Product Type	Pivot Arm with Adjustable Wheel Lock Control
Brand	Impact
Model	BHE-115
Extended Length	20 in (50.8 cm)
Folded Length	10 in (25.4 cm)
Weight	2 lb (0.91 kg)
Maximum Load Capacity	8 lb (3.6 kg)
Construction Material	Aluminum alloy
Attachment Options	5/8" (16 mm) stud with 1/4"-20 female thread; 5/8" (16 mm) stud with 3/8" female thread
Joint Type	Rotary pivot joint with 360° rotation
Adjustable Tension	Yes, via adjustable wheel lock control
Compatible with Super Clamps	Yes, via baby 5/8" receivers
Threaded Baby Pins	Two, with ball-and-socket joints; one 1/4"-20 female, one 3/8" female
Usage	Mounting cameras, lighting gear, or brackets
Cleaning Instructions	Wipe with a soft, dry cloth
Safety Precautions	Keep away from children; do not exceed max load; ensure secure attachment before use
Warranty	One-year limited warranty from date of purchase
Warranty Provider	Gradus Group (via Impact Customer Service)

Frequently Asked Questions - BHE-115 Impact

How does the adjustable wheel lock control work?

The adjustable wheel lock control varies the tension of the internal locking mechanism. Loosen it for micro-adjustments of the pivot arms and baby pins, then tighten to lock them in place.

What is the maximum load capacity?

The maximum load capacity is 8 lb (3.6 kg). Do not exceed this weight to avoid damage or injury.

What attachments are compatible?

The pivot arm features two baby pins: one with 1/4"-20 female thread and one with 3/8" female thread. It also has 5/8" studs for use with super clamps and baby receivers.

Can I use this arm with a super clamp?

Yes, the flat-sided baby pins are designed to fit into baby 5/8" receivers on super clamps and other mounting gear.

How do I clean the pivot arm?

Clean the unit with a soft, dry cloth. Do not use liquids or abrasive cleaners.

Is the pivot arm adjustable for different angles?

Yes, the rotary pivot joint rotates 360° for all-around positioning, and the ball-and-socket baby pins allow flexible movement and accurate positioning.

What is the warranty coverage?

The product comes with a one-year limited warranty against defects in materials and workmanship. It covers repair or replacement at the provider's discretion.

How do I obtain warranty service?

Contact Impact Customer Service at 212-594-2353 or visit www.impactstudiolighting.com to obtain an RMA number. Return the defective product with proof of purchase.

What is the folded length of the arm?

The folded length is 10 inches (25.4 cm), making it compact for storage and transport.

Is this product suitable for heavy studio lights?

It supports up to 8 lb (3.6 kg), so it can handle many compact studio lights and cameras. Always verify the weight of your gear before mounting.

USER MANUAL BHE-115 Impact

Two Impact PivotArm tools against a solid yellow background (no text or symbols on the devices themselves)

Pivot Arm 20" Adjustable

Wheel Lock Control

INSTRUCTIONS

Introduction

Thank you for choosing Impact.

The Impact Pivot Arm 20" with Adjustable Wheel Lock Control is a strong mounting arm with an elbow pivot joint that securely attaches cameras, lighting gear, or brackets while being attached to any baby receiver adapter or super clamp. The adjustable wheel lock control varies the tension of the internal locking mechanism so small adjustments can be made without moving other parts of the unit. Also, by twisting the adjustable wheel lock control fully, it locks the pivot arms and baby pins in place.

Two female threaded baby pins enable the connection to a variety of devices with one having a 1/4"-20 thread and the other a 3/8" thread while both offering the ability to attach the arms to super clamps or other mounting gear with baby 5/8" receivers. Whether in a space where conventional tripods cannot be used or needing a unique angle, this 360° pivot arm with ball and socket positioning baby pins is a great addition to your grip kit.

Overview

1 Adjustable wheel lock control

Internally locks pivot arms and baby pins in position. If you need to adjust the position of the pivot arms or baby pins for optimal placement, loosen the adjustable wheel lock control just enough to make micro adjustments. When you have the correct position of the unit and your gear, tighten by twisting the adjustable wheel lock control and lock the pivot arm and baby pins in place.

2 Rotary pivot joint

Rotates 360^ for all-around positioning.

Solid yellow gradient background with no text, symbols, or discernible features

Close-up of a black mechanical pipe fitting with a yellow numbered component (3) attached to the end, no visible text or symbols on the main body.

3 Threaded Baby Pins

Each baby pin is affixed to a ball and socket, allowing for flexible movement and accurate positioning of the gear attached.

Connect many types of lighting and camera equipment with 1/4"-20 or 3/8" female threads.

Ideal for use with super clamps.

Flat-sided baby pins help to prevent the pivot arms from rotating in any baby receiver.

Specifications

Construction: Aluminum alloy

Extended length: 20" (50.8 cm)

Folded length: 10" (25.4 cm)

Weight: 2 lb. (.91 kg)

Maximum load capacity: 8 lb. (3.6 kg)

Attachment: 5/8" (16 mm) stud with 1/4"-20 female thread

5/8" (16 mm) stud with 3/8" female thread

Precautions ⚠️

• Please read and follow these instructions, and keep this manual in a safe place.
• Handle the unit with care.
• Clean the unit with a soft, dry cloth.
• Keep this unit away from children.
  • Make sure everything is secure before proceeding.
  • Make sure the item is intact and that there are no missing parts.
• Do not exceed the maximum load capacity.
  • All photos are for illustrative purposes only.

One-Year Limited Warranty

This IMPACT product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later. The warranty provider's responsibility with respect to this limited warranty shall be limited solely to repair or replacement, at the provider's discretion, of any product that fails during normal use of this product in its intended manner and in its intended environment. Inoperability of the product or part(s) shall be determined by the warranty provider. If the product has been discontinued, the warranty provider reserves the right to replace it with a model of equivalent quality and function.

This warranty does not cover damage or defect caused by misuse, neglect, accident, alteration, abuse, improper installation or maintenance. EXCEPT AS PROVIDED HEREIN, THE WARRANTY PROVIDER MAKES NEITHER ANY EXPRESS WARRANTIES NOR ANY IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. This warranty provides you with specific legal rights, and you may also have additional rights that vary from state to state.

To obtain warranty coverage, contact the Impact Customer Service Department to obtain a return merchandise authorization ("RMA") number, and return the defective product to Impact along with the RMA number and proof of purchase. Shipment of the defective product is at the purchaser's own risk and expense.

For more information or to arrange service,

visit www.impactstudiolighting.com

or call Customer Service at 212-594-2353.

IMPACT™

A Gradus Group Brand

Product warranty provided by the Gradus Group.

www.gradusgroup.com

IMPACT is a registered trademark of the Gradus Group.

© 2015 Gradus Group LLC. All Rights Reserved.
