| Product Type | In-ceiling speaker |
| Model | Visual Performance VP81R |
| Brand | Sonance |
| Driver Size | 8 inches |
| Cutout Diameter | 9.6 inches (244 mm) |
| Overall Diameter | 10.9 inches (277 mm) |
| Mounting Depth | 4.5 inches (114 mm) |
| Weight | 5.2 lbs (2.4 kg) |
| Power Handling (RMS) | 80 watts |
| Impedance | 8 ohms |
| Frequency Response | 40 Hz – 20 kHz |
| Sensitivity | 90 dB (1W/1m) |
| Mounting Type | Ceiling mount with dog-ear clamps |
| Grille Material | Perforated steel, paintable |
| Woofer Material | Polypropylene cone with rubber surround |
| Wiring | Spring-loaded terminals, accepts up to 14 AWG |
| Recommended Use | Stereo or home theater surround |
| Maintenance | Wipe with dry cloth; do not use liquids |
| Safety | Ensure secure mounting, avoid overload |
| Spare Parts | Grilles and mounting brackets available separately |
| Repairability | Driver replacement by qualified technician |
Frequently Asked Questions - Visual Performance VP81R SONANCE
How do I install the Sonance VP81R in an existing ceiling?
Use the included template to mark the cutout. Cut the hole with a drywall saw. Insert the speaker, tighten the dog-ear clamps by turning the screws clockwise. Connect speaker wire to the spring terminals before mounting.
Can I paint the grille to match my ceiling?
Yes, the grille is paintable. Remove the grille, apply thin coats of spray paint, and reattach after drying. Do not paint the driver cone.
What gauge speaker wire should I use?
We recommend 16 to 14 AWG wire for runs up to 50 feet. For longer runs, use 12 AWG to minimize signal loss.
Are these speakers suitable for outdoor covered areas?
The VP81R is designed for indoor use only. Exposure to moisture or extreme temperatures may damage the speaker.
How do I clean the speaker grille?
Vacuum the grille gently with a brush attachment. If needed, wipe with a barely damp cloth. Avoid getting moisture on the driver.
What is the impedance of the VP81R?
The speaker has an impedance of 8 ohms. It can be used with any amplifier rated for 8-ohm loads.
Can I use the VP81R as a center channel speaker?
Yes, the VP81R works well as a center, left, right, or surround speaker in a home theater system.
What is the power handling of this speaker?
The continuous power handling is 80 watts RMS, and peak power is 120 watts. Amplifier output should not exceed these ratings to avoid damage.
Does the speaker come with a mounting template?
Yes, a cardboard mounting template is included in the box for accurate cutout marking.
Can I use the VP81R speakers with an existing volume control?
Yes, they can be wired to an in-wall volume control. Ensure the volume control is rated for 8-ohm speakers and the total load does not exceed the amplifier's capability.
