| Product Type | 32-bit Microcontroller |
| Manufacturer | Microchip Technology |
| Model | PIC32MZ1024ECG064 |
| Core | MIPS32® microAptiv™ |
| Maximum CPU Speed | 200 MHz |
| Flash Memory | 1024 KB |
| SRAM | 512 KB |
| Package Type | 64-pin TQFP (10x10 mm) |
| Operating Voltage | 2.3V to 3.6V |
| Operating Temperature Range | -40°C to +85°C |
| Digital I/O Pins | 49 |
| Analog Peripherals | 2x 12-bit ADC (up to 24 channels), 2x Comparators |
| Communication Interfaces | 6x UART, 5x SPI, 5x I2C, 2x CAN, 1x Ethernet MAC |
| Timers | 9x 16-bit, 4x 32-bit |
| DMA Channels | 8 |
| Weight (typical) | 0.5 g |
| Power Consumption (typical) | 250 mA at 200 MHz active mode |
| Maintenance | No routine maintenance required; handle with ESD precautions |
| Safety | Use in low-voltage circuits; avoid reverse polarity and overvoltage |
| Spare Parts / Repairability | Not repairable; replace device if faulty; available through distributors |
Frequently Asked Questions - PIC32MZ1024ECG064 Microchip
What is the maximum clock frequency of the PIC32MZ1024ECG064?
How much flash memory does the PIC32MZ1024ECG064 have?
What is the operating voltage range of this microcontroller?
Does the PIC32MZ1024ECG064 have built-in Ethernet?
How many CAN modules are available?
What development tools support this microcontroller?
What is the package type and size?
How many analog-to-digital converter channels are there?
Is the PIC32MZ1024ECG064 compatible with 5V logic?
Where can I find the full datasheet and reference manual?
