ma-

nual modifications to the product will not be covered and automatically voids the warranty.

Assistance

In case of malfunction, take your appliance to a qualified technician for assistance.

This appliance can be used by children from the age of 8 and by people with reduced physical, sensorial or mental capabilities and/or lack of experience and knowledge if they have been given instructions on using the appliance safely and if they understand the hazards involved. Children may not play with the appliance. Cleaning and maintenance must not be carried out by children without supervision.

These instructions are also available at www.suporteworten.pt

1.1. Power Supply

Make sure the main voltage is compatible with the appliance's. If this is not the case please consult the Customer Support Service.

kunft.®

1.2. Power Cord and Other Cables

Do not tangle the cord or pull it to disconnect the appliance. Also, keep the cord away from warm surfaces.

Never use the appliance if it has a damaged cable or socket.

Take it to the Technical Support Service for replacement.

1.3. Humidity and Water

Do not use your appliance in humid places. Do not allow the appliance to become wet under any circumstances as this may be dangerous. To avoid fire hazard or electric shock do not expose your appliance to humidity or water. Furthermore, do not place your appliance under water (e.g. for cleaning).

1.4. Cleaning

Before cleaning, be sure to switch off the appliance and remove the plug from the main power supply. Always allow the unit to cool down before cleaning.

To clean the exterior of the product use a dry soft cloth only.

1.5. General Precautions

- Please follow the instructions in the user manual which help to properly install and operate this product and enjoy its advanced features. Please keep the instructions for future reference.

halogen heater

KHH3607

EN

• Read all instructions before using the product.
• Maintenance and service operations are only to be carried out by authorized professionals.
• Any damage caused by manual modifications to the product is not covered by the warranty.
• If this product is used for other purposes than the ones originally intended, or if it is not correctly connected, the product may become damaged and the warranty will be voided.

kunft.®

2. UTILIZATION AND FUNCTIONING

2.1. Product Description

1. Power switch and middle tube switch.

2. Lower tube power switch.

3. Upper tube switch.

4. Turning switch.

5. Upper lid.

6. Lattice net.

7. Halogen heating Tube.

8. Reflector.

9. Lattice net.

10. Grill.

11. Body frame.

12. Base plate.

13. Handle.

14. Power cord and plug.

15. Butterfly nuts.

16. Tip-over safety switch.

17. Power cord guide

Exterior view of a portable electronic device with labeled parts (13 and 14), no visible text or symbols beyond labels

Diagram of a portable electronic device with labeled parts (15, 16, 17), no readable text or symbols beyond part numbers

2.2. Assembly

Follow the instructions for assembly. Remove butterfly nuts from the base.

1) Pull the power cord through the base plate and place the cord through the cable channel to ensure that it is secure.
2) Ensure that the base plate is firmly in position and then gently screw the butterfly nuts into position and secure firmly.

2.3. Operation

1) Insert plug into socket.
2) Set the power supply switch (orange color) to the "ON" position. This will enable the upper and middle heating tube to start. To control the other tubes use switches 2 and 3.
3) To allow the heater to oscillate please press the 'TURN' button.

3. TECHNICAL SPECIFICATIONS

Model no. KHH3607

Rated voltage 220-240V \~ 50/60Hz

Rated output 1200W

Power consumption 400W-800W-1200W

4. POST-SALE SERVICE

KUNFT has designed this appliance in order to guarantee maximum reliability. However, if a problem occurs do not attempt to open the appliance - there is a risk of electrical shock. If you are not able to solve the problem, please contact the Costumer Support Service of any Worten, Modelo or Continente store in order to be assisted. Worten Equipamentos para o Lar provides a 2-year warranty for manufacturing defects from the date of purchase of the appliance.

WARNING: Any attempt to repair the appliance without contacting the manufacturer or seller will void the warranty.

All users must be familiar with these instructions. Knowing what could go wrong can help prevent problems from occurring.

5. ENVIRONMENTAL PROTECTION

In order to protect the environment we strive to reduce the volume of packaging used, limiting it to three easily sorted materials: cardboard, paper and plastic. The appliance is manufactured using recyclable materials after disassembled by a specialized company. Please comply with local regulations concerning the recycling of all materials.
