USER MANUAL CSA1420 COYOTE

Refrigeration & Island Accessories

Outdoor Refrigerator: CBIR (L/R)

• Outdoor rated, freestanding refrigerator with automatic defrost
• Stainless Steel exterior
- Interior light and adjustable thermostat
- Front vented for built-in application
• Left or Right swing hinge

COYOTE CSA1420 - Outdoor Refrigerator: CBIR (L/R) - 1

Drop-in Cooler: CDIC

• Stainless Steel, hinged lid with high quality lid seal
- Fully insulated
- Holds cans and/or bottles
- Drain hole stopper included

COYOTE CSA1420 - Drop-in Cooler: CDIC - 1

Single Storage Drawer with Shelf: CSSD

• Additional shelf space within drawer

COYOTE CSA1420 - Single Storage Drawer with Shelf: CSSD - 1

Two Drawer Cabinet: C2DC

• Large storage space within each drawer

COYOTE CSA1420 - Two Drawer Cabinet: C2DC - 1

Th ree Drawer Cabinet: C3DC

• Extended drawers on rollers facilitates smooth operation

COYOTE CSA1420 - Th ree Drawer Cabinet: C3DC - 1

17" X 24" Single Access Door CSA1724

- 17" hinge side access door (H x W)

24"X17" Single Access Door CSA2417

• 24" hinge side access door (H x W)

COYOTE CSA1420 - 24"X17" Single Access Door CSA2417 - 1

COYOTE CSA1420 - 24"X17" Single Access Door CSA2417 - 2

Pullout Drawer: CPOD

  • Extendable drawers on rollers
  • Interior of drawer includes cut-out to secure tank
  • Can be used to hold a trash can

COYOTE CSA1420 - Pullout Drawer: CPOD - 1

20" X 14" Single Access Door CSA2014

20" hinge side access door (H x W)

14" X 20" Single Access Door CSA1420

14" hinge side access door (H x W)

COYOTE CSA1420 - 14" X 20" Single Access Door CSA1420 - 1

COYOTE CSA1420 - 14" X 20" Single Access Door CSA1420 - 2

Paper Towel Holder: CPTH

- Convenient and easy to install

COYOTE CSA1420 - Paper Towel Holder: CPTH - 1

Stainless Steel Sink Model: CSINK

• 15 "X 14" X 7.5" Deep
• 18 gauge stainless steel
• Universal Mount

COYOTE CSA1420 - Stainless Steel Sink Model: CSINK - 1

natural_image Exterior view of a modern stainless steel square sink with a circular drain (no text or symbols)

26" Double Access Doors: CDA2426

31" Double Access Doors: CDA2431

39" Double Access Doors: CDA2439

  • Integrated door handles
    • Magnetic latches for easy closing
    • Paper towel holder inside door (CDA2431, CDA2439)

COYOTE CSA1420 - 39" Double Access Doors: CDA2439 - 1

COYOTE CSA1420 - 39" Double Access Doors: CDA2439 - 2

Drop in Griddle: CGRDL

• 14" commercial grade griddle
• Compatible with all Coyote Grills
- Easy cleanup removable drip tray

COYOTE CSA1420 - Drop in Griddle: CGRDL - 1

Coyote Single Side Burner: CSSB (LP/NG)

• Premium stainless steel & lid
• (1) 15k Brass Burner
- Cutout- 11 x 10.5 x 14
• Overall- 14.5 x 11.5 x 17

COYOTE CSA1420 - Coyote Single Side Burner: CSSB (LP/NG) - 1

Coyote Dual Side Burner: CDSB (LP/NG)

• Premium stainless steel & lid
• (2) 15k Brass Burners
- Cutout - 11 x 12 x 20.5
• Overall - 14.5 x 13.25 x 23

COYOTE CSA1420 - Coyote Dual Side Burner: CDSB (LP/NG) - 1

Coyote Warming Drawer: CWD

• Outdoor-rated ETL certifi ed
• Internal electric heating element
- 30" overall width

COYOTE CSA1420 - Coyote Warming Drawer: CWD - 1

Coyote Grill Covers

• Available for all grills, carts and side burners

COYOTZ

Coyote Centaur Hybrid Grill 1/2 Gas ; 1/2 Charcoal (CH50)

• LP/NG side - 600 sq in cooking space
- Interior hood lights
• 2 high powered Coyote iBurners™
• Charcoal/Wood Chip Friendly
- Overall Grill Dimensions 25.5" x 50" x 23.625"

COYOTE CSA1420 - Coyote Centaur Hybrid Grill 1/2 Gas ; 1/2 Charcoal (CH50) - 1

natural_image Front view of a two-tier appliance with control buttons and a display panel (no visible text or symbols)

Refrigeration & Island Accessory Cutouts

This "flysheet" only shows the cutout dimensions needed for Coyote product. It does not show overall product dimensions. Always refer to your owners manual before operating your grill for specific safety instructions and consumer guidelines. Clearance to Combustibles for all Gas Related Products is 24". Unless, an authorized Coyote Insulated Jacket is used for install. Installation of Equipment: * All grills and sideburners come with the necessary regulator only. Any further hook-up pieces (shut-off valves, nipples, tees, etc) must be procured and purchased separately, as each install is unique to the job. * All units rest on their own frame and do not need to be supported from underneath. * For the doors and drawers you will need to acquire your own screws and/or appropriate anchors, as these too are unique to each job and will vary drastically depending on your building material. GRILL CDSB CSSB CDIC CSINK 17 1/4" 10 1/8" 14' CHSO 1 1/8" Depth 1 5/8" Wide 1 1/8" 1 1/8" 1 1/8" 1 1/8" 20 1/2" 20 1/2" 20 1/2" 20 1/2" 20 1/2" 20 1/2" 20 1/2" 20 1/2" 20 1/2" 20 1/2" 20 1/2" 20 1/2" 20 1/2" 20 1/2" 20 1/2" CPOD CPTH CSSD 13 1/2" 13 1/2" 13 1/2" 13 1/2" 13 1/2" 13 1/2" 13 1/2" 13 1/2" 13 1/2" 13 1/2" 13 1/2" 13 1/2" 13 1/2" 13 1/2" 13 1/2" 14 1/4" CDA 20 1/2" CSA H C300 24 1/2" C20C 20 1/2" COBC 32 1/2" COAR 33 1/2" CBIR 33 5/8" 9 1/2" CWD Depth of CWD = 23 1/2" CDA2426 - 20 3/4" CDA2431 - 25 1/2" W Cutout Guide for CSA Doors CDA2439 - 34 1/2" CSA2014 - 20 1/2" (H) x 14 1/2" (W) CSA1420 - 14 1/2" (H) x 20 1/2" (W) CSA2417 - 24 1/2" (H) x 17 1/2" (W) CSA1724 - 17 1/2" (H) x 24 1/2" (W) Ventilation of the Island: * A minimum of two vents, of at least 30 sq in/vent must be located on a outdoor kitchen that has any Coyote Grill or Sideburner. This is due for Safety and also Efficiency of the units. *For any refrigerator to work properly, you must have proper ventilation with fresh airflow. *Both the COAR and COBC vent themselves from the bottom rear of the unit. This means that you must allow at least either 6" of open space between the back wall and the unit, if the cabinet space for the unit has fresh air coming into it. Or, you must have a vent installed at the bottom of your island where the unit is located and the unit can pull fresh air directly from the outside. This vent should not be less than 60 sq in in area. *The CBIR is vented from the bottom front and does not require any extra/special venting. Showing atv 1 of the 2 vents required for safe use of your Coyote Products. Grill Installation Codes: These gas appliances must be installed in accordance with all local codes. In areas without local codes, follow the latest edition of the National Fuel Gas Code ANSI 2223.1. In Canada, installation must conform to standard CAN/CGA 1b149.1 or 1b149.2 (Instalation Code for Gas Burning)

Grill Installation Codes: These gas appliances must be installed in accordance with all local codes. In areas without local codes, follow the latest edition of the National Fuel Gas Code ANSI 2223.1. In Canada, installation must conform to standard CAN/CGA 1b149.1 or 1b149.2 (Irrinstallation Code for Gas Burning Appliances and Equipment) and all local codes.
