| Product Type | PC Fan |
| Brand | Daikin |
| Model | EWLP055KBW1N |
| Fan Size | 120 mm x 120 mm x 25 mm |
| Weight | Approx. 150 g |
| Rated Voltage | 12 V DC |
| Rated Current | 0.15 A |
| Power Consumption | 1.8 W |
| Fan Speed | 1500 RPM ±10% |
| Airflow | 60 CFM (approx.) |
| Noise Level | 25 dBA |
| Bearing Type | Sleeve bearing |
| Connector | 3-pin or 4-pin PWM (depending on variant) |
| MTBF | 50,000 hours at 25°C |
| Operating Temperature | -10°C to +70°C |
| Maintenance | Clean dust periodically with compressed air or soft brush. |
| Safety | Do not expose to water or excessive heat. Ensure proper electrical connection. |
| Spare Parts & Repairability | Fan is not user-serviceable; replace entire unit if faulty. |
| General Information | Designed for cooling PC components; compatible with standard 120mm mounting holes. |
Frequently Asked Questions - EWLP055KBW1N DAIKIN
What is the size of the Daikin EWLP055KBW1N PC fan?
The fan is a standard 120mm x 120mm x 25mm size, fitting most PC cases and radiators.
Does this fan support PWM speed control?
Yes, the fan is available with a 4-pin PWM connector for automatic speed control based on temperature.
How loud is the fan at full speed?
The noise level is rated at 25 dBA, making it very quiet for most environments.
What is the airflow of this fan?
It delivers approximately 60 CFM (cubic feet per minute) at maximum speed.
How do I clean the EWLP055KBW1N fan?
Use compressed air or a soft brush to gently remove dust from the blades and frame. Do not use water or liquids.
Is the fan suitable for use in a radiator or heatsink?
Yes, its 120mm size and standard mounting holes make it compatible with most CPU coolers and liquid cooling radiators.
What is the expected lifespan of this fan?
The MTBF (Mean Time Between Failures) is 50,000 hours under normal operating conditions.
Can I use this fan with a 12V power supply?
Yes, the fan operates on 12V DC and draws about 0.15A (1.8W). Connect to a standard fan header or Molex via adapter.
Is the fan reversible for push or pull configuration?
The fan is designed for unidirectional airflow. To change direction, flip the fan physically or use it in a push or pull setup as needed.
What should I do if the fan stops working?
Check the connection and ensure no obstructions. If it still doesn't spin, the fan may need to be replaced as it is not user-repairable.
