SI12010N - Iron SWAN - Free user manual and instructions

Product Type	Steam Generator Iron
Model	SI12010N
Brand	Swan
Input Voltage	220-240V
Frequency	50/60Hz
Power Consumption	2000-2400 Watts
Water Tank Capacity	500 ml
Steam Output	Continuous steam with lock function
Vertical Steam	Yes
Soleplate Material	Not specified (assumed stainless steel or ceramic)
Temperature Settings	Adjustable thermostat with fabric guide
Indicator Lights	Steam ready/empty tank light, heating indicator
Safety Features	Auto shut-off not specified, safety valve on boiler
Cord Length	Not specified (estimated 2m)
Weight	Not specified (estimated 2.5 kg)
Dimensions	Not specified
Cleaning and Maintenance	Clean with damp cloth; descale with lemon juice solution
Descaling	Recommended regularly, especially in hard water areas
Warranty	2 years (UK and Eire only)
Certifications	EMC, LVD, RoHS, EcoDesign

Frequently Asked Questions - SI12010N SWAN

How do I fill the water tank?

Unplug the iron and wait 15 minutes for it to cool. Remove the filler cap on the boiler and fill with water using the provided jug. Do not overfill. The tank holds approximately 500 ml. Always close the cap tightly before use.

Can I use tap water?

In hard water areas, use bottled, distilled, or filtered water to prevent limescale buildup. Tap water may cause scaling, which voids the warranty. If you notice flecks on the soleplate, descale immediately.

How do I use the steam lock?

Press the steam button, then push the steam lock switch forward to lock continuous steam. To release, press the steam trigger and pull the steam lock switch back. This is useful for steady ironing.

Is vertical steaming possible?

Yes. Hold the iron vertically 5-15 cm from hanging fabrics and press the steam button. Use for curtains or hanging clothes. Always ventilate the room and never direct steam at people or animals.

How often should I descale the iron?

Descale regularly, especially if you live in a hard water area. A mixture of 1 part lemon juice to 10 parts water can be used. Run on max steam for 5 minutes, then rinse with clean water. Ignoring scale may damage the iron.

What should I do if the iron produces smoke on first use?

This is normal. The sealers inside the steam generator burn off during first heating. The smoke and odor will disappear after a few minutes. Ensure good ventilation.

Can children use this iron?

Children aged 8 years and above can use it under supervision. Cleaning and maintenance should not be done by children unless they are older and supervised. Keep the appliance and cord out of reach of children under 8.

How do I clean the soleplate?

Unplug and let cool. Wipe with a damp cloth or non-abrasive liquid cleaner. Never immerse the iron in water. For stubborn deposits, use a gentle cleaner suitable for irons.

What does the indicator light mean?

The 'steam ready/empty water tank' light indicates when the boiler is ready for steam or if water is low. The heating indicator on the iron turns on during heating and off when the set temperature is reached.

What is the warranty period?

The Swan SI12010N comes with a 2-year warranty from the date of purchase, valid in the UK and Eire. It covers faulty materials or workmanship. Keep the proof of purchase.

USER MANUAL SI12010N SWAN

Purple and white steam iron with brand name 'ProSteam' on the side (no visible text beyond branding)

IMPORTANT INFORMATION - RETAIN FOR FUTURE USE

When using any electrical appliance, basic safety precautions should always be followed including the following:

• Always ensure that the voltage on the rating label corresponds to the mains voltage in your home
• Incorrect operation and improper use can damage the appliance and cause injury to the user.
• This appliance can be used by children aged from 8 years and above if they have been given supervision or instruction concerning use of the appliance in a safe way and if they understand the hazards involved. Cleaning and user maintenance shall not be made by children unless they are older than B and supervised. Keep the appliance and its cord out of reach of children aged less than 8 years. Check the power cord and plug regularly for any damage. If the cord or the plug is damaged, it must be replaced by the manufacturer or qualified person in order to avoid an electrical hazard.
• Do not use the appliance if it has been dropped or damaged in any way. In case of damage, take the unit in for examination and/or repair by an authorised service agent.
  • Never immerse the unit in water or any other liquid for cleaning purposes.
• Remove the plug from the socket by gripping the plug. Do not pull on the cord to disconnect the appliance from the mains. Always unplug the unit when not in use, before cleaning or when adding or removing parts.
• The use of accessory attachments that are not recommended or supplied by the manufacturer may result in injuries, fire or electric shock.
• Do not let the cord hang over the edge of a table or counter. Ensure that the cord is not in a position where it can be pulled on inadvertently.
• Do not allow the cord to touch hot surfaces and do not place on or near a hot gas or electric burner or in a heated oven.
• Do not use the appliance on a gas or electric cooking top or over or near an open flame.
• Use of an extension cord with this appliance is not recommended. However, if it is necessary to use an extension lead, ensure that the lead is suited to the power consumption of the appliance to avoid overheating of extension cord, appliance or plug point. Do not place the extension cord in a position where it can be pulled

IMPORTANT INFORMATION - RETAIN FOR FUTURE USE

• Do not carry the appliance by the power cord.
• Do not leave the appliance unattended during use. Always unplug the unit when not in use or before cleaning.
• Always operate the appliance on a smooth, even, stable surface. Do not place the unit on a hot surface.
  • Ensure that the unit is switched off after use.
• The manufacturer does not accept responsibility for any damage or injury caused by improper or incorrect use, or for repairs carried out by unauthorised personnel.
• In case of technical problems, switch off the product and do not attempt to repair it yourself. Return the appliance to an authorised service facility for examination, adjustment or repair. Always insist on the use of original spare parts. Failure to comply with the above mentions precautions and instructions, could affect the safe operation of this product.
• Your appliance must never be switched on through an external timer or any kind of separate remote control system
  • The water inlet must be closed during use
• Do not open the safety valve while using the appliance or before the water is completely used up [when the iron stops producing steam indicates that the tank is empty]. To add water, unplug and wait 15 minutes to avoid sudden temperature changes. Place a cloth over the safety valve and unscrew slowly to allow any remaining steam/pressure to escape slowly
• Only place the unit complete with base on a stand that is designed to withstand the weight. Some lightweight ironing boards may be unsuitable. In this case, place on separate counter top.

TECHNICAL DATA

Description: Steam Generator

Model: SI12010N

Input Voltage: 220-240V

Frequency: 50/60Hz

Power consumption: 2000-2400 Watts

1. Steam/cable tube

2. Power cord with plug (British standard plug on this model)

3. power switch on/off button

4. Steam ready / empty water tank indicator light

5. Iron stand

6. Boiler filter cap

S

HOW TO USE

Temperature Setting	Synthetic●	Wool Silk●●	Cotton●●●	Max
Fabric	Nylon Synthetic Acrylic Acetate	Silk Wool Polyester	Rayon Cotton Linen	Cotton, Linen
Ironing Instruction	Dry iron on the opposite side of the fabric.	Use a press cloth and steam iron on the opposite side of the fabric	Steam Ironing	Steam Ironing
Steam Selection

PREPARE THE APPLIANCE FOR USE:

Remove all packaging including any soleplate covers etc.

• Check if the rating indicated in the rating plate is corresponding to the mains voltage in your home (220-240V).
  • Fully unwind and straighten the power cord and the supply hose.
• Place the appliance on a stable, level and horizontal surface like an ironing board.
• Place the iron on the iron rest horizontally.
• Remove the filler cap [6] and fill the base with water using the filling jug [12]. The base will hold around 500ml of water.
• IMPORTANT: Your warranty does not cover damage caused by limescale! If you live in a hard water area, use bottled, distilled or filtered water. Do not use

8

了

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

[Non-Text]

HOW TO USE

CONTROLS

- When used for the first time, the appliance may give off smoke and an odour for several minutes. This is caused by heating and subsequent drying of the sealers used in assembling the steam generator and iron. This will only happen one time.

DRY IRONING (Just don't press the steam button!)

1. Connect the appliance to a suitable socket outlet. Then the heating indicator light will light up to indicate that the unit has been connected to the power supply.
2. Set temperature control knob to desired position according to above ironing temperature setting guide or fabric setting chart. Heating indicator (B) light on the iron unit will turn on to indicate that the soleplate is being heated up. When heating indicator light turns off, it indicates that desired temperature has been reached. It is ready for dry ironing. During use, it is normal that heating indicator light will cycle on and off, which means that the soleplate is automatically keeping temperature constant. (For every first time use, it should be pre-heated for about 3 minutes to ensure even temperature across the soleplate)
3. After use, put iron unit back on the base unit, turn temperature control knob to "MIN" and turn off power switch on the control panel.
4. Unplug the appliance from main socket.
5. Note: When changing your temperature setting from higher setting to lower, do not start ironing immediately since it may burn your fabrics. Please wait until heating indicator light turns on, and then turn off again.
6. For best results always start with the fabrics that need coolest setting first.

STEAM IRONING

1. Follow the steps above but press the steam button during ironing. The high pressure system and the constant flow of steam makes ironing much easier!
2. For constant steam, press the steam button then push the Steam Lock switch forward. This will lock the steam trigger in the ON position.

3. To release the steam lock, press the steam trigger and pull the steam lock switch back.

4. 1

HOW TO USE

FILLING THE BOILER

1. Make sure the supply cord is unplugged from the main socket.
2. Do not open the filler cap while using the appliance or before the water is completely used up [when the iron stops producing steam indicates that the tank is empty]. To add water, unplug and wait 15 minutes to avoid sudden temperature changes. Place a cloth over the safety valve and unscrew slowly to allow any remaining steam/pressure to escape slowly
3. Fill the boiler with water using refill cup. 12)
4. Refit the filler cap fully.
5. After use, put iron unit back on the base unit, turn temperature control knob to "MIN" and turn off power switch on the control panel.

STEAM IRONING TIPS

1. Before steam ironing, make sure the fabric is suitable for this kind of ironing. Check the garment label for the correct ironing temperature
2. Sort the garments by ironing temperature with lowest first. This saves time as the iron takes longer to cool down than it does to heat up.
3. Always unlock the steam button between garments and when not ironing.

VERTICAL STEAM IRONING

• Follow the steam ironing process, and then hold the iron in vertical position about 5cm to 15cm away from the hanging fabrics. Press the steam button, which will create the steam.
• This feature is especially used for removing creases from hanging clothes and curtains. Never directsteam toward people or animals
  • The room should be ventilated.
  • Note: Never block the steam hose.

HOW TO USE

EMPTYING AND STORING

• Disconnect the appliance from the mains socket and allow the appliance to cool down for 60 minutes at least.
  • After use, pour out all the remaining water. Take care when removing the filler cap as described on page 7
  • The iron should be placed on the iron rest, and then stored

CLEANING & MAINTENANCE

• Unplug the appliance from the main socket and let the iron completely cool down.
• Clean the iron with a damp cloth.
- Wipe off scale and any other deposits on the soleplate with a damp cloth or non-abrasive (liquid) cleaner.
• Never clean the appliance under the tap.
- The outside of the base can be cleaned with a soft cloth moistened with a mild detergent solution

DESCALING

It is very important to descale the iron regularly - especially if you live in a hard water area! If you notice small flecks of scale coming from the soleplate, it is a sure sign that the product needs descaling.

A cheap method of descaling is to use 1 part lemon juice to 10 parts water. Add to tank and run through for about 5 minutes on max steam setting. Empty out the water and repeat process with clean water.

We highly recommend using bottled water as it is inexpensive and it could be many years before you need to descale the product. In certain areas of the UK, the iron can become scaled up after only a few weeks!

Call 0871 200 0003 for more info.

DOCUMENTATION

We Swan Products Ltd declare that this product conforms to the following product legislation in accordance with the following directive(s):

• 2004/108/EC The EMC Directive (the Electromagnetic Compatibility Directive).
• 2006/95EC. The LVD Directive (Low Voltage Directive).
• 2011-65-EU. The RoHS directive (Restriction of Hazardous Substances Directive) • 2009/125/EC Eco Design

WARRANTY

This product is guaranteed for 2 years from the date of original purchase. If any defect arises due to faulty materials of workmanship the faulty products must be returned to the place of purchase. Refunds or replacement is at the discretion of the store.

The following conditions apply:

• The product must be returned to the retailer with proof of purchase.
- The product must be installed and used in accordance with the instructions contained in this instruction guide.
• It must be used only for domestic purposes.
• It does not cover wear and tear, damage, misuse or consumable parts.
- Swan Products Ltd has limited liability for incidental or consequential loss or damage.
• This guarantee is valid in the UK and Eire Only.

BS PLUG

The wires in the mains lead are coloured in accordance with the following code:

BLUE

NEUTRAL

BROWN

LIVE

GREEN/YELLOW EARTH

As the colours of the wire in the mains lead of this appliance may not correspond with the colour markings identifying the terminals on your plug, proceed as follows:

The wire which is coloured BLUE must be connected to the terminal which is marked with the letter N or coloured black. The wire which is coloured BROWN must be connected to the terminal which is marked with the letter L or coloured red. The wire which is coloured GREEN/YELLOW must be connected to the terminal which is marked with the letter E or [earth symbol] and is coloured GREEN or GREEN/YELLOW.

WARNING: THIS APPLIANCE MUST BE EARTHED

DISPOSAL OF UNIT

Appliances bearing the symbol shown here may not be disposed of in domestic rubbish. You are required to dispose of old electrical and electronic appliances like this separately. Please visit www.recycle-more.co.uk or www.recyclenow.co.uk for access to information about the

recycling of electrical items. Please visit www.weeeireland.ie for access to information about the recycling of electrical items purchased in Ireland. The WEEE directive, introduced in August 2006, states that all electrical items must be recycled, rather than taken to landfill. Please arrange to take this appliance to your local Civic Amenity site for recycling, once it has reached the end of its life.

Two horizontal bar segments with grayscale shades and a central crosshair symbol (no text or labels)

SWAN BRAND HERITAGE

Vintage iron iron with coiled cord and handle (no visible text or symbols)

Did you know...

In 1933 most homes were heating their irons over the gas ring or still putting hot coal in them. This Swan iron was basically an element with a handle, which plugged straight into a light bulb socket. And at a mere 14 shillings (70p), it meant many households could own a prestigious Swan Product.
