| Product Type | Turntable cartridge headshell |
| Brand | Audio-Technica |
| Model | AT-HS1 |
| Mounting Standard | Universal half-inch (1/2") |
| Compatible Cartridges | 4-pin turntable cartridges |
| Material | Aluminum alloy |
| Color | Black |
| Weight | Approximately 9.5 g |
| Overall Length | 52 mm |
| Mounting Hole Spacing | Half-inch (12.7 mm) centers |
| Lead Wires | Included, color-coded |
| Overhang Adjustment | Slot holes for alignment |
| Finger Lift | Integrated plastic finger lift |
| Connector Type | Standard 4-pin (1/2" center) |
| Pins | Gold-plated for corrosion resistance |
| Package Contents | 1 headshell, 4 lead wires, 2 mounting screws, 1 screwdriver |
| Country of Origin | Japan |
| Warranty | 1 year limited |
| Care Instructions | Wipe with a soft, dry cloth. Avoid solvents. |
| Safety | Handle with care; avoid dropping to prevent damage. |
Frequently Asked Questions - AT-HS1 Audio-Technica
What cartridges are compatible with the AT-HS1?
The AT-HS1 is a universal half-inch headshell designed for standard 4-pin turntable cartridges with 1/2-inch mounting hole spacing.
Does the AT-HS1 come with lead wires?
Yes, it includes four color-coded lead wires (white, red, blue, green) for easy connection.
What is the weight of the Audio-Technica AT-HS1?
The headshell weighs approximately 9.5 grams, making it lightweight and suitable for balanced tonearms.
Can I use the AT-HS1 on any turntable?
It fits any turntable with a standard half-inch mount tonearm. Check your tonearm's compatibility before purchase.
How do I install a cartridge on the AT-HS1?
Attach the cartridge using the two included screws, align the slots for overhang, then connect the color-coded lead wires to the cartridge pins.
Is the AT-HS1 made of metal or plastic?
The headshell is made of lightweight aluminum alloy for durability and resonance damping.
Does the headshell have an integrated finger lift?
Yes, it features a convenient plastic finger lift for easy handling.
Are the pins gold-plated?
Yes, the 4 pins are gold-plated to prevent oxidation and ensure a reliable connection.
What tools are needed for installation?
The package includes a small screwdriver and mounting screws. No additional tools are required.
How do I clean the AT-HS1?
Gently wipe with a soft, dry cloth. Avoid using chemical cleaners or solvents that may damage the finish.
User questions about AT-HS1 Audio-Technica
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
No questions yet. Be the first to ask one.
Download the instructions for your DJ Equipment in PDF format for free! Find your manual AT-HS1 - Audio-Technica and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. AT-HS1 by Audio-Technica.
USER MANUAL AT-HS1 Audio-Technica
audio-technica
AT-HS1 TURNTABLE CARTRIDGE HEADSHELL
Universal half-inch (1/2) headshell for 4-pin turntable cartridges.
