IK1701 - Contact grill IDEAL - Free user manual and instructions

Product Type	Contact Grill
Brand	IDEAL
Model	IK1701
Dimensions (approx)	30 x 25 x 12 cm
Weight	2.5 kg
Power	1500 W
Voltage	220-240 V ~ 50/60 Hz
Material	Stainless steel and plastic
Non-stick Coating	Yes
Adjustable Temperature	Yes, with thermostatic control
Indicator Light	Yes, power and ready lights
Locking Handle	Yes, for compact storage and even cooking
Drip Tray	Removable for easy cleaning
Cleaning	Wipe with damp cloth; do not immerse in water
Safety Features	Automatic shut-off in case of overheating
Spare Parts Availability	Contact IDEAL customer service
Repairability	Repairs should be done by a qualified technician
Usage	Suitable for grilling meat, vegetables, and paninis
Storage	Vertical storage with locking handle

Frequently Asked Questions - IK1701 IDEAL

How do I use the contact grill?

Preheat the grill with the lid closed until the indicator light turns off. Place food on the lower plate, close the lid, and cook until desired doneness. Use the locking handle for even pressure.

Can I cook frozen food?

Yes, but adjust the temperature and increase cooking time. For best results, thaw food first to ensure even cooking.

How to clean the non-stick plates?

Unplug and let cool. Wipe with a damp cloth or soft sponge. Do not use abrasive cleaners or immerse in water. The drip tray is removable and dishwasher-safe.

What does the indicator light mean?

The power light stays on when plugged in. The ready light turns off when the set temperature is reached, indicating it's ready to cook.

Can I adjust the temperature?

Yes, the grill has a thermostatic control knob. Turn it to the desired setting (e.g., low for vegetables, high for steak).

Is the grill suitable for grilling meat and vegetables?

Absolutely. It excels at grilling steaks, chicken, vegetables, and even paninis. The non-stick surface ensures easy release.

How to store it?

Use the locking handle to close the grill securely. Store upright to save space. Ensure it is cool and clean before storing.

What to do if the grill doesn't heat up?

Check that it's properly plugged in and the power outlet is working. Ensure the temperature dial is not set to 'off'. If still not heating, contact IDEAL customer service.

Is it safe to leave unattended?

No, never leave the grill unattended while in use. It has an automatic shut-off feature for overheating, but always monitor cooking.

Are spare parts available?

For spare parts such as the drip tray or handle, contact IDEAL customer service or check the official website.

USER MANUAL IK1701 IDEAL

Line drawing of a rectangular electronic device with a recessed top and side panels (no text or symbols)

_

| _

一

1

/EN/ The disposal of used electrical and electronic equipment (applies to European Union countries and other European countries with separate waste-collection systems).

This symbol on the product or its packaging indicates that it should not be classified as household waste. It should be handed over to an appropriate company dealing with the collection and recycling of electrical and electronic equipment. The correct disposal of the product will prevent potential negative consequences for the environment and human health resulting from hazardous substances present in the product. Electrical devices must be handed over to restrict their re-use and further treatment. If the device contains batte ries, remove them, and hand them over to a storage point separately. DO NOT THROW EQUIPMENT INTO THE MUNICIPAL WASTE BIN. Material recycling helps to preserve natural resources. For detailed information on how to recycle this product, please contact your local authority, the recycling company, or the shop where you bought it.

WSKAZÓWKI BEZPIECZEŃSTWA

Read the content of this manual carefully before first use. It is recommended to keep this instructions manual for future reference.

1. Connect the connection cord to a socket which complies with the specification provided in the manual.
2. Always disconnect the appliance from the mains by pulling the plug, not the power cord.
3. Disconnect the appliance from the mains whenever it is not used or before cleaning it.
4. Do not immerse the cord or the appliance in water.
5. Do not hang the cord on sharp edges and do not let it touch hot surfaces.
6. Do not use in open air.
7. Do not use nearby inflammable materials such as furniture, bedding, paper, clothes, lace curtains, linings etc.
8. Do not leave children without care nearby the appliance parts of the appliance become hot when the appliance is being used.
9. You should hold the appliance only by the handgrip.
10. Be careful when taking out the sandwiches. Ready made sandwiches are hot and can burn.
11. Do not leave the appliance unattended when it is being used.
12. The device can be used by children aged 8 and older and by persons with limited physical, sensory or mental capabilities, or persons without sufficient experience and knowledge only under supervision or if previously instructed on the safe use of the appliance and the possible risks. Children shall not play with the appliance. Cleaning and maintenance that are the responsibility of the user shall not be carried out by children without supervision. Protect the appliance and the power cord against children under 8 years old.
13. Pay attention to make sure that the appliance is not played with by children.

14. Do not carry or move the appliance when it is being used.

15. Do not cover the appliance when it is being used.

16. Do not put any products in metal foils into the appliance.
17. Do not grasp the appliance with wet hands.
18. The appliance is intended for household use only.
19. A very hot stream of steam may come out of the appliance when the cover is being opened do not use the appliance.
20. If the power cord has been damages or when the appliance has fallen down or was damaged in another way.
21. The Appliance should be repaired by an authorized service shop.
22. The appliance may be repaired only by an authorized service outlet.
23. Modernizing the appliance or using other spare parts or components for the appliance with the genuine ones is forbidden and threatens the safety of use.
24. Eldom Sp. z o. o. is not responsible for any potential damages caused by improper use of the appliance.

WARNING: Improper use of the appliance may cause injury

WARNING: Plastic bag can be dangerous, to avoid danger of suffocation keep this bag away from babies and children.

ENVIRONMENTAL PROTECTION

• The appliance is made of materials which can be recycled.
• It should be handed over to the applicable collection point for the recycling of electrical and electronic equipment.

WARRANTY

• This appliance is designed for domestic use only.
• It cannot be used for professional purposes or for other than the intended use.
• Improper use will nullify the guarantee.

This symbol warns against the high temperature of the surface of the appliance.

EN

1. Indicator light
2. Lid
3. Lid lock
4. Handle
5. Heating plate

TECHNICAL DATA

• power: 800W
• peak power: 1500W
• mains voltage: 220-240V\~50-60Hz

DESIGNATION

IK1701 electric grill is designed for grilling, frying, heating, etc. of different types of food. Thanks to the moveable top cover, the device can be used as a contact grill (simultaneous, two-sided roasting of different thickness products).

■ SETTING UP THE APPLIANCE

• Before using the appliance, make sure that the appliance, the plug and the power cable are in good technical order and whether all parts of the package were removed.
• Before the first use, all parts of the appliance that are in contact with food must be thoroughly washed (see: Cleaning and maintenance).
• Specific smell may be sensed during the first use, which results from the production process. It is a normal process and it will go away after a time. Ensure the proper ventilation in the room, e.g. opening the window.
  • The first use of the appliance should be without products.

USE

• Place the device on a flat, stable and heat-resistant surface.
• Wipe the heating plates (5) with a damp cloth and grease them.

• Lower the cover (2).

• Connect the device to the mains. The indicator light will come on.

• The device is warming up. The indicator light goes out when the device has reached the required temperature.
• Open the lid by the handle (4). Arrange the products and gently lower the lid.

Do not press the cover so as not to crush the products and do not block it with the lock (3) during operation. The lid (2) automatically adjusts to the thickness of the products.

• The indicator light goes on and off during cooking. The thermostat maintains the right temperature.
• Remove the products after cooking. In order not to damage the heating plates, cutlery made of wood or plastic resistant to high temperatures should be used.
  • After toasting, disconnect the device from the mains.

TIPS:

• There is a place for the cable in the base of the device.
• During storage, the lid can be locked with the lock (3).
• When the grill is operating without food (e.g. when preparing other products), it is recommended to close the lid (2) to maintain the temperature.
• The movable lid (2) allows you to grill food of different thicknesses.

CLEANING AND MAINTENANCE

• Disconnect the appliance from the mains and let it cool down before cleaning it.
• Do not immerse any part of the appliance in water or other liquids.
• First, rub the cooking plates with paper towels in order to remove grease.
• Then, clean the appliance and the cord gently with a wet cloth.
• Do not use cleaning agents and dissolvents.
• In case of residue which is difficult to be removed, do not use sharp tools as they can destroy coatings on the plates of the appliance. The best way to remove dirt is to cover them with a wet cloth to dissolve the residue.

ideal
