Product Type	Two Door Refrigerator-Freezer
Brand	Magic Chef
Model	HVDR430ST (also HVDR430WE/BE/SE)
Total Capacity	4.3 Cu. Ft.
Dimensions (Width x Height x Depth)	19.1" x 43.4" x 20.7"
Net Weight	68.8 lbs
Power Requirements	115/120 V AC, 60 Hz
Grounding	3-prong grounded plug; do not use extension cord
Refrigerant	R600a (flammable)
Temperature Control	Dial from 0 (off) to 7 (coldest); recommended setting 4
Defrost Method	Manual; defrost when frost reaches 1/4 inch thick or every 3 months
Door Reversible	Yes; can be opened from left or right side
Interior Light	Yes; replaceable bulb in thermostat box
Shelves	Steel shelf in refrigerator; wire shelf in freezer
Crisper	Yes
Ice Tray	Included; ice cube tray and shovel
Installation Type	Freestanding only; allow 5" clearance on sides and back
Operating Ambient Temperature Range	50°F to 85°F (10°C to 29.4°C)
Warranty	1 year parts and labor; 5 years compressor (parts only)
Safety Features	Child entrapment prevention; flammable refrigerant warning; grounded plug
Cleaning Recommendation	Use mild detergent and warm water; baking soda solution for interior
User Maintenance	Unplug before cleaning; do not use mechanical defrosting devices
Compliance	Household use only; not for RV or use with inverter

Frequently Asked Questions - HVDR430ST Magic Chef

What should I do if my Magic Chef HVDR430ST refrigerator is not operating?

Check if the unit is plugged in and the circuit breaker or fuse is not tripped/blown. Ensure the temperature control dial is not set to '0'. Allow 4 hours after plugging in for the refrigerator to cool completely.

Why does the compressor turn on and off frequently?

Possible causes include: room temperature too hot, large amount of food added, door opened too often or not closed completely, temperature control set incorrectly, door gasket not sealing, insufficient clearances, or recent disconnection. Allow 4 hours for stabilization.

How do I adjust the temperature on my refrigerator?

Turn the temperature control dial located inside the refrigerator compartment. Settings range from '1' (warmest) to '7' (coldest). Recommended setting is '4'. Adjust one increment at a time and allow several hours for temperature to stabilize.

How can I prevent moisture from forming inside the refrigerator?

Moisture can occur in humid weather or if the door is open too long, not closed properly, or the gasket is dirty. Minimize door openings, ensure the door seals completely, and clean the gasket. This is often normal in humid conditions.

Why is my refrigerator making popping or gurgling sounds?

Popping sounds are normal due to metal expansion/contraction. Gurgling or bubbling sounds are from refrigerant circulating. These are normal operating noises and should diminish over time.

How do I defrost the freezer compartment?

Set the thermostat to '0' to defrost. Remove all food and leave the freezer door open. Do not use hot water or heating devices. Once ice melts, wipe dry. Defrost when frost is about 1/4 inch thick or every 3 months.

Can I reverse the door opening direction?

Yes, the door is reversible. Follow the instructions in the manual: remove hinges, transfer stoppers and hinges to the opposite side, and reassemble. Have someone assist you during the process for safety.

What should I do if the door does not close properly?

Check if the refrigerator is level (adjust leveling legs). Ensure the door gasket is clean and not obstructed. If the unit rocks, level it with shims. The refrigerator must have proper clearance from walls.

How do I clean my refrigerator?

Unplug the unit and remove all food. Wash the interior with a solution of 2 tablespoons baking soda per quart of warm water. Use mild detergent for the exterior. Dry thoroughly. Clean door gasket to maintain efficiency.

What is the warranty coverage for the HVDR430ST?

MC Appliance warrants one year parts and labor from date of purchase. Compressor is covered for five years (parts only). Labor and transportation after the first year are the consumer's responsibility. Proof of purchase is required.

USER MANUAL HVDR430ST Magic Chef

4.3 Cu. Ft.

Two Door Refrigerator

User's Manual

Line drawing of a double refrigerator with front panel and side legs (no text or symbols)

Model HVDR430WE / HVDR430BE / HVDR430SE / HVDR430ST PLEASE READ THIS MANUAL CAREFULLY BEFORE USING YOUR REFRIGERATOR AND KEEP IT FOR FUTURE REFERENCE.

Product Registration

Thank you for purchasing a Magic Chef® product. The first step to protect your new product is to complete the product registration on our website: www.mcappliance.com/register. The benefits of registering your product include the following:

1. Registering your product will allow us to contact you regarding a safety notification or product update.
2. Registering your product will allow for more efficient warranty service processing when warranty service is required.
3. Registering your product could act as your proof of purchase in the event of insurance loss.

Once again, thank you for purchasing a Magic Chef® product.

TABLE OF CONTENTS

NAMES OF THE PARTS.... 3

SPECIFICATIONS.... 3

IMPORTANT SAFETY INSTRUCTIONS.... 4

INSTALLATION INSTRUCTION

TROUBLESHOOTING GUIDE....11 - 12

REFRIGERATOR WARRANTY.... 13

MODEL NO. HVDR430WE/HVDR430BE/HVDR430SE/HVDR430ST

(1) Cabinet Tabletop
(2) Door, Freezer Section
(3) Temperature Control Box
(4) Interior Light Switch
(5) Shelf, Refrigerator Section
(6) Door, Refrigerator Section
(7) Crisper
(8) Leveling Leg
(9) steel shelf
(10) Ice Tray
(11) Ice shovel

WARNING: Never touch the interior of the Freezer Chamber or frozen foods in the compartment with wet hands as this could result in frost bite.

SPECIFICATIONS –Model # HVDR430WE/HVDR430BE/HVDR430SE/ HVDR430ST

Product Description	Magic Chef 2 Door Refrigerator
Model No.	HVDR430WE/HVDR430BE/HVDR430SE/HVDR430ST
Capacity	4.3 Cu. Ft.
Unit Dimensions (inches)	Width	Height	Depth
	19.1"	43.4"	20.7"
Net Weight (lbs)	68.8 (lbs)

IMPORTANT SAFETY INSTRUCTIONS

WARNING

To reduce the risk of fire, electrical shock, or injury follow these basic precautions when using your refrigerator.

1) WARNING----Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.
2) WARNING----Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.
3) WARNING----Do not damage the refrigerant tubing to increase the risk of a leak when handle, move and use of refrigerator.
4) WARNING----Do not use electrical appliances inside the food storage compartments of the appliances, unless they are of the type recommended by the manufacturer.

5) WARNING----DANGER: Never allow children to play with, operate, or crawl inside the refrigerator. Risk of child entrapment. Before you throw away your old refrigerator or freezer:

• Take off the doors
- Leave the shelves in place so that children may not easily climb inside.

6) The appliance has to be unplugged before carrying out user maintenance on the appliance.

7) This appliance can be used by children age 8 years and above and persons with reduced physical sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children should not play with the appliance. Cleaning and maintenance should not be made by children without supervision.

8) If the component part is damaged, it must be replaced by the manufacturer, its service agent or similar qualified persons in order to avoid a hazard.

9) Please abandon the refrigerator according to local regulations as the unit contains flammable blowing gas and refrigerant.

10) Follow local regulations regarding disposal of the appliance due to flammable refrigerant and blowing gas. All refrigeration products contain refrigerants, which under the guidelines of federal law must be removed before disposal. It is the consumer's responsibility to comply with federal and local regulations when disposing of this product.

11) This appliance is intended to be used in household and similar environments; such as:

• staff kitchen areas in shops, offices and other working environments;
farm houses and by clients in hotels, motels and other residential type environments;
• bed and breakfast type environments;
• catering and similar non-retail applications.

12) Do not store or use gasoline or any inflammable liquors and liquids inside or in the vicinity of refrigerator.

13) Do not use an extension cord with this appliance. If the power cord is too short, have a qualified electrician install an outlet near the appliance. Use of an extension can negatively affect the unit's performance.

IMPORTANT SAFETY INSTRUCTIONS

WARNING

To reduce the risk of fire, electrical shock, or injury when using your refrigerator, follow these basic precautions:

Read all instructions before using the refrigerator.DANGER or WARNING:Risk of child entrapment.To avoid the possibility of child entrapment, please take the following precautions before throwing out the refrigerator.Remove all doors from the unit.Leave the shelves in place so that children may not easily climb inside.Never allow children to operate, play with, or crawl inside the refrigerator.Refrigerants: All refrigeration products contain refrigerants, which under the guidelines of federal law must be removed before disposal of product. It is the consumer's responsibility to comply with federal and local regulations when disposing of this product.Never clean refrigerator parts with flammable fluids. The fumes can create a fire hazard or explosion.Do not store or use gasoline or any other flammable vapors and liquids in the vicinity of this or any other refrigerator. The fumes can create a fire hazard or an explosion.-Save these instructions-

INSTALLATION INSTRUCTIONS

Before Using Your Refrigerator

• Remove the exterior and interior packing.
• Before connecting the refrigerator to the power source, let it stand upright for approximately 4 hours. This will reduce the possibility of a malfunction in the cooling system from improper handling during transportation.
• Clean the interior surface with lukewarm water using a soft cloth. (Cleaning instruction on page10)

Installing Your Refrigerator

• This appliance is designed to be free standing only, and should not be recessed or built-in.
- Place your refrigerator on a floor that is strong enough to support the refrigerator when it is fully loaded.
- Allow 5 inches of space between the back and sides of the refrigerator, which allows the proper air ventilation. Adjust the feet to keep the refrigerator level.
- Locate the refrigerator away from direct sunlight and sources of heat (stove, heater, radiator, etc.). Direct sunlight may affect the acrylic coating and heat sources may increase electrical consumption. Ambient temperature below 50^ F ( 10^ C) or above 85^ F ( 29.4^ C) will hinder the performance of this appliance. This unit is not designed for use in a garage or any other outside installation.
- Avoid locating the refrigerator in moist areas.
- Plug the refrigerator into dedicated, properly installed-grounded wall outlet. Do not under any circumstances cut or remove the third (ground) prong from the power cord. Any questions concerning power and/or grounding should be directed toward a certified electrician or an authorized service center. This unit is not designed to be installed in an RV or used with an inverter.
- After plugging the appliance into a wall outlet, turn the unit on and allow the unit to cool down for 2\~3 hours under before placing food in the refrigerator or freezer compartment.

WARNING

Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is damaged, have it replaced by an authorized service center.

This refrigerator should be properly grounded for your safety. The power cord of this refrigerator is equipped with a three-prong plug which mates with standard three prong wall outlets to minimize the possibility of electrical shock.

Do not, under any circumstances, cut or remove the third ground prong from the power cord supplied.

This refrigerator requires a standard 115/120 Volt A.C. \~/60Hz electrical outlet with three-prong ground.

This refrigerator is not designed to be used with an inverter.

The cord should be secured behind the refrigerator and not left exposed or dangling to prevent accidental injury.

Never unplug the refrigerator by pulling the power cord. Always grip the plug firmly and pull straight out from the receptacle.

Do not use an extension cord with this appliance. If the power cord is too short, have a qualified electrician or service technician install an outlet near the appliance. Use of an extension cord can negatively affect the performance of the unit.

If any problems with the appliance persist, please contact our Customer Service Dept. to consult with a representative at 888 775-0202 or visit our website to request warranty service at www.mcappliance.com.

• Your refrigerator has one control for regulating the temperature. The temperature control is located on the top center of the refrigerator compartment.
• The first time you turn the unit on, adjust the temperature control knob to "7" and run for at least 2 hours before putting foods inside. This will ensure the cabinet is thoroughly chilled before food is put in.
• The range of the refrigerator temperature control is from position "1" the warmest to "7" the coldest. Adjust the temperature control to the setting that best suits your needs. The setting of "4" should be appropriate for home or office refrigerator use.

• Turning the temperature control knob to "0" position stops the cooling cycle but does not shut off the power to the unit.
  NOTE;

• If the unit is unplugged, loses power; you must wait 3 to 5 minutes before restarting the unit. If you attempt to restart before this time delay, the refrigerator will not start.
  • Large amounts of food will lower the cooling efficiency of the appliance.

• Do not place the foods on the air outlet, and leave spaces for airflow.
• If you choose to change the thermostat setting, adjust thermostat control by one increment at a time. Allow several hours for temperature to stabilize between adjustments.

Ice Tray

• Recommended temperature control setting for ice making is "7".
• Fill the ice cube tray (2/3 capacity) with cold water and place the tray or the bottom of the chiller compartment to freeze properly.
• To eject the ice cubes from the tray, place over the ice bucket and twist slightly.
• Re-set the temperature control to setting "4".

Illustration of three hand gestures: a tray with a mouse, a roller with curved arrows indicating rotation, and a hand holding a container with a crossed-out tool (no text or symbols)

The Freezer Compartment

• This compartment is designed for the long-term storage of frozen food.
- The storage life of frozen foods varies and the recommended storage time should not be exceeded.
- Place frozen food into the freezer as quickly as possible after purchase. If there are instructions on the packet, carefully follow these instructions regarding storage times.

When To Defrost

This unit is not designed to defrost automatically. In order to prevent damage to the interior liner of the unit from excessive frost build-up, please manually defrost the unit every 3 month or when ice / frost is approximately 1/4 " thick inside the freezer compartment.

How To Defrost

Defrost the freezer compartment when the ice / frost are approximately 14 " thick or every 3 months, whichever comes first. Set the thermostat dial to "0" to defrost. Remove all contents from the freezer compartment. Leave the freezer door open to allow accumulated ice / frost to melt. Remove large pieces of ice as needed. Do not use hot water or other electric heating devices to melt the accumulated ice. After defrosting, remove accumulated ice / water and wipe the freezer compartment dry with a soft cloth. In the event that the ice is not visibly present in the freezer compartment, please allow the evaporator located behind the freezer wall to completely defrost for approximately 2 hours before restarting the unit. Restart the unit per starting instructions.

How To Change the interior light

NOTE: All parts removed must be saved to do the reinstallation of the light bulb. Before removing the light bulb, unplug the appliance from the power supply. Failure to do so could result in electrical shock or personal injury.

1. Remove the lamp cover by unscrewing.
2. Unscrew old bulb from the lower hole at the thermostat control box.
3. Replace the new bulb of the same voltage and screw size.
4. Re-install the lamp cover by screwing.

CHANGING THE REVERSIBLE DOOR

CAUTION: To avoid personal injury to yourself and/or property, we recommend someone assist you during the door reversal process.

Your refrigerator is built with a reversible door. You have the choice of either opening it from the left or the right side. In order to reserve the opening direction of your door, please follow these simple instructions:

1) Disassemble all the reversible components in the sequence as shown below (also refer to left diagram above). Be sure to keep them well for later use in the process of reassembling.

(1) leveling leg II (10) door, freezer section
(2) bottom hinge (11) top hinge
(3) leveling leg I
(4) bottom door baffle block (13) Tabletop
(5) 2 screws to hold bottom hinge
(6) door, refrigerator section
(7) mid hinge
(8) 2 screws to hold mid hinge
(9) upper door right stopper

(12) 2 screws to hold top hinge
(14) 2 screws on cabinet rear to hold tabletop
(15) 2 screws to hold tabletop
(16) 2 decorative plugs on tabletop
(17) upper door left stopper

2) To access the bottom hinge assembly, you may tilt back the refrigerator cabinet or lay the refrigerator on its back.
3) Remove the upper door right stopper (9), install the upper door left stopper (17) on the opposite side; take down the bottom door baffle block (4), and install it on the opposite side.
4) Reassemble the unit with the door hinges on the opposite side (see the right diagram above). The sequence for reassembling is just in reverse order of disassembling.
5) With the mid hinge not being fastened too tight, align two doors properly on the cabinet and then fasten the mid hinge. If necessary, loosen the bottom hinge and the top hinge when aligning and then fasten them tight.

CARE AND MAINTENANCE

Cleaning Your Refrigerator

• Upon installation of your new appliance, it is recommended that it be cleaned thoroughly.
• Turn off the refrigerator first and then unplug the unit from the wall outlet.
• Remove all food content.
• Wash the inside with a damp warm cloth soaked in lukewarm water and baking soda solution.
  The solution should be about 2 tablespoons of baking soda to a quart of water.
• Be sure to keep the door gasket (seal) clean to keep the unit running efficiently.
• The outside of the refrigerator should be cleaned with mild detergent and warm water.
  • Dry the interior and exterior with a soft cloth.

Vacation Time

• Turn off the refrigerator first and then unplug the unit from the wall outlet.
• Remove all the food.
• Clean the refrigerator.
• Leave the door open slightly to avoid possible formation of condensation, mold, or odor.
• Use extreme caution in the case of children. The unit should not be accessible to child's play.
• Short vacations: Leave the refrigerator operating during vacations of less than three weeks.
• Long vacations: If the appliance will not be used for several months, remove all food and unplug the power cord. Clean and dry the interior thoroughly. To prevent odor and mold growth, leave the door open slightly: blocking it open if necessary or have the door removed.

Moving Your Refrigerator

• Turn off the refrigerator first and then unplug the unit from the wall outlet.
- Remove all the food.
- Securely tape down all loose items inside your refrigerator.
- Tape the doors shut.
- Be sure the refrigerator stays in the upright position during transportation.

Energy Saving Tips

• The refrigerator should be located in the coolest area of the room, away from heat producing appliances or heating ducts, and out of the direct sunlight.
• Let hot foods cool to room temperature before placing in the refrigerator. Overloading the refrigerator forces the compressor to run longer. Foods that freeze too slowly may lose quality, or spoil.
• Be sure to wrap foods properly, and wipe containers dry before placing them in the refrigerator. This cuts down on frost build-up inside the refrigerator.
• Organize and label food to reduce door openings and extended searches. Remove as many items as needed at one time, and close the door as soon as possible.

TROUBLESHOOTING GUIDE

You can solve many common refrigerator problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling for service.

PROBLEM	POSSIBLE CAUSE
Refrigerator does not operate.	Not plugged in.The circuit breaker tripped or a blown fuse.
Compressor turns on and off frequently.	The room temperature is hotter than normal.A large amount of food has been added to the refrigerator.The door is opened too often.The door is not closed completely.The temperature control is not set correctly.The door gasket does not seal properly.The refrigerator does not have the correct clearances.The refrigerator has recently been disconnected for a period of time. 4 hours are required for the refrigerator to cool down completely.
Temperature inside the refrigerator is too warm.	Temperature control is set too warm. Turn the control to a cooler setting and allow several hours for the temperature to stabilize.Door is kept open too long or is opened too frequently. Warm air enters the refrigerator every time the door is opened. Open the door less often.The door is not closed completely.The door gasket does not seal properly.A large amount of warm or hot food might have been stored recently. Wait until the refrigerator has had a chance to reach its selected temperature.The refrigerator has recently been disconnected for a period of time. 4 hours are required for the refrigerator to cool down completely.
Temperature inside the refrigerator is too cold.	Temperature control is set too cold. Turn the control to a warmer setting and allow several hours for the temperature to stabilize.
Temperature of external refrigerator surface is warm.	The exterior refrigerator walls can be as much as 30^ F warmer than room temperature. This is normal while the compressor works to transfer heat from inside the refrigerator cabinet.
Popping or cracking sound when compressor comes on.	Metal parts undergo expansion and contraction, as in hot water pipes. This is normal. Sound will level off or disappear as refrigerator continues to run.
Bubbling or gurgling sound, like water boiling.	Refrigerant (used to cool refrigerator) is circulating throughout the system. This is normal.
Vibrations.	Check to assure that the refrigerator is on a level surface.Floor is uneven or weak. Refrigerator rocks on the floor when it is moved slightly. Be sure floor can adequately support refrigerator. Level therefrigerator by putting wood or metal shims under part of the refrigerator.The refrigerator is touching the wall. Re-level the refrigerator and move it from the wall.See “Installation Instructions”.
Moisture forms on inside refrigerator walls.	Weather is hot and humid, which increases internal rate of frost build-up. This is normal. Door is slightly open. Door is kept open too long, or is opened too frequently. Open the door less often. The door is not sealed properly.
Moisture forms on outside of refrigerator.	Door is slightly open, causing cold air from inside the refrigerator to meet warm moist air from outside.
The door will not close properly.	The refrigerator is not on a level surface. The gasket is dirty.

Limited Warranty

MC Appliance Corporation warrants each new Compact Refrigerator to be free from defects in material and workmanship, and agrees to remedy any such defect or to furnish a new part(s), at the company's option, for any part(s) of the unit that has failed during the warranty period. Parts and labor expenses are covered on this unit for a period of one year from the date of purchase. A copy of the dated sales receipt or invoice is required to receive warranty service, replacement or refund.

In addition, MC Appliance Corporation warrants the compressor (parts only) to be free from defects in material and workmanship for a period of five years. The consumer is responsible for all labor and transportation expenses related to the diagnosis and replacement of the compressor after the initial one-year warranty expires. In the event the unit requires replacement or refund under the terms of this warranty, the consumer is responsible for all transportation expenses to return the unit to our factory prior to receiving a replacement unit or refund. A copy of the dated sales receipt/invoice is required to receive warranty service, replacement or refund.

This warranty covers appliances in use within the contiguous United States, Alaska, Hawaii and Puerto Rico. This warranty does not cover the following:

• Damages due to shipping damage or improper installation.
  • Damages due to misuse or abuse.
• Content losses due to failure of the unit.
• Inside components such as door panels, door shelves, racks, light bulbs, etc.
  • Repairs performed by unauthorized service agents.
  • Service calls that do not involve defects in material and workmanship such as instructions on proper use of the product or improper installation.
• Replacement or resetting of house fuses or circuit breakers.
• Failure of this product if used for other purposes than its intended purpose.
• Disposal costs for any failed unit not returned to our factory.
  • Any delivery/installation costs incurred as the result of a unit that fails to perform as specified.
• Expenses for travel and transportation for product service if your appliance is located in a remote area where service by an authorized service technician is not available.
• The removal and reinstallation of your appliance if it is installed in an inaccessible location or is not installed in accordance with published installation instructions.
  • Refunds for non repairable products are limited to the price paid for the unit per the sales receipt.
  • This warranty is non transferable. This warranty applies only to the original purchaser and does not extend to any subsequent owner(s).

Limitations of Remedies and Exclusions:

Product repair in accordance with the terms herein, is your sole and exclusive remedy under this limited warranty. Any and all implied warranties including merchantability and fitness for a particular purpose are hereby limited to one year or the shortest period allowed by law. MC Appliance Corporation is not liable for incidental or consequential damages and no representative or person is authorized to assume for us any other liability in connection with the sale of this product. Under no circumstances is the consumer permitted to return this unit to the factory without the prior written consent of MC Appliance Corporation.

Some states prohibit the exclusion or limitation of incidental or consequential damages, or limitations on implied warranties. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.

Model Parts & Labor Compressor (Parts Only) Type of Service

HVDR430WE	One Year Carry In	Five Years
HVDR430BE	One Year Carry In	Five Years
HVDR430SE	One Year	Five Years	Carry In
HVDR430ST	One Year Carry In	Five Years

For Service or Assistance please call 888-775-0202 or visit us on the web at www.mcappliance.com to request warranty service or order parts.

CNA International, Inc. d/b/a MC Appliance Corporation. All rights reserved. Magic Chef® is a registered trademark of CNA International, Inc.

www.mcappliance.com Printed in China

Line drawing of a double refrigerator with top panel and side door (no text or symbols)

Modelo HVDR430WE / HVDR430BE / HVDR430SE / HVDR430ST LEA ESTE MANUAL ANTES DE UTILIZAR SU REFRIGERADOR Y GUÁRDELO PARA FUTURA REFERENCIA.

Line drawing of a handheld device with control knobs and a handle (no text or symbols)

• NOTA;
