GEM-10-D - Uncategorized ENTES - Free user manual and instructions
Find the device manual for free GEM-10-D ENTES in PDF.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product Type | Power Factor Controller |
| Brand | ENTES |
| Model | GEM-10-D |
| Dimensions (H x W x D) | 96 x 96 x 70 mm |
| Panel Cutout | 92 x 92 mm |
| Weight | 0.5 kg |
| Power Supply | 110-240V AC, 50/60Hz |
| Power Consumption | ≤ 5 VA |
| Measurement Parameters | Voltage, Current, Power, Power Factor, Frequency |
| Number of Steps | 10 |
| Display | Backlit LCD |
| Communication | RS485 Modbus (optional) |
| Operating Temperature | -10°C to +55°C |
| Storage Temperature | -20°C to +70°C |
| Humidity | < 95% non-condensing |
| Protection Rating | IP40 (front), IP20 (back) |
| Installation | Panel mount |
| Mounting Category | CAT III |
| Applicable Standards | IEC 61000, EN 61000 |
| Manual Language | English (28 pages) |
| Warranty | 2 years |
| Included Accessories | Mounting brackets, user manual |
| Maintenance | Clean with dry cloth; no user-serviceable parts |
| Safety | Disconnect power before installation; follow local codes |
Frequently Asked Questions - GEM-10-D ENTES
What is the ENTES GEM-10-D used for?
The GEM-10-D is a power factor controller designed to automatically improve the power factor of electrical installations by switching capacitor banks in steps.
How do I install the GEM-10-D?
Install in a panel with a 92x92 mm cutout. Connect power supply (110-240V AC) and current/voltage inputs following the wiring diagram in the manual. Ensure all connections are tight and system is de-energized.
What is the maximum number of capacitor steps?
The GEM-10-D supports up to 10 capacitor steps for power factor correction.
Can the GEM-10-D display measurement values?
Yes, it displays voltage, current, power factor, active/reactive power, and frequency on its backlit LCD. Use the front buttons to scroll through parameters.
Does the GEM-10-D have communication capability?
It can be equipped with an optional RS485 Modbus interface for remote monitoring and control.
How do I set the C/K ratio?
The C/K ratio is set during commissioning via the front panel. Consult the manual for step-by-step instructions based on your capacitor bank size and CT ratio.
What should I do if the display shows an error?
Common errors: 'No volt' or 'No current' indicate missing inputs. Check wiring and fuses. 'Over temp' means internal temperature too high; ensure adequate ventilation. Refer to manual error code table.
Can I use the GEM-10-D in a three-phase system?
Yes, it is suitable for three-phase systems with balanced or unbalanced loads. The device measures one phase voltage and current, and calculates total values.
How to clean and maintain the GEM-10-D?
Turn off power. Clean the front panel with a soft dry cloth. Do not use solvents or water. No internal maintenance is required; contact ENTES if faulty.
Where can I download the user manual?
The manual in English (28 pages) is available for free download on notice-facile.com in PDF format.
User questions about GEM-10-D ENTES
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
No questions yet. Be the first to ask one.
Download the instructions for your Uncategorized in PDF format for free! Find your manual GEM-10-D - ENTES and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. GEM-10-D by ENTES.
