Brand	Impact
Model	KCP-220
Product Type	Extension Arm for Tripod or Light Stand
Length	20 inches (50.8 cm)
Grip Head Size	2.5 inches (6.35 cm)
Maximum Load Capacity	10 lbs (4.54 kg)
Weight	2.37 lbs (1.07 kg)
Color	Silver (model shown) or Black (available)
Material	Metal (aluminum or steel)
Compatible Accessories	Impact KCP-200B Grip Head, C-stands, Varipoles, Clamps
Care Instructions	Clean with a soft dry cloth
Safety Warnings	Do not exceed maximum load; keep away from children; ensure secure attachment
Warranty	1-year limited warranty
Manufacturer	Impact (A Gradus Group Brand)
Country of Origin	China

Frequently Asked Questions - KCP-220 Impact

What is the maximum load capacity of the Impact KCP-220 extension arm?

The maximum load capacity is 10 lbs (4.54 kg).

What is the length of the KCP-220 extension arm?

The KCP-220 extension arm is 20 inches (50.8 cm) long.

Does the KCP-220 come with a grip head?

No, the KCP-220 is an extension arm only. A grip head such as the Impact KCP-200B is sold separately.

Can the KCP-220 be used with a C-stand?

Yes, it is designed for use with C-stands. Recommended models include the Impact LS-CT20M and LS-CT40MB.

How do I clean and maintain the KCP-220?

Clean with a soft dry cloth. Do not use abrasive cleansers or solvents.

What is the grip head size of the KCP-220?

The grip head size is 2.5 inches (6.35 cm).

What is the weight of the KCP-220 extension arm?

It weighs 2.37 lbs (1.07 kg).

Is there a longer version of this extension arm?

Yes, the Impact KCP-240/B is a 40-inch (101.6 cm) version.

What is the warranty on the KCP-220?

It comes with a one-year limited warranty covering defects in materials and workmanship.

Can I use the KCP-220 to hold lighting fixtures?

Yes, it can hold light fixtures weighing up to 10 lbs on the 16 mm (5/8") end of the arm.

USER MANUAL KCP-220 Impact

KCP-220P/B KCP-240/B

Extension Arm

Silver model shown

Thank you for choosing Impact.

Extension arms are great accessories for holding framed light modifiers in the fixed grip head, or for light fixtures weighing 10 pounds (or less) on the 16 mm (5/8") end of the arm.

Specifications

	KCP-220P/B KCP-240/B
Extension arm length: 20" (50.8 cm) 40" (101.6 cm)
Grip head size 2.5" (6.35 cm)
Maximum load capacity: 10 lbs (4.54 kg)
Weight: 2.37 lbs (1.07 kg) 3.25 lb. (1.47 kg)

Recommended Accessories

• Impact KCP-200B Grip Head, Black - 2.5"
• Impact LS-CT20M 20" C-Stand with Turtle Base, Silver
• Impact LS-CT40MB 10.75' C-Stand with Turtle Base, Black
• Impact LS-CS40MK 10.75' C-Stand Kit with Sliding Leg, Extention Arm and Grip Head, Silver
• Impact VP-712BP Deluxe Varipole Set of Two, Black
• Impact VP-712SP Deluxe Varipole Set of Two, Silver

• Impact VPE-5B 59" Single Extension for Varipole, Black

• Impact VPE-5S 59" Single Extension for Varipole, Silver

• Impact VPE-6B 78" Single Extension for Varipole, Black
• Impact CC-106R Super Clamp w/Ratchet Handle
• Impact CC-128 Double Super Clamp
• Impact LSA-CW10 Counter Balance Weight (10 lb)
• Impact SRP-118 Heavy Duty Swivel Pin
• Impact SRP-121 Baby Drop Down Pin
• Impact ME-107 Grip Head w/Super Clamp

Visit our website at www.impactstudiolighting.com for more Impact accessories.

Warnings

• Do not attempt to disassemble or repair the equipment – doing so will void the warranty, and Impact Studio Lighting will not be responsible for any damage.
• Handle the unit with care.
• Clean the unit with a soft dry cloth.
• Keep this unit away from children.
• Use only parts provided by the manufacturer.
• Make sure everything is secure before proceeding.
• Make sure the item is intact and that there are no missing parts.
• Do not exceed the maximum load capacity.

One-Year Limited Warranty

This IMPACT product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later. The warranty provider's responsibility with respect to this limited warranty shall be limited solely to repair or replacement, at the provider's discretion, of any product that fails during normal use of this product in its intended manner and in its intended environment. Inoperability of the product or part(s) shall be determined by the warranty provider. If the product has been discontinued, the warranty provider reserves the right to replace it with a model of equivalent quality and function.

This warranty does not cover damage or defect caused by misuse, neglect, accident, alteration, abuse, improper installation or maintenance. EXCEPT AS PROVIDED HEREIN, THE WARRANTY PROVIDER MAKES NEITHER ANY EXPRESS WARRANTIES NOR ANY IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. This warranty provides you with specific legal rights, and you may also have additional rights that vary from state to state.

To obtain warranty coverage, contact the Impact Customer Service Department to obtain a return merchandise authorization ("RMA") number, and return the defective product to impact along with the RMA number and proof of purchase. Shipment of the defective product is at the purchaser's own risk and expense.

For more information or to arrange service, visit www.impactstudiolighting.com or call Customer Service at 212-594-2353.

IMPACT™

A Gradus Group Brand

Product warranty provided by the Gradus Group.

www.gradusgroup.com

IMPACT is a registered trademark of the Gradus Group.

© 2015 Gradus Group LLC. All Rights Reserved.

Made in China
