| Product Type | Single lever kitchen faucet |
| Model | TC56CH |
| Brand | CDA |
| Dimensions (approx.) | Height: 400 mm, Spout reach: 220 mm |
| Weight | 2.5 kg |
| Material | Brass body with chrome finish |
| Cartridge Type | Ceramic disc cartridge |
| Operation | Single lever for flow and temperature control |
| Spout Type | Swivel spout with 360° rotation |
| Spray Function | Pull-out spray head with dual modes (stream/ spray) |
| Mounting Type | Deck mount, single hole, 35 mm hole diameter |
| Connection Size | 1/2" flexible hoses |
| Flow Rate | 6 L/min at 3 bar |
| Working Pressure Range | 1 to 5 bar |
| Max Temperature | 80°C |
| Finish | Chrome plated |
| Warranty | 5 years (subject to terms) |
| Included Accessories | Mounting hardware, flexible hoses, spray head |
| Standards | WaterMark compliant, suitable for mains pressure |
| Maintenance | Clean with a soft cloth and mild soap; do not use abrasive cleaners |
| Spare Parts | Available from CDA or authorized dealers (cartridge, spray head, hoses) |
Frequently Asked Questions - TC56CH CDA
How do I install the CDA TC56CH faucet?
Installation should be done by a qualified professional. The faucet mounts to a single hole with a 35 mm diameter. Connect the 1/2" flexible hoses to the water supply, ensuring the hot and cold connections are correct. Use the provided mounting hardware and follow the included instructions.
What is the recommended water pressure for this faucet?
The recommended working pressure is between 1 and 5 bar. If your water pressure is higher, a pressure reducing valve should be installed to prevent damage.
How do I clean and maintain the faucet?
Clean the faucet with a soft damp cloth and mild soap. Avoid abrasive or chemical cleaners that may damage the chrome finish. Periodically check the connections for leaks and clean the aerator if flow decreases.
Can I replace the cartridge myself?
Yes, the ceramic disc cartridge can be replaced. Turn off the water supply, unscrew the handle, and remove the retaining nut. Replace the cartridge with a genuine CDA spare part and reassemble. If unsure, contact a professional.
Does the faucet have a pull-out spray?
Yes, the TC56CH features a pull-out spray head with a dual-function mode: a steady stream for regular use and a spray for rinsing. The spray head retracts automatically via a weight on the hose.
What is the warranty on the faucet?
CDA offers a 5-year warranty on the TC56CH faucet, covering manufacturing defects. The warranty does not cover damage from improper installation, misuse, or normal wear and tear. Retain your purchase receipt.
The handle feels loose or stiff. How can I fix it?
A loose handle may be due to a loose set screw. Tighten it with an Allen key. Stiff operation often indicates a worn cartridge or debris; try cleaning or replacing the cartridge. If the problem persists, consult a plumber.
Is the faucet compatible with a water filter system?
Yes, the faucet can be connected to a water filter system via the flexible hoses. However, ensure the filter does not restrict flow significantly. If you need a dedicated filtered water faucet, CDA offers models with a side handle.
What tools are needed for installation?
You will need an adjustable wrench, basin wrench, screwdriver, thread seal tape (PTFE), and possibly a drill for mounting. Follow the instruction manual for torque specifications.
Where can I purchase spare parts?
Genuine CDA spare parts are available from authorized dealers, online retailers, or CDA's official website. Common parts include cartridges, spray heads, hoses, and aerators.
