| Product Type | KVM over IP Extender |
| Model | Altusen KE8952R |
| Manufacturer | ATEN |
| Dimensions (W x D x H) | 20.0 x 15.0 x 4.4 cm |
| Weight | 1.2 kg |
| Power Supply | DC 5V / 2A |
| Video Resolution (Max) | 1920 x 1200 @ 60 Hz |
| Remote Access | Over IP (RJ-45) |
| Supported Interfaces | HDMI, USB, RS-232 |
| Features | Zero U, rack-mountable |
| Maintenance | Clean with dry, soft cloth. Do not use liquid cleaners. |
| Safety Precautions | Operate between 0°C and 50°C. Avoid direct sunlight and moisture. |
| Spare Parts | Power adapter; contact ATEN support for other parts |
| Repairability | Refer to qualified personnel; no user-serviceable parts inside |
| General Information | Extend keyboard, mouse, and video up to 300 m via Cat 5e/6 cable |
Frequently Asked Questions - Altusen KE8952R ATEN
What is the maximum video resolution supported by the KE8952R?
The KE8952R supports a maximum video resolution of 1920 x 1200 at 60 Hz.
How do I connect the KE8952R over IP?
Connect the transmitter unit to your computer via HDMI and USB. Then connect the transmitter to your network using an RJ-45 cable. The receiver unit connects to the remote console and also to the network. Ensure both units are on the same subnet.
What is the maximum transmission distance?
With Cat 5e/6 cable, the KE8952R can extend signals up to 300 meters.
Does the KE8952R support RS-232?
Yes, it supports RS-232 serial communication for controlling devices such as serial consoles.
How can I update the firmware?
Download the latest firmware from ATEN's support website. Use the firmware update utility (e.g., via the web interface or a dedicated tool) while the unit is powered and connected.
Can I use the KE8952R with HDMI 2.0?
The KE8952R supports HDMI 1.4 specifications. It is not compatible with HDMI 2.0 features like 4K at 60 Hz.
Is the KE8952R compatible with USB 3.0?
No, it supports USB 2.0 for keyboard and mouse. For high-speed USB devices, consider a different model.
What are the power requirements?
The unit requires a DC 5V / 2A power adapter. Use only the provided adapter or an equivalent certified one.
Does the KE8952R support daisy-chaining?
No, it is a single extender pair. For multi-Console setups, use an ATEN KVM switch in combination.
How do I reset the KE8952R to factory defaults?
Press and hold the reset button (located on the unit) for 10 seconds until the power LED blinks. This restores default IP settings and configuration.
