BP-828 - Camera battery Watson - Free user manual and instructions

Product Type	Camera Battery
Model Number	BP-828
Brand	Watson
Chemistry	Lithium-Ion (Li-ion)
Voltage	7.2 V
Capacity	1800 mAh
Dimensions (L x W x H)	50 x 35 x 20 mm
Weight	80 g
Compatibility	Canon PowerShot, ELPH series
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 45°C
Overcharge Protection	Built-in
Short Circuit Protection	Yes
Charging Time (approx.)	2-3 hours
Cycle Life	Up to 500 charge cycles
Maintenance	Keep terminals clean; avoid extreme temperatures
Safety Features	Overcurrent, overvoltage, temperature control
Spare Parts Availability	Branded replacements available online
Warranty	1 year
Certifications	CE, RoHS

Frequently Asked Questions - BP-828 Watson

Which cameras are compatible with the Watson BP-828 battery?

The Watson BP-828 is compatible with Canon PowerShot and ELPH series cameras that use the NB-4L or NB-5L battery models. Always check your camera's manual for compatibility.

How long does it take to fully charge the BP-828 battery?

Charging time is approximately 2 to 3 hours using a standard charger. Use only a compatible Watson charger for optimal performance.

What is the capacity of the BP-828 battery?

The BP-828 has a capacity of 1800 mAh, providing reliable power for extended photo sessions.

Is the Watson BP-828 a rechargeable battery?

Yes, it is a rechargeable Lithium-Ion (Li-ion) battery designed for repeated use.

How should I store the BP-828 battery when not in use?

Store in a cool, dry place between 0°C and 25°C. Avoid full discharge; keep at about 50% charge for long-term storage.

What safety protections does the BP-828 have?

The battery includes built-in protections against overcharge, overdischarge, short circuit, and overheating.

Can I use the Watson BP-828 as a replacement for my original Canon battery?

Yes, the Watson BP-828 is a direct replacement for Canon NB-4L/NB-5L batteries, offering similar performance and fit.

How many charge cycles can I expect from this battery?

The BP-828 typically lasts up to 500 charge cycles before noticeable capacity loss occurs.

What is the voltage of the BP-828?

The battery outputs a standard voltage of 7.2 V.

Does the Watson BP-828 come with a warranty?

Yes, it includes a 1-year limited warranty against manufacturing defects.

USER MANUAL BP-828 Watson

Please read before using this equipment.

Blue 3D illustration of a folded or layered object with smooth edges and no visible text or symbols

Abstract geometric pattern with yellow and white shapes (no text or symbols)

Thank you for purchasing the Watson Li-ion Battery Pack.

Browse through this manual for information and useful tips on how to use your new equipment.

SAFETY INSTRUCTIONS:

- Charge the battery pack before use. Read your camcorder or digital camera manual for charging instructions.

- When not in use, remove the battery pack from its device and store in a cool, dry place.

- Do not short circuit the terminals. This battery is protected with an internal self-resetting fuse, but short circuits may still cause severe damage to the battery. Be careful where you set the battery down.

• Under no circumstance attempt to open the battery case.
- Do not expose the battery to rain or moisture.

- Keep away from fire. Do not incinerate. Battery may explode in the presence of fire.

- Do not drop battery or expose it to strong shocks.

- Do not use at temperatures below 15°F (-10°C) or above 105°F (40°C). Use of the battery at very high temperatures will activate a safety circuit, disallowing use.

- Running time depends on the power demanded. Stated manufacturer run times are developed in simple laboratory tests of non-stop recording. Real-life use of zoom, automatic focus, tape review, etc., all demand extra power and shorten run time.

TO MAXIMIZE BATTERY PERFORMANCE

• Make sure the battery is fully charged before use.
- Clean the battery and terminals with a clean, soft, dry cloth.
• The battery may be warm during use on recharging. This is normal.
- When storing the battery for an extended period, be sure that it is not completely charged, nor completely discharged.

The ideal level is a 40% charge. This is approximate; the closer the battery is to this level, the better it will hold its charge during storage. The battery should be stored in a cool, dry place. The recommended temperature for storage is 59°F (15°C). You may store a battery in a refrigerator. Do not store batteries in a freezer.

- Remove the battery from your equipment when not in use. Some electronic equipment will draw current even when the switch is off.

- When operation time has noticeably shortened, the battery may need to be replaced.

ONE-YEAR LIMITED WARRANTY

This Watson product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later. The warranty provider's responsibility with respect to this limited warranty shall be limited solely to repair or replacement, at the provider's discretion, of any product that fails during normal use of this product in its intended manner and in its intended environment. Inoperability of the product or part(s) shall be determined by the warranty provider. If the product has been discontinued, the warranty provider reserves the right to replace it with a model of equivalent quality and function. This warranty does not cover damage or defect caused by misuse, neglect, accident, alteration, abuse, improper installation or maintenance. EXCEPT AS PROVIDED HEREIN, THE WARRANTY PROVIDER MAKES NEITHER ANY EXPRESS WARRANTIES NOR ANY IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. This warranty provides you with specific legal rights, and you may also have additional rights that vary from state to state. To obtain warranty coverage, contact the Watson Customer Service Department to obtain a return merchandise authorization ("RMA") number, and return the defective product to Watson along with the RMA number and proof of purchase. Shipment of the defective product is at the purchaser's own risk and expense.

For more information or to arrange service, visit www.poweredbywatson.com or call Customer Service at 212-594-2353.

WATSON™ A Gradus Group Brand

Product warranty provided by the Gradus Group. Watson is a registered trademark of the Gradus Group. © 2016 Gradus Group LLC. All Rights Reserved.

WATSON

www.poweredbywatson.com
