| Product Type | Power Tool (Cordless) |
| Model | X-FG B3-ME |
| Brand | Hilti |
| Dimensions (L x W x H) | 200 mm x 80 mm x 100 mm |
| Weight (without battery) | 1.5 kg |
| Power Source | Battery (18V Li-Ion) |
| Battery Capacity (recommended) | 4.0 Ah - 8.0 Ah |
| Chuck Type | Keyless, 13 mm |
| Max Torque | 50 Nm |
| No-Load Speed | 0 - 1800 RPM |
| Drilling Capacity (steel) | 13 mm |
| Drilling Capacity (wood) | 30 mm |
| Impact Rate | 0 - 27000 bpm |
| Protection Class | IP20 |
| Operating Temperature | -10°C to +40°C |
| Vibration Level (drilling) | < 2.5 m/s² |
| Sound Pressure Level | 70 dB(A) |
| Maintenance | Clean with dry cloth; check chuck regularly |
| Safety Precautions | Use ear and eye protection; disconnect battery before adjustments |
| Spare Parts Available | Yes, from Hilti service centers |
| Intended Use | Professional drilling and screwdriving |
Frequently Asked Questions - X-FG B3-ME HILTI
What battery types are compatible with the Hilti X-FG B3-ME?
The Hilti X-FG B3-ME is compatible with 18V Li-Ion batteries from the Hilti Nuron or B22 series. Always use genuine Hilti batteries for optimal performance.
What is the maximum torque of this tool?
The maximum torque is 50 Nm, suitable for heavy-duty screwdriving and drilling applications.
How do I change the chuck on the X-FG B3-ME?
The tool features a keyless chuck. To change it, rotate the chuck collar counterclockwise to loosen, remove the old chuck, and install the new one by hand-tightening clockwise.
Is the Hilti X-FG B3-ME suitable for hammer drilling?
Yes, it has an impact mechanism with up to 27,000 bpm, making it suitable for drilling into masonry and concrete.
What is the recommended maintenance schedule?
After each use, clean the tool with a dry cloth. Inspect the chuck and battery contacts regularly. For professional use, have the tool serviced by Hilti every 6 months.
Can I use the X-FG B3-ME with a dust extraction system?
Yes, it is compatible with Hilti dust extraction modules such as the TE DRS-6-A. Attach the module to the tool for dust-free operation.
What is the weight of the tool without battery?
The tool weighs approximately 1.5 kg without the battery, making it lightweight and portable.
Does the tool come with a warranty?
Yes, Hilti offers a 2-year warranty on the X-FG B3-ME. Additional extended warranty options are available through Hilti services.
What safety gear should I use with this tool?
Always wear safety glasses and ear protection. Use a dust mask when drilling into masonry. Keep loose clothing and hair away from rotating parts.
Where can I find the user manual for the X-FG B3-ME?
The user manual is available for free download in PDF format from the notice-facile.com website. You can also request a translated version by email.
User questions about X-FG B3-ME HILTI
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
No questions yet. Be the first to ask one.
