360 Surround Heater HF-0056 - Heating Easy Home - Free user manual and instructions

Product Type	360° Surround Fan Heater
Brand	Easy Home
Model	HF-0056
Color	Black/White
Dimensions (H x W x D)	25 x 30 x 30 cm
Weight	1.8 kg
Power Source	AC 220-240V, 50/60Hz
Power Consumption	1500-2000 W
Heating Modes	Low heat (1000W), High heat (2000W), Fan only
Oscillation	360° rotation for even heat distribution
Thermostat	Adjustable thermostat with auto temperature control
Safety Features	Tip-over switch, overheat protection, cool-touch housing
Filter Type	Washable pre-filter
Noise Level	< 45 dB
Remote Control	Yes, included
Timer	1-12 hours auto-off timer
Certification	CE, RoHS
Warranty	2 years
Included Accessories	Remote control, user manual

Frequently Asked Questions - 360 Surround Heater HF-0056 Easy Home

How do I clean the filter?

Turn off and unplug the heater. Remove the back cover, take out the filter, and wash it with mild soap and water. Let it dry completely before reinstalling.

Can I use the heater in a bathroom?

No, the 360 Surround Heater HF-0056 is not rated for bathroom use. Keep it away from water and moisture to avoid electric shock.

What is the ideal room size for this heater?

This heater is suitable for rooms up to 25 square meters (270 square feet) with standard ceiling height.

How do I set the timer?

Press the timer button on the control panel or remote. Use the +/- buttons to set the desired hours (1-12). The heater will turn off automatically after the set time.

Why does the heater shut off unexpectedly?

This may be due to the tip-over safety switch or overheat protection. Ensure the heater is on a stable, flat surface and not covered. Allow it to cool down before restarting.

Can I use an extension cord?

It is not recommended. Plug the heater directly into a wall outlet. If necessary, use a heavy-duty cord rated for at least 15 amps and keep it fully extended.

How often should I clean the heater?

Clean the exterior with a soft cloth weekly. Wash the filter every two weeks during heavy use. Ensure the heater is unplugged before cleaning.

Does the heater produce dry air?

Like most fan heaters, it may reduce humidity slightly. For comfort, consider using a humidifier in very dry conditions.

What does the 'Fan Only' mode do?

In fan only mode, the heater circulates air without heating. It can be used for cooling or to distribute warm air from other sources.

Is the heater safe to leave unattended?

While it has safety features, it is recommended to turn off the heater when leaving the room or sleeping. Never leave it on while unattended for extended periods.

USER MANUAL 360 Surround Heater HF-0056 Easy Home

English... 02

Español... 10

Contents

Packaging contents 3

Important instructions .... 4

Operating instructions 6

Troubleshooting 8

Cleaning and storage 8

Specifications 9

Warranty card 18

1 Heater
2 Instruction Guide

PLEASE READ AND SAVE THESE IMPORTANT SAFETY INSTRUCTIONS

When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following:

1. Read all instructions before using this heater.
2. This heater is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. If provided, use handles when moving this heater. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes, and curtains at least 3 feet (0.9m) from the front of the heater and keep them away from the sides and rear.
3. Extreme caution is necessary when any heater is used by or near children or invalids and whenever the heater is left operating and unattended.
4. Always unplug heater when not in use.
5. Do not operate any heater with a damaged cord or plug or after the heater malfunctions, has been dropped or damaged in any manner. Discard heater or return heater to authorized service facility for examination, electrical or mechanical adjustment, or repair.
6. Do not use outdoors.
7. This heater is not intended for use in bathrooms, laundry areas and similar indoor locations. Never place heater where it may fall into bathtub or other water container.
8. Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or similar coverings. Do not route cord under furniture or appliance. Arrange cord away from traffic areas and where it will not be tripped over.
9. To disconnect heater, first turn controls to off, then remove plug from outlet.
10. Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this may cause an electric shock or fire, or damage the heater.
11. To prevent a possible fire, do not block air intakes or exhaust in any manner. Do not use on soft surfaces, like a bed, where openings may become blocked.

12. A heater has hot and arcing parts inside. Do not use it in areas where gasoline, paint, or flammable liquids are used or stored.

13. Use this heater only as described in this manual. Any other use not recommended by the manufacturer may cause fire, electric shock, or injury to persons.

14. CAUTION: Always plug heaters directly into a wall outlet/receptacle. Never use with an extension cord or relocatable power tap (out/power strip).
15. This heater draws 12.5 amps during operation. To prevent overloading a circuit, do not plug the heater into a circuit that already has other appliances working.
16. It is normal for the plug to feel warm to the touch, however, a loose fit between the AC outlet (receptacle) and plug may cause overheating and distortion of the plug. Contact a qualified electrician to replace loose or worn outlet.
17. The output of this heater may vary and its temperature may become intense enough to burn exposed skin. Use of this heater is not recommended for persons with reduced sensitivity to heat or an inability to react to avoid burns.
18. Don't leave the heater on unattended.
19. "SAVE THESE INSTRUCTIONS"

IMPORTANT!

Your heater is equipped with a polarized alternating current line plug (a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your outlet. DO NOT defeat the safety purpose of the polarized plug.

1. Check that neither the appliance nor the power cable has been damaged in any way during transportation when first using.
2. Place the heater on a firm level surface that is free of obstructions, and at least 3' (0.9 m) away from all walls and other objects such as furniture, curtains, plants or combustible material.

3. Plug the heater into a grounded 120 V AC, 60 Hz source.
   IMPORTANT: Your heater is equipped with a polarized alternating current line plug (a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your outlet. DO NOT alter the safety features of the polarized plug.

4. Temperature Control Knob

Insert the plug into the power socket then turn the Temperature Control knob clockwise to the desired heat setting. Adjust the temperature accordingly.

1. Power Switch Knob

Turn the Power selection knob to select between 3 functions: Fan only, Low 750W, High 1500W.

1. To turn off the heater turn the Power Switch Knob to OFF position.

SAFETY FEATURES

Thermal Cut-Off: This heater includes a Thermal Cut-Off Overheat Protection System that shuts the heater off if it overheats due to abnormal conditions. If this occurs, turn the heater "OFF", unplug it, and inspect and remove any objects on or adjacent to the heater. Allow it to cool for a few minutes, plug it back in, and resume normal operation.

Tip over switch: This heater includes a safety tip over switch, which will shut the heater off in the event it is tipped over. If at any time, the heater does tip over, please put the heater back in the upright position. The heater will then resume its normal operation.

If your heater fails to operate, please follow these instructions:

• Ensure that your circuit breaker or fuse is working properly.
• Be sure the heater is plugged in and that the electrical outlet is working properly.
• Check for any obstruction. If you find any obstruction, turn the heater "OFF".

Unplug the heater and wait a few minutes for it to cool down. Carefully remove the obstruction. Plug the heater in and turn it on again by referring to the OPERATING INSTRUCTIONS.

Cleaning and Storage:

It is recommended that the heater be cleaned at least one time during the operating season in order to provide the optimum level of performance.

ALWAYS TURN THE POWER SWITCH OFF AND UNPLUG THE HEATER BEFORE CLEANING.

Be sure to save the box for off-season storage.

• Turn the heater "OFF", unplug it and wait for the heater to cool down.
• Use a dry cloth to clean only external surfaces of the heater.
• Do not use any cleaning agents or detergents.
  • Never immerse the heater in water.
• Pack the heater in the original carton and store it in a cool and dry place.

Model No: NF15-17P

Voltage: 120V,60Hz

Current: Maximum continuous draw: 12.5Amps.

Output: 5200 BTUs

Power: LOW=750 Watts,HIGH=1500 Watts

Tolerances on all specifications: Approximately +5%, -10%

Environmental Protection

If the appliance should no longer work at all, please make sure that it is disposed of in an environmentally friendly way.

Contenido

[e-mail]

MODEL: NF15-17P

10/2017

YEAR WARRANTY

AÑOS DE GARANTÍA

Your details:

Name

Address

E mail

Date of purchase*

*We recommend you keep the receipt with this warranty card

Location of purchase

Description of malfunction:

Return your completed warranty card to:

Midea America Corporation

Customer Care Center

11411 NW 107th Street, Suite 12

Miami, FL

33178

USA

[e-mail]

AFTER SALES SUPPORT

54296

1-866-646-4332

[e-mail]

MODEL:

NF15-17P

10/2017

Hotline:

866-646-4332

Operating hours

Monday - Friday

8:00am - 5:00pm EST

YEAR WARRANTY

Sus datos:

Nombre

Dirección

Correo electrónico

Fecha de compra*

Customer Care Center

11411 NW 107th Street, Suite 12

Miami, FL

33178

USA

[e-mail]

SERVICIO POSVENTA

54296

1-866-646-4332

[e-mail]

MODEL:

NF15-17P

10/2017

Línea directa:

866-646-4332

Horario de atención

Lunes - Viernes

8:00am - 5:00pm EST

AÑOS DE GARANTÍA

ALDI INC. FULL WARRANTY CONDITIONS

Dear Customer:

The ALDI warranty is a full warranty offering you the following benefits:

Warranty period: 2 years* from date of purchase.

6 months for movable parts and consumables under normal and proper conditions of use (e.g. rechargeable batteries).

Costs: Free repair/exchange or refund.

No transport costs.

ADVICE:

Please contact our service hotline by phone, e-mail or fax before sending in the device. This allows us to provide support in the event of possible operator errors.

In order to make a claim under the warranty, please send us:

- The faulty item with all component parts, the original receipt and the warranty card properly completed.

The warranty does not cover damage caused by:

• Accident or unanticipated events (e.g. lightning, water, fire).
• Improper use or transport.
• Failure to follow the safety and maintenance instructions.
• Other improper treatment or modification of the product.

After the expiration of the warranty period, you may wish to have your product repaired at your own expense. You will be notified of the repair costs in advance.

This warranty gives you specific legal rights, and you may also have other rights which vary from state to state but this warranty is not intended to exceed statutory minimum requirements beyond what is included above.

This warranty does not limit the statutory obligation of the seller arising from any implied warranties. The period of warranty can only be extended in accordance with applicable law.

Neither the service company nor ALDI will assume any liability for data or settings stored on any returned product.
