Product Type	Weapon-mounted LED tactical light and laser pointer
Brand	Steiner
Model	TOR Fusion
Color	Black
Housing Material	Rugged military-grade aluminum
Finish	Hard anodized
Light Output	500 lumens white LED
Laser Type	Red or Green (depending on model)
Laser Wavelength (Red)	635 nm
Laser Wavelength (Green)	515 nm
Laser Power	< 5 mW
Laser Class	3R
Battery Type	1 CR123A lithium battery
Weight (without battery)	3.9 oz (113 g)
Dimensions	2.7 x 1.4 x 1.6 in (6.86 x 3.55 x 4.06 cm)
Mount Type	Rail mount (Picatinny/Weaver)
Rail Positions	6
Activation Method	Left/right pressure pads
Modes	Laser only, light only, both
Brightness Levels	Low, medium, high, plus high pulse mode for light
Auto-On Feature	Activates when weapon is raised
Auto Shut-Off	Laser only: after 5 minutes
Low Battery Indication	Flashing 5 times before shutdown
Environmental Resistance	Water resistant and dust proof
Adjustments	Windage and elevation
Included Accessories	1 CR123A battery, 5/64 Allen wrench, caution and aperture labels, user guide
Warranty Period	2 years
Part Numbers	Green laser: 7001; Red laser: 7005

Frequently Asked Questions - TOR Fusion Steiner

How do I install the battery in the TOR Fusion?

Twist the front bezel counterclockwise to separate it from the housing. Insert a new CR123A battery with the positive terminal (+) first. Align the white mark on the bezel with the white arrow on the housing and twist clockwise to close.

How do I mount the TOR Fusion to my weapon?

Ensure the firearm is unloaded. Use a flathead screwdriver to fully loosen the captive screws, pull back the clamp bar, position the rail bar on the weapon's rail, select one of 6 rail positions, then tighten the screws until snug.

How do I adjust the laser windage and elevation?

Use the included 5/64 Allen wrench. Turn the elevation screw clockwise to move the beam down, counterclockwise to move up. Turn the windage screw clockwise to move right, counterclockwise to move left. Do not over-torque.

How do I activate the Auto-On feature?

Turn the TOR Fusion on, then within 5 seconds press the pressure pads in sequence: Left, Right, Left, Right. The unit will flash to confirm. Point the unit at the ground for more than 1 second to set the inactive zone. Raising the weapon activates the unit.

How do I switch between laser, light, and dual modes?

Press and hold both pressure pads simultaneously to cycle through Laser Only, Light Only, and Both. Release when the desired mode is reached.

How do I adjust the brightness of the light?

Press and hold either the right or left pressure pad. The brightness cycles through low, medium, high, and high pulse mode for the light. Release when the desired level is reached.

What does the low battery indication look like?

When the battery is low, the laser or light will step down in power and flash 5 times slowly before turning off completely. Replace the battery when this occurs.

How do I clean the TOR Fusion?

Use alcohol and a cotton swab to clean the laser lens. Do not use strong cleaning fluid or solvents, and avoid liquid cleaners inside the battery compartment. Always remove the unit before cleaning the weapon.

What is the warranty period for the TOR Fusion?

Steiner offers a 2-year warranty against defects in workmanship and materials from the date of purchase. The warranty does not cover abuse, misuse, neglect, or disassembly.

Can I use the TOR Fusion with any handgun?

The TOR Fusion fits pistols with a Picatinny or Weaver-style rail forward of the trigger guard. It has 6 rail positions to accommodate different rail lengths.

USER MANUAL TOR Fusion Steiner

Black SEINER flashlight with lens and metallic components (no visible text or symbols on body)

User Guide

TOR Fusion

Welcome to the TOR Fusion weapon-mounted LED tactical light and laser pointer! From the company that brings you world-class tactical lasers and optics, the TOR Fusion combines a powerful white light LED and a red or green laser for spot-on accuracy and illumination.

Features

• Rugged military-grade aluminum housing
- Left/right pressure pads
• Auto-on function when drawn
- Adjustable laser and illumination power
- Water resistant
- Fits common holsters

This powerful weapon-mounted light and laser combination ensures Nothing Escapes You!

TOR Fusion At-A-Glance

Feature Description
Activation Options	Multiple modes of laser and light operation
Housing Durable, Hard	Anodized Machined Aluminum Housing and Rail Mount
Color Black
Adjustable Windage	and Elevation Laser and Light Brightness
Mounting Rail Mount
Battery Type One CR	123A Lithium Manganese Dioxide (Li/MnO2)
Environmental Conditions	Water resistant Dust Proof
Part Numbers Green	laser: 7001 Red laser: 7005

Included with your purchase of a TOR Fusion:

• One CR123A battery
• 5/64 Allen wrench
• Caution and aperture labels
• User guide

Important Warnings

Failure to read and follow these operating instructions and warnings may result in serious injury, damage to property, or death.

Firearm Safety

Prior to installing the TOR Fusion, ensure the firearm is unloaded and the magazine is removed.

Always follow these safety rules when handling a firearm:

• Always treat a firearm as if it were loaded.
- Store your firearm so that children cannot gain access to it.
- Always point the gun in a safe direction, away from anything you do not want to destroy.
- Keep your finger off the trigger until you are ready to fire.
- Be aware of your surroundings, target and what is beyond.

Laser Safety Precautions

The TOR Fusion features:

• A high-intensity 500 lumen white LED tactical light
- Either a green or red laser pointer, depending on the unit purchased

CAUTION: The TOR Fusion contains a Class 3R laser capable of causing permanent eye injury.

• DO NOT stare into the laser beam
• DO NOT look into the laser beam through binoculars or telescopes
• DO NOT point the laser beam at mirror-like surfaces
• DO NOT shine the laser beam into other individual's eyes

Red Laser Caution Label

Aperture Label

Green Laser Caution Label

Battery Warning

WARNING: FIRE, EXPLOSION, BURN HAZARD

The Fusion is powered by one CR123A battery.

The following safety precautions apply when handling lithium batteries:

• DO NOT short circuit, puncture, or disassemble a battery
• DO NOT attempt to recharge a battery
- NEVER dispose of lithium batteries in a fire, or in any way expose lithium batteries to excessive heat
- Batteries may explode if disassembled, crushed, recharged, or exposed to high temperatures
- Prior to use, inspect all batteries for cracks, leakage, or bulging
- NEVER install a defective battery in the TOR Fusion
- Store batteries at room temperature
• Refer to applicable federal, state, and local laws and regulations for proper disposal of the batteries

Getting Started

TOR Fusion Light & Laser Specifications
Center Wavelength	Green laser: 520 +/-10 nmRed laser: 635 +15/-5 nm
Beam Dot Size 0.50 inches at 50 feet
Maximum Power Output	Laser: <5 mWLED: 500 lumens +/- 10%
Weight (out battery) 3.9 oz. / 113 g
Size	2.7 x 1.4 x 1.6 in.(6.86 x 3.55 x 4.06 cm)

Battery Installation

Follow all firearm safety precautions before installing the battery.

1. Twist the front bezel counterclockwise to separate it from the housing.
2. Place a new CR123A battery into the unit with the positive terminal (+) in first.
3. Align the white mark on the bezel with the white arrow on the housing and twist the bezel clockwise to close.

The green and red lasers are direct diode lasers capable of extreme cold weather operation. The constant power drive circuit ensures that the laser output remains constant throughout the life of the battery.

Low Battery Indication

When the battery gets low, the TOR Fusion's laser or light will step down in power and flash 5 times slowly before turning off completely. Replace the battery when this occurs.

Rail Mounting

IMPORTANT: Unload the firearm and remove the magazine before mounting the TOR Fusion.

The rail mount on the TOR Fusion will fit pistols with a Picatinny or Weaver style rail forward of the trigger guard.

Follow these steps to mount the TOR Fusion to the rail:

1. Using a flathead screwdriver, fully loosen the captive screws.

2. Pull back the clamp bar.

3. Position the rail bar to fit the weapon's rail.

4. Once the best rail position is found, ensure the rail bar pins are inserted in the clamp bar in your preferred position. There are 6 rail positions to choose from.

5. Tighten down the screws until snug.

Operating the TOR Fusion

Always operate the TOR Fusion with the mount facing up.

Turn On

- Press and release right or left pressure pad to turn the laser and/or light on.

Turn Off

- Press and release right or left pressure pad to turn the unit off.

Note: If the TOR Fusion laser is left on, it will shut off automatically after 5 minutes to conserve battery power. If the LED light or the dual mode (laser + light) is left on, the Fusion stays on.

Switch to laser, light, and dual (laser + light) modes:

Press and hold BOTH pressure pads to cycle through:

• Laser Only
• Light Only
• Both Laser and Light

Release both pressure pads once the setting you want is reached.

Adjust brightness level and turn on high pulse mode:

1. Press and hold right or left pressure pad. The TOR Fusion laser and light brightness can be adjusted to low, medium and high. The light also has a high pulse mode.
2. Release the pressure pad when the brightness level you want is reached.
3. When the dual mode is displayed, adjust the brightness of the white light by pressing and holding the right or left pressure pad. The laser brightness does not change.
4. When the light is in high mode, the brightness will drop to medium after approximately 30 seconds to conserve battery life.

The TOR Fusion will remember the last setting even if the batteries are removed and replaced.

Windage and Elevation Adjustment

The TOR Fusion is pre-sighted at the factory. It may not be necessary for you to adjust the factory settings. However, differences in the alignment of your handgun's rail to its bore can result in the laser aim point being off target. Verify the boresight and adjust, if necessary, every time the TOR Fusion is mounted to a weapon.

The TOR Fusion has one screw for windage adjustment and one screw for elevation adjustment.

Adjust the laser beam using the windage and elevation screws

Use the 5/64 Allen wrench provided in the box to make adjustments.

• To move the beam spot down, turn the elevation screw clockwise.
• To move the beam spot up, turn the elevation screw counterclockwise.
• To move the beam spot to the right, turn the windage screw clockwise.
• To move the beam spot to the left, turn the windage screw counterclockwise.

DO NOT over-torque the screws. It can damage the internal laser module.

When the laser spot cannot move further, stop turning the adjustment screw.

Turn on Auto On

The TOR Fusion can be set to turn on automatically when you raise or draw your weapon. This mode is ideal for training.

With the TOR Fusion mount facing UP, do the following:

1. Turn the TOR Fusion on using the right or left pressure pad.

2. Within 5 seconds, fully press and release the activation pads in this pattern:

Left - Right - Left - Right

- If you take more than 5 seconds to press the pressure pads in this order, the Auto On feature will not work.

• After the sequence is completed, the TOR Fusion flashes to indicate that the Auto On feature is activated.

1. Turn the unit off using the right or left pressure pad.

2. Point the TOR Fusion at the ground (if weapon-mounted, point the muzzle straight at the ground). Keep the TOR Fusion in this position for more than 1 second. This is the INACTIVE ZONE.

3. Raise the TOR Fusion or your weapon to a shooting position. The laser, light or dual mode displays. This is the ACTIVE ZONE.

If the TOR Fusion goes untouched for more than 10 minutes, the Auto On feature is disabled to conserve battery life.

To turn off the Auto-On feature, with the TOR Fusion ON and mount facing UP, do the following:

1. Turn the TOR Fusion on using the right or left pressure pad.
2. Within 5 seconds, fully press and release the activation pads in this pattern:

Left - Right - Left - Right

1. After the pads are pressed, the TOR Fusion flashes to indicate that the Auto On feature is deactivated.

Maintenance

• Never use strong cleaning fluid or solvents.
• Do not use liquid cleaners inside the battery compartment.
• Keep the lens of the laser clean. Clean with alcohol and a cotton swab. A dirty lens will affect beam quality.
• ALWAYS remove the TOR Fusion before cleaning your weapon.

Warranty and Repair

Steiner Optics, Inc. warrants its products against defects in workmanship and materials for a period of two years from the date of purchase. Warranty is void if the product has been abused, misused, neglected, or disassembled prior to the return to the manufacturer.

This warranty does not cover loss, theft, deliberate damage, or cosmetic damage that does not hinder the performance of the product.

If you are experiencing any problems with your Steiner TOR product, please first review the manual for tips and information.

To return the TOR Fusion for repair, please contact Steiner Optics at www.steiner-optics.com.

STEINER

Nothing Escapes You

Steiner Optics

331 East 8th St.

Greeley, CO 80631

Tel: [phone]

www.steiner-optics.com
