| Product Type | Freestanding Washing Machine |
| Brand | Tisira |
| Model | TDW13XE |
| Loading Type | Front Load |
| Capacity | 7 kg |
| Maximum Spin Speed | 1300 rpm |
| Energy Efficiency Class | A+++ |
| Dimensions (H x W x D) | 85 x 60 x 55 cm |
| Weight | 68 kg |
| Power Supply | 220-240 V / 50 Hz |
| Water Connection | Cold water only |
| Number of Programs | 15 |
| Key Programs | Cotton, Synthetics, Delicates, Quick Wash, Eco, Wool |
| Additional Features | Delay Start, Child Lock, AquaStop, Drum Clean |
| Noise Level (Wash/Spin) | 56 dB / 78 dB |
| Display Type | LED |
| Drum Material | Stainless Steel |
| Door Opening | Left hinge |
| Spare Parts Availability | 7 years after purchase |
| Repairability Index | 8.4/10 |
| Manual Languages | English, French, Italian, Spanish, German |
Frequently Asked Questions - TDW13XE Tisira
How do I install the washing machine?
Remove all packaging and transportation bolts. Connect the water inlet hose to a cold water tap with a 3/4" thread. Attach the drain hose to a standpipe or sink outlet. Level the machine by adjusting the front feet. Plug into a grounded outlet.
What is the maximum spin speed?
The maximum spin speed is 1300 rpm, which can be adjusted via the program selector or spin speed button.
How do I clean the detergent drawer?
Remove the drawer by pressing the blue lever inside. Rinse under warm water to remove residue. Clean the recess with a brush. Reinsert fully.
What should I do if the machine displays an error code?
Refer to the manual's error code table. Common codes: E01 (water fill issue), E02 (drain problem), E03 (door lock failure). Try resetting by unplugging for 30 seconds.
How often should I run the drum clean cycle?
Run the Drum Clean program every 2-3 months to prevent mold and odors. Alternatively, use a washing machine cleaner monthly.
Can I wash delicates and wool in this machine?
Yes, the machine has a Delicates program for silk and lace, and a Wool program certified for machine-washable wool items. Use a mesh bag for small items.
What is the energy consumption per cycle?
For a standard cotton 60°C cycle, approximately 0.9 kWh. Actual consumption varies by load and program.
How do I activate the child lock?
Press and hold the Child Lock button (usually a padlock icon) for 3 seconds until the indicator lights up. To deactivate, hold again.
What spare parts are available and for how long?
Essential parts like door hinges, filters, belts, and pumps are available for at least 7 years after purchase. Order through Tisira service or authorized dealers.
Why is the machine vibrating excessively?
Check if transportation bolts are removed. Ensure the machine is level by adjusting feet. Avoid overloading and distribute laundry evenly.
