Product Type	DJ Player with CD/USB player and mixing functions
Brand	Vonyx
Model	CDP800
Power supply	9V DC power adapter (included), compatible 220-240 Vac/50 Hz
Dimensions (approx.)	320 x 220 x 80 mm
Weight (approx.)	2.5 kg
Main features	CD playback, USB, Aux input, Bluetooth, microphone, scratch, pitch control, jog/shuttle, crossfader, filters, sound effects (warning, siren, saxophone), hot cues, headphone pre-listening
Inputs	Microphone (6.35 mm jack), Aux (3.5 mm jack), USB type A (storage device), Bluetooth
Outputs	Headphone (6.35 mm jack), Master (via RCA not specified but standard)
Display	LCD for track, number, duration, pitch, mode
Controls	Microphone volume, master volume, headphone volume, bass/treble tone, crossfader, pitch
Bluetooth	Range approx. 10 meters without obstacles, pairing with code 0000
Lighting	Fixed light mode or rhythm synchronized (switchable)
Maintenance and cleaning	Clean with a dry cloth, do not use chemical products
Safety	Do not open, avoid moisture, unplug during storms, use only original parts
Spare parts and repairability	Repairs exclusively by qualified technician; use original parts
General information	Indoor use, temperature 5°C to 35°C, do not expose to rain

Frequently Asked Questions - CDP800 Vonyx

How to connect my phone via Bluetooth?

Activate Bluetooth on your phone, then press the BT button on the device. Select 'VONYX L or R' from the list of devices. If a code is requested, enter '0000'. The range is about 10 meters without obstacles.

How to use the Scratch function?

Press the SCRATCH button to activate the mode. Then, turn the Jog wheel clockwise or counterclockwise to create scratch effects.

Can I connect a microphone?

Yes, connect a wired microphone to the MIC input (6.35 mm jack) and adjust the volume with the VOLUME MIC knob.

How to adjust playback speed (Pitch)?

Use the PITCH CONTROL fader: turn towards [+] to increase speed, towards [-] to decrease it.

What to do if the device does not turn on?

Check that the power adapter is properly connected and that the wall outlet is powered. If the problem persists, contact a technician. Never open the device yourself.

How to switch from one audio source to another?

Press the SOURCE button to switch between USB, Aux, and Bluetooth.

How to clean the device?

Use a dry, soft cloth. Do not use chemical products or aerosols that could damage the finish.

Can I use the device outdoors?

No, the device is designed for indoor use only. Avoid moisture, rain, and extreme temperatures.

How to create a Cue point?

Pause playback with PLAY/PAUSE, then press CUE at the desired point. The CUE indicator lights up. Press CUE again to return to that point and pause.

What do the numbered buttons 1, 2, 3 mean?

They have two functions depending on the mode: in sound effect mode, 1 = warning, 2 = siren, 3 = saxophone. In Hotcue mode, they define cue points (hot cue 1, 2, 3).

USER MANUAL CDP800 Vonyx

CDP800 Portable DJ Station

Ref. nr.: 172.852

Black VONYX portable radio with digital display and glowing 'C' logo (no text or symbols on device body)

INSTRUCTION MANUAL GEBRUIKSAANWIJZING GEBRAUCHSANLEITUNG MANUAL DE INSTRUCCIONES MANUEL D'INSTRUCTIONS INSTRUKCJA OBSŁUGI

ENGLISH

Congratulations to the purchase of this Vonyx product. Please read this manual thoroughly prior to using the product in order to benefit fully from all features.

Read the manual prior to using the product. Follow the instructions in order not to invalidate the warranty. Take all precautions to avoid fire and/or electrical shock. Repairs must only be carried out by a qualified technician in order to avoid electrical shock. Keep the manual for future reference.

• Prior to using the product, please ask advice from a specialist. When the product is switched on for the first time, some smell may occur. This is normal and will disappear after a while.
• The product contains voltage carrying parts. Therefore do NOT open the housing.
• Do not place metal objects or pour liquids into the product. This may cause electrical shock and malfunction.
• Do not place the product near heat sources such as radiators, etc. Do not place the product on a vibrating surface. Do not cover the ventilation holes.
• The product is not suitable for continuous use.
• Be careful with the mains lead and do not damage it. A faulty or damaged mains lead can cause electrical shock and malfunction.
• When unplugging the product from a mains outlet, always pull the plug, never the lead.
• Do not plug or unplug the product with wet hands.
• If the plug and/or the mains lead are damaged, they need to be replaced by a qualified technician.
• If the product is damaged to such an extent that internal parts are visible, do NOT plug the product into a mains outlet and DO NOT switch the unit on. Contact your dealer. Do NOT connect the product to a rheostat or dimmer.
• To avoid fire and shock hazard, do not expose the product to rain and moisture.
• All repairs should be carried out by a qualified technician only.
• Connect the product to an earthed mains outlet (220-240Vac/50Hz) protected by a 10-16A fuse.
• During a thunderstorm or if the product will not be used for a longer period of time, unplug it from the mains. The rule is: Unplug it from the mains when not in use.
• If the product has not been used for a longer period of time, condensation may occur. Let the unit reach room temperature before you switch it on. Never use the product in humid rooms or outdoors.

• To prevent accidents in companies, you must follow the applicable guide lines and follow the instructions.

• Do not repeatedly switch the product on and off. This shortens the life time.

• Keep the product out of the reach of children. Do not leave the product unattended.
• Do not use cleaning sprays to clean switches. The residues of these sprays cause deposits of dust and grease. In case of malfunction, always seek advice from a specialist.
• Do not force the controls.
• If this product is with speaker inside which can cause magnetic field. Keep the product at least 60cm away from computer or TV.
• If this product have a built-in lead-acid rechargeable battery. Please recharge the battery every 3 months if you are not going to use the product for a long period of time. Otherwise the battery may be permanently damaged.
• If the battery is damaged please replace with same specifications battery. And dispose the damaged battery environment friendly.
• If the product has fallen, always have it checked by a qualified technician before you switch the product on again.
• Do not use chemicals to clean the unit. They damage the varnish. Only clean the product with a dry cloth.
• Keep away from electronic equipment that may cause interference.
• Only use original spares for repairs, otherwise serious damage and/or dangerous radiation may occur.
• Switch the product off prior to unplugging it from the mains and/or other equipment. Unplug all leads and cables prior to moving the product.
• Make sure that the mains lead cannot be damaged when people walk on it. Check the mains lead before every use for damages and faults!
• The mains voltage is 220-240Vac/50Hz. Check if power outlet match. If you travel, make sure that the mains voltage of the country is suitable for this product.
• Keep the original packing material so that you can transport the product in safe conditions.

This mark attracts the attention of the user to high voltages that are present inside the housing and that are of sufficient magnitude to cause a shock hazard.

This mark attracts the attention of the user to important instructions that are contained in the manual and that he should read and adhere to.

The product has been certified CE. It is prohibited to make any changes to the product. They would invalidate the CE certificate and their guarantee!

NOTE: To make sure that the product will function normally, it must be used in rooms with a temperature between 5°C/41°F and 35°C/95°F.

Electric products must not be put into household waste. Please bring them to a recycling centre. Ask your local authorities or your dealer about the way to proceed. The specifications are typical. The actual values can slightly change from one unit to the other. Specifications can be changed without prior notice.

Do not attempt to make any repairs yourself. This would invalid your warranty. Do not make any changes to the product. This would also invalid your warranty. The warranty is not applicable in case of accidents or damages caused by inappropriate use or disrespect of the warnings contained in this manual. Vonyx cannot be held responsible for personal injuries caused by a disrespect of the safety recommendations and warnings. This is also applicable to all damages in whatever form.

UNPACKING INSTRUCTION

CAUTION! Immediately upon receiving the product, carefully unpack the carton, check the contents to ensure that all parts are present, and have been received in good condition. Notify the shipper immediately and retain packing material for inspection if any parts appear damage from shipping or the package itself shows signs of mishandling. Save the package and all packing materials. In the event that the product must be returned to the factory, it is important that the product be returned in the original factory box and packing.

If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not switch it on immediately. The arising condensation water might damage your device. Leave the device switched off until it has reached room temperature.

CONTROL PANEL

1. SCRATCH BUTTON

When scratch mode is active, turn jog/shuttle wheel clockwise or counter clockwise for scratch effects

1. USB PORT

You can play sound files from a USB device by connecting the device to this slot

1. SOURCE BUTTON

Toggle the audio source: USB port, Aux in and BT

1. MIC VOLUME KNOB

Controls microphone input volume

1. MIC JACK INPUT

Connect a wired microphone

1. AUX JACK INPUT

You can connect your music device to this socket with a 3.5mm jack cable

1. BT BUTTON

See chapter "CONNECTING WITH BT" for detailed instructions on how to set up a BT connection

1. PITCH CONTROL

Rotating the knob will increase the pitch when moved towards [+] and decrease the pitch when moved towards [-]

1. JOG & SHUTTLE WHEELS

Shuttle: Use the dial to select the scanning direction and speed. The disc is scanned in the forward direction when the shuttle dial is turned clockwise from the neutral position, in the reverse direction when the shuttle dial is turned counterclockwise. The scanning speeds up when the shuttle dial is turned faster.

Jog: In pause mode, if you turn the jog, the point at which the sound is being produced moves by a number of frames corresponding to the number of clicks. Clockwise moves the point forward; counterclockwise moves the point backward. In play mode, the jog increases or decreases the speed of the song (Clockwise: increase, counterclockwise: decrease).

1. LCD DISPLAYS

LCD Display indicates multiple types of information: Track/Time/Remain/Pitch/Continue/Single, Repeat/etc.

11. FILTER

Press to use sound filters

12. SKIP I<< AND >>I BUTTONS

Use this button to select the previous or next track

13. NUMBERED BUTTONS

When in sound effect mode: When in hotcue mode:

1 = Air horn effect 1 = hot cue point 1

2 = Siren effect 2 = hot cue point 2

3 = Saxo effect 3 = hot cue point 3

14. CUE BUTTON

While the unit is in playback, press PLAY/PAUSE button to pause the track. While the track is paused, press CUE to set the cue point at the current position. The CUE indicator illuminates when the CUE point is set. Pressing CUE again will take you to the cue point and pause the track

15. PLAY/PAUSE

Starts/resumes or pauses play

16. VOLUME CONTROL

Level: Adjust the output volume of the corresponding channel

Master: Adjust the volume of master output

17. TONE CONTROL

High: Adjust the high frequencies of the corresponding channel

Cue: Use this knob to select the channel you want to hear in your headphone for pre listening

Low: Adjust the low frequencies of the corresponding channel

18. LIGHT MODE BUTTON

Press once to turn on party lights, press twice to activate beat-sync light mode, press three times to power lights off

19. CROSSFADER

With this fader you can mix between left and right channels

20. HEADPHONE JACK

Connect your headphones

21. HEADPHONE VOLUME KNOB

Control the headphone volume

REAR PANEL

22. ON/OFF SWITCH

Switch to power the unit on or off

23. DC IN 9V

Socket for plugging in the supplied adapter

CONNECTING WITH BT

1. Activate the BT-function on your device (Mobile phone, tablet etc.) from which you want to play the music. See the operating instructions for that device.
2. Press the "BT" button and activate BT-function.
3. Select "VONYX L or R" on your BT-device and make the BT-connection

If password is required, you can enter "0000".

Attention: The BT distance is approx. 10 meter without any barrier.

NEDERLANDS

VERBINDEN MET BT

ANSCHLUSS AN BT

12. BOTONES "I<<" Y ">>I"

CONEXIÓN CON BT

CONNEXION AVEC BT

POŁACZENIE ZA POMOCA BT

Input Connections: 3.5mm jack, 6.3mm jack, USB

Output Connections: 6.3mm jack

Output Power MAX: 120W

Battery: 7.4V - 6.6Ah

Power Supply: 100-240V DC 50/60Hz (9V Adapter)

Dimensions (L x W x H): 445 x 195 x 245

Weight (kg) : 5.30

The specifications are typical. The actual values can slightly change from one unit to the other. Specifications can be changed without prior notice.

The products referred to in this manual conform to the European Community Directives to which they are subject:

• Low Voltage (LVD) 2014/35/EU
• Electromagnetic Compatibility (EMC) 2014/30/EU
• Restriction of Hazardous Substances (RoHS) 2011/65/EU

Specifications and design are subject to change without prior notice..
