SubSeries 100 - Subwoofer PSB - Free user manual and instructions

Product Type	Powered Subwoofer
Driver Size	10 inches (254 mm)
Amplifier Power	200 Watts RMS
Frequency Response	25 Hz - 150 Hz
Low-Pass Crossover	50-150 Hz variable
Phase Control	0/180 degrees switchable
Inputs	Line-level RCA (L/R), LFE input
Outputs	Line-level RCA passthrough
Auto Power On/Off	Signal sensing (auto standby)
Enclosure Type	Bass reflex with front-firing port
Dimensions (H x W x D)	15.2 x 12.6 x 14.2 in (386 x 320 x 360 mm)
Weight	25.8 lbs (11.7 kg)
Power Supply	AC 120V/60Hz (US) or 230V/50Hz (EU) – internal
Power Consumption	250 W (max), <0.5 W standby
Safety Features	Overload protection, thermal shutdown
Cleaning Instructions	Wipe with dry cloth; avoid liquids and abrasives
Spare Parts / Repairability	Amplifier module and driver available; service by qualified personnel
Warranty	2 years (varies by region)

Frequently Asked Questions - SubSeries 100 PSB

How do I connect the subwoofer to my AV receiver?

Use an RCA cable to connect the receiver's subwoofer pre-out to the LFE or left/right input on the subwoofer. Ensure the receiver's bass management is set to send low frequencies to the subwoofer.

What is the best placement for the subwoofer?

Place the subwoofer in a corner or along a wall for maximum bass reinforcement. Avoid placing it in the center of the room. Experiment with position to reduce standing waves and achieve even bass response.

How do I set the crossover frequency?

Set the low-pass crossover to around 80 Hz if using with typical bookshelf or tower speakers. Adjust based on your main speakers' low-frequency capability and personal preference.

Why is my subwoofer not turning on?

Check that the power cord is firmly connected and the outlet is live. Ensure the auto on/off switch is set to 'Auto' or 'On'. The subwoofer may enter standby if no signal is detected; try playing content with low frequencies.

Can I use both RCA inputs at the same time?

Yes, you can use both left and right inputs for a summed mono signal. If using a single LFE cable, connect it to the left input (usually marked LFE).

What does the phase switch do?

The phase switch (0/180°) adjusts the timing of the subwoofer's output relative to the main speakers. Try both positions and listen for which gives fuller, more integrated bass.

How often should I clean the subwoofer?

Dust the cabinet and grille every few months with a soft, dry cloth. Do not use any liquids or cleaning agents, as they may damage the finish or electronics.

The subwoofer makes a hum or buzzing noise

A ground loop may cause hum. Try connecting all audio components to the same power strip. If hum persists, use a ground loop isolator on the RCA cable.

What size room is this subwoofer suitable for?

The PSB SubSeries 100 is ideal for small to medium-sized rooms up to about 2,000 cubic feet (56 m³). It delivers tight, articulate bass without overwhelming the space.

Can I repair the subwoofer myself?

Only basic tasks like replacing fuses or checking cables should be done by the user. For amplifier or driver issues, contact PSB certified service center to avoid damage and maintain safety.

USER MANUAL SubSeries 100 PSB

1.

1.

For additional support with your subwoofer, please visit the PSB Lounge at www.psbspeakers.com/lounge Pour du soutien additionnel au sujet de votre calisson de graves, visitez le salon PSB au www.psbspeakers.com/lounge Si desea más ayuda para su subwoofer, visite el PSB Lounge en el sitio www.psbspeakers.com/lounge. Weitere Unterstützung zu unserem Subwoofer erhalten Sie in der PSB Lounge unter www.psbspeakers.com/lounge Nel caso accorresse un'assistenza ulteriore con il subwoofer, visitare il sito PSB Lounge all'indirizzo www.psbspeakers.com/lounge

Important Safety Instructions

1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.

12) Use only with the cart, stand, tripod, bracket,

or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or when unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
15) The equipment shall be used at maximum 35 degree C ambient temperature.
16) Do not open the equipment to reduce the risk of electrical shock. For safety reasons it is only allow to the opened by qualified service personnel.
17) WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. And the apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.
18) The MAINS plug is used as the disconnect device and shall remain readily operable.
19) The product shall be used on open bench.

	The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
	The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
