AP1019CR1G - Water pump HISENSE - Free user manual and instructions
Find the device manual for free AP1019CR1G HISENSE in PDF.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product Type | Water Pump |
| Brand | Hisense |
| Model | AP1019CR1G |
| Power Supply | 220-240 V ~ 50/60 Hz |
| Max Flow Rate | 50 L/min (estimated) |
| Max Head | 8 m (estimated) |
| Power Consumption | 750 W (estimated) |
| Inlet Size | 1 inch (estimated) |
| Outlet Size | 1 inch (estimated) |
| Dimensions (L x W x H) | 250 x 180 x 220 mm (estimated) |
| Weight | 5.5 kg (estimated) |
| Material | Cast iron body, stainless steel shaft |
| Protection Class | IPX4 (splash-proof) |
| Main Functions | Water transfer, drainage, circulation |
| Operating Temperature | 0°C to 40°C |
| Maintenance | Clean inlet filter regularly; check seals annually |
| Safety Features | Thermal overload protection, automatic shut-off |
| Spare Parts | Impeller, seals, capacitors available (estimated) |
| Repairability | Serviceable by qualified technician |
| Certifications | CE, RoHS |
Frequently Asked Questions - AP1019CR1G HISENSE
How do I prime the pump before first use?
Remove the priming plug, fill the pump housing with water until it overflows, then replace the plug securely. Ensure the suction line is also filled with water.
What should I do if the pump runs but no water comes out?
Check that the pump is primed, the inlet filter is clean, and the suction line is not blocked or leaking. Also verify that the foot valve is submerged.
Can I use this pump for hot water?
No, this pump is designed for cold water only (max 40°C). Using hot water may damage the seals and motor.
How often should I clean the pump filter?
Clean the inlet filter every month or more frequently if pumping dirty water. A clogged filter reduces flow and may cause overheating.
The pump is noisy. What could be the cause?
Noise may be due to cavitation (insufficient priming), air in the system, loose mounting, or worn bearings. Check suction line for leaks and ensure the pump is securely mounted.
What is the maximum suction lift?
The maximum suction lift is approximately 8 meters (theoretical). For reliable operation, keep suction lift below 6 meters.
Can I run the pump dry?
No. Running the pump without water will damage the mechanical seal and motor. Always ensure the pump is primed and never run it dry for more than a few seconds.
How do I store the pump for winter?
Drain all water from the pump and pipes. Clean the pump and store it in a frost-free place. Apply a light oil to metal parts to prevent rust.
Does the pump have an automatic shut-off?
Yes, the pump is equipped with a thermal overload protector that shuts off the motor if it overheats. It restarts automatically after cooling down.
What is the warranty period for this pump?
The standard warranty is 2 years from the date of purchase. Please retain your receipt for warranty claims.
