Product Type	Phono Cartridge for 78 RPM records
Brand	Audio-Technica
Model	AT-VM95SP/H
Category	DJ Equipment
Stylus Type	3 mil conical (78 RPM)
Stylus Replacement	AT-VM95SP (replaceable)
Output Voltage	4.0 mV (1 kHz, 5 cm/sec)
Channel Separation	20 dB (1 kHz)
Frequency Response	20-20,000 Hz
Tracking Force Range	1.8-2.2 g (recommended 2.0 g)
Cartridge Weight	6.0 g
Dimensions (Cartridge)	17.5 x 17.5 x 24.0 mm
Mounting	Standard 1/2-inch spacing
Load Impedance	47 kΩ
Load Capacitance	100-200 pF
Power Source	Passive (no external power)
Maintenance	Clean stylus with soft brush; replace stylus after 500-1000 hours
Safety Precautions	Avoid dropping; keep away from strong magnetic fields
Spare Parts	Replacement stylus: AT-VM95SP

Frequently Asked Questions - AT-VM95SP/H Audio-Technica

What is the AT-VM95SP/H used for?

It is a phono cartridge designed specifically for playing 78 RPM records with a 3 mil conical stylus.

Is the stylus replaceable?

Yes, the stylus is replaceable. Use the AT-VM95SP replacement stylus.

What is the recommended tracking force?

The recommended tracking force is 2.0 grams, with a range of 1.8-2.2 grams.

How do I clean the stylus?

Use a soft brush to gently clean the stylus from back to front. Avoid using liquid cleaners.

What is the output voltage of this cartridge?

The output voltage is 4.0 mV at 1 kHz and 5 cm/sec.

Will the AT-VM95SP/H work with any turntable?

It fits standard 1/2-inch mounting heads. Ensure your turntable can accommodate a 78 RPM stylus and proper preamp.

How often should I replace the stylus?

Replace the stylus after 500-1000 hours of play, or sooner if you notice distortion.

What is the channel separation?

Channel separation is 20 dB at 1 kHz.

Can I use this cartridge for 33 or 45 RPM records?

No, it is optimized for 78 RPM records. Using it for other speeds may damage your records.

Where can I find the user manual?

The user manual is available for download on notice-facile.com in PDF format.

USER MANUAL AT-VM95SP/H Audio-Technica

VM95 Series Cartridges

Close-up of a metallic cylindrical object with a pointed tip, no visible text or symbols

Metal

Bonded Stylus Models

In a bonded (or jointed) stylus, a diamond tip is glued on a metal shank that is itself glued into the hole of the cantilever. This type of stylus is generally less expensive to produce, but provides an excellent option for the casual listener.

Diamond (bonded to metal)

AT-VM95C

Dual Moving Magnet Cartridge with Conical Bonded Stylus Perfect for casual listener searching for a reliable cost-effective cartridge

AT-VM95E

Dual Moving Magnet Cartridges with Elliptical Bonded Stylus Next generation of the legendary 95E, considered one of the finest entry-level phone cartridges ever produced

AT-VM95SP

Dual Moving Magnet Cartridge with Canical Bonded Stylus Designed for use with 78 rpm/shellac or short play (SP) records

Conical

STYLUS FRONT VIEW STYLUS FRONT VIEW

STYLUS FRONT VIEW

STYLUS HORIZONTAL CROSS SECTION STYLUS HORIZONTAL CROSS SECTION

R = 0.6 mil

R = 0.3 mil R = 3 mil

Close-up of a metallic conical object with a faceted surface (no text or symbols visible)

Whole diamond

Nude Stylus Models

Nude styli, shaped from whole diamonds, are more costly than bonded styli. But because of their lower mass, nude styli track more accurately. Also, since our nude styli are grain-oriented, with their longest-wearing faces touching the record surface, they last longer.

AT-VM95EN

Dual Moving Magnet Cartridge with Elliptical Nude Stylus Ideal step-up model. The nude elliptical tip is lighter and follows the groove of your records with more precision

AT-VM95ML

Dual Moving Magnet Cartridge with Microlinear Nucle Stylus Microlinear (ridge shape) allows for more precise contact with record grooves leading to higher fidelity and less inner groove distortion

AT-VM95SH

Dual Moving Magnat Cartridge with Shibata Nude Styus Premier VM95 cartidge. Shibata shape has two longer, narrower radii, allowing more surface contact resulting in an extended frequency response and a highly detailed listening experience

Elliptical Microlinear ShibataConical (78 rpm) Elliptical
