D/A-Converter S - Audio/video converter AVM - Free user manual and instructions

Product Type	High-End D/A Converter Module
DAC Chip	ESS9038PRO with bi-quad output
Clock Generation	Temperature-stabilized high-precision oscillator with minimal jitter
Power Supply	Separate voltage regulation for digital and analogue circuits with multi-stage filtering
Cooling System	Massive cooling block for thermal stabilization and vibration damping
Compatibility	AVM OVATION CS 6.3/8.3, SD 6.3/8.3, MP 6.3/8.3
Installation	Factory or authorized dealer installation required
Warranty	2 years (extendable to 4 years with online registration)
Safety	Do not open; risk of electrical shock; must be grounded; protect from humidity, heat, direct sunlight
Design Principle	Modular for future hardware upgrades
Sound Improvement	Improved spatial imaging, detailed resolution, precise bass, natural musical flow
Certifications	EU Directives 2014/35/EU, 2014/30/EU, 2014/53/EU, 2009/125/EC, 2015/863/EU

Frequently Asked Questions - D/A-Converter S AVM

What is the AVM D/A-Converter S?

It is a high-end D/A converter module designed for AVM OVATION devices, featuring the ESS9038PRO DAC chip.

Which devices is the D/A-Converter S compatible with?

It is developed for OVATION CS 6.3/8.3, SD 6.3/8.3, and MP 6.3/8.3 models.

Can I install the D/A-Converter S myself?

No, installation should only be carried out by qualified personnel from AVM factory service or an authorized AVM dealer due to risk of damage or injury.

What sound improvements can I expect?

The D/A-Converter S provides significantly improved spatial imaging, more detailed resolution, precise bass, and a natural musical flow.

Does the D/A-Converter S have a warranty?

Yes, it comes with a 2-year guarantee which can be extended to 4 years by registering online.

Is the D/A-Converter S future-proof?

Yes, its modular design allows for simple retroactive hardware updates or upgrades, keeping the device state-of-the-art.

What are the main components of the D/A-Converter S?

It uses a flagship ESS9038PRO DAC, high-precision clock generator, separate voltage regulation, and a massive cooling block for thermal and vibration control.

How do I maintain the D/A-Converter S?

There is no user maintenance required. Keep the device protected from humidity, heat, and direct sunlight. Do not open the casing.

What certifications does the D/A-Converter S have?

It complies with EU Directives 2014/35/EU, 2014/30/EU, 2014/53/EU, 2009/125/EC, and 2015/863/EU.

Where can I find detailed installation instructions?

Detailed instructions are available at https://avm.audio/download/?filename=installationguide%2Favm_installationguide_DAC-S_de_en.pdf or via the QR code in the manual.

USER MANUAL D/A-Converter S AVM

We are delighted that you have chosen an audiophile masterpiece from AVM and thank you for your trust.

With the OVATION D/A-CONVERTER S, you have acquired a high-end component with outstanding sound quality to expand your OVATION .3 device!

In the following, we would like to give you some further information about your new DAC as well as installation instructions.

And finally, the most important thing: We at AVM and our specialist dealers are always happy to help you. If you have any questions, requests or suggestions, please contact us at any time. And if you are satisfied with us: Please feel free to recommend us to others.

Udo Besser - AVM Owner & Managing Director

Gerät nicht öffnen

Do not open – risk of electrical shock

Abstract black-and-white triangular symbol with a stylized human figure inside (no text or symbols)

Opened and installed by authorized personal only

Device must be grounded

Warning symbol: black exclamation mark inside a triangle (no text or numbers)

Protect against humidity

Bedienungsanleitung

OVATION D/A-Converter S

Warning symbol: black exclamation mark inside a triangle (no text or numbers)

Protect from heat and direct sunlight

Symbol of a trash bin with crossed lines indicating no waste or restriction, plus a solid black rectangle below (no text or symbols)

the device in household waste!

INHALTSVERZEICHNIS

PRODUKTINFORMATIONEN 8

GRUNDSÄTZLICHES 11

EINBAU....13

GARANTIE 15

RECHTLICHE INFORMATIONEN ...... 16

PRODUCTINFORMATION 18

FUNDAMENTALS....21

INSTALLATION 23

WARRANTY 25

LEGAL INFORMATION 26

Bedienungsanleitung

OVATION D/A-Converter S

Produktinformationen

Warning symbol: black exclamation mark inside a triangle (no text or numbers)

https://avm.audio/download/?filename=installationguide%2Favm_installationguide_DAC-S_de_en.pdf

AVM OVATION CS 6.3/8.3:

https://avm.audio/wp-content/uploads/Declaration-of-Conformity_CS8-3_CS6-3.pdf

AVM OVATION SD 6.3/8.3:

https://avm.audio/wp-content/uploads/Declaration-of-Conformity_SD8-3_SD6-3.pdf

AVM OVATION MP 6.3/8.3:

https://avm.audio/wp-content/uploads/Declaration-of-Conformity_MP8-3_MP6-3.pdf

Productinformation

• Highly specialised and selected components

• Flagship D/A converter ESS9038PRO with bi-quad output
  o High-precision metal film resistors
  o Audiophile and close-tolerance capacitors
  o Lowest noise and selected voltage regulators of the latest generation

• High-precision clock generation

o Temperature-stabilized and highly accurate oscillator with minimal jitter
o Minimal phase noise is achieved through strictly selected and matched components
- Separate voltage regulation with downstream multi-stage filtering

Separate supply voltages for the digital and analogue circuit parts

Multi-stage filtering of the supply voltages to prevent mutual interference between the various circuit components

Bedienungsanleitung

OVATION D/A-Converter S

- A new massive cooling block takes over extensive and sound-relevant tasks:

• Intensive cooling stabilises the operating points of the voltage regulators, resulting in significantly reduced noise components on the supply voltage
• Cooling and temperature stabilisation of the D/A converters and the I/U (current/voltage) converters ensure minimum distortion and maximum dynamic range at the same time
• Electrical shielding of the oscillator: mutual interference with the surrounding circuit components is effectively excluded

- The massive cooling block leads to effective vibration damping and thus significantly reduces sound-influencing microphonic effects, i.e. micromovements of the components through which electrical current flows against each other are effectively prevented, so that the induction of interference between them is no longer possible.

○ Increased service life of all components as all components are always operated in the ideal temperature range thanks to intensive cooling

• Developed for the following OVATION devices:

○ CS 6.3/8.3
○ SD 6.3/8.3
o MP 6.3/8.3

Fundamentals

Right from the start of the Ovation Line's construction, the realisation of a digital section was a top priority. This digital section should not only be the best in the world in terms of sound, but should also be future-proof.

The progress of developments in the digital world is fast-moving, that was already clear at the time. So what could be done to incorporate future developments?

The answer was obvious: the D/A converter section of the Ovation Line was designed to be modular, i.e. a hardware update or upgrade is simple and retroactive.

This means that the Ovation Line devices always remain state-of-the-art, with the highest level of sound quality, and will continue to grow in line with technical progress in the future. This is also our contribution to sustainability.

Bedienungsanleitung

OVATION D/A-Converter S

What will change in terms of sound?

This extensive redesign of the D/A-CONVERTER S results in significantly improved spatial imaging and an even more detailed resolution of the audio reproduction.

The bass range is reproduced more precisely, and the musical flow reaches a new level of naturalness.

The relaxed long-term enjoyment of all music genres is further enhanced.

Installation

Caution:

Warning symbol: black exclamation mark inside a triangle (no text or numbers)

As the D/A-CONVERTER S is a high-quality electronic component and improper installation can result in destruction or even danger to life and limb, installation should only be carried out by qualified personnel from our factory service or your AVM dealer.

Please contact us at: [e-mail]

Detailed installation instructions can be found here or via the QR code on the next page:

https://avm.audio/download/?filename=installationguide%2Favm_installationguide_DAC-S_de_en.pdf

QR code for installation instructions

Warranty

With the installation of the new D/A-CONVERTER S, we grant an additional one-year guarantee for your Ovation Line device if we install the D/A-CONVERTER S in our factory.

Like all our AVM devices, the D/A-CONVERTER S comes with a 2-year guarantee. If you register online, we will extend this guarantee to 4 years.

Legal information

AVM Audio Video Manufaktur GmbH confirms that the D/A-CONVERTER S extension and the upgradeable devices CS/SD/MP 6.3/8.3, to which these operating instructions belong, comply with the EU Directives 2014/35/EU, 2014/30/EU, 2014/53/EU, 2009/125/EC and 2015/863/EU valid at the time of preparation, as evidenced by the

confirmed by the labelling. The necessary tests were carried out with positive results.

Bedienungsanleitung

OVATION D/A-Converter S

The full text of the respective EU Declaration of Conformity is available at the following Internet address:

AVM OVATION CS 6.3/8.3:

https://avm.audio/wp-content/uploads/Declaration-of-

Conformity_CS8-3_CS6-3.pdf

AVM OVATION SD 6.3/8.3:

https://avm.audio/wp-content/uploads/Declaration-of-

Conformity_SD8-3_SD6-3.pdf

AVM OVATION MP 6.3/8.3:

https://avm.audio/wp-content/uploads/Declaration-of-

Conformity MP8-3 MP6-3.pdf
