MR035 - Kettle Maestro - Free user manual and instructions

Product Type	Electric Kettle
Brand	Maestro
Model	MR035
Capacity	1.7 L (1700 ml)
Rated Voltage	220-240 V ~AC
Rated Frequency	50 Hz
Power Consumption	1850-2200 W
Protection Class	Class I (earthed)
IP Protection	IPX0 (no water ingress protection)
Water Level Indicator	Yes, with indicator light
Automatic Shut-Off	Yes (when boiling or empty)
Boil-Dry Protection	Yes
Cordless Base	Yes, 360° rotation
Concealed Heating Element	Yes
Removable Anti-Scale Filter	Yes
Cover Opening	Button release
On/Off Switch	Yes, with indicator light
Handle	Ergonomic
Housing Material	Plastic
Weight (approx.)	1.2 kg
Usage	Household only

Frequently Asked Questions - MR035 Maestro

How do I descale the kettle?

Fill the kettle with a mixture of 1 part vinegar and 2 parts water up to the MAX level. Boil and let it sit for 10-12 hours. Pour out, then boil fresh water twice to remove vinegar smell. Alternatively, use a commercial descaling agent. Regular descaling every 2-3 months is recommended.

What is the maximum water level?

The maximum water level is indicated by the MAX mark on the water level indicator. Do not fill above this mark to avoid overflow during boiling.

Why does my kettle turn off before the water boils?

This usually indicates scale buildup on the heating element. The kettle's safety device shuts it off prematurely. Descale the kettle as described in the manual to restore normal operation.

Can I open the lid while the kettle is boiling?

No, do not open the lid during boiling. The steam can cause burns. Wait until the kettle has automatically turned off and cooled down before opening.

How do I clean the removable filter?

Remove the filter and clean it with a nylon brush under running water. For heavy limescale, soak the filter in vinegar or a descaling solution before brushing.

What does the indicator light mean?

The indicator light turns on when the kettle is heating water and turns off when the water reaches boiling point (automatic shut-off). It signals that the appliance is powered.

Is the kettle safe to use around children?

The kettle gets very hot. Do not let children use it without supervision. Keep out of reach of children. The appliance is not intended for use by persons with reduced capabilities without supervision.

Can I use the kettle for heating milk or other liquids?

No, the kettle is designed only for boiling water. Using it for other liquids may damage the appliance and void the warranty.

What should I do if the kettle does not turn on?

Check that the plug is securely connected to a power outlet and the base is properly connected. Ensure the switch is set to 'I'. If it still doesn't work, contact an authorized service center.

How to remove plastic taste from a new kettle?

Boil a full kettle of water, then discard. Repeat 2-3 times. If the taste persists, boil water with 2 teaspoons of baking soda, then discard and rinse thoroughly.

USER MANUAL MR035 Maestro

EN

DE

PL

RO

RU

UA

Owners manual. Electric kettle

White Kriggle water heater with engraved branding (no visible text or symbols on body)

Модель/Model: MR035

091

Certificated in Ukraine

Dear customer, we thank you for purchase of goods

Functionality, design and conformity to the quality standards guarantee to you reliability and convenience in use of this device. Please read and comply with these original instructions prior to the initial operation of your appliance and store them for later use of subsequent owners.

The kettle is designed only for warming and boiling water for home use.

Under condition of observance of user regulations and a special-purpose designation, a parts of appliance do not contain unhealthy substances.

Technical specifications

Model: MR035

Capacity: 1,7 L

Electrical supply:

Alternating current- AC;

Rated voltage 220-240V;

Rated frequency 50Hz;

Power consumption 1850-2200 W

Protective class I

Protection class IPX0

Description of the appliance

Picture1 (page 2)

A- Cover
B- Button for cover opening
C- Switch button
Position «0»- OFF
Position «I»- ON
D- Handle
E- Kettle case
F- Base

G- Scale of water level with indicator light

Safety instructions

When using your appliance, basic safety precautions should always be followed, including the following:

SPECIAL INSTRUCTIONS

ATTENTION!

• Do not allow the ingress of water and moisture on the support and internal electric parts of the device located outside the container for water.
• Always remove the kettle from the support to fill it with water or to clean.
• Do not touch the water in the kettle when it is on the support.

Failure to observe these rules may result in electric shock!

Only plug the appliance into an outlet with an earthed (ground) contact.

- DO NOT let children or untrained persons use the appliance

without supervision.

- DO NOT leave the appliance unnecessarily plugged in.

Disconnect the plug from the mains when the appliance is not being used.

- DO NOT use the power cord or the appliance in order to pull the plug out of the socket.

- DO NOT leave the appliance exposed to the weather (rain, sun, etc.).

- DO NOT leave the appliance without supervision when it is connected to the power supply.

- Close supervision is necessary when the appliance is used near children.

- Always use the appliance on a dry, level surface.

- Do not put on and take off the kettle from the support when it is switched on. First, turn it off with a switch.

- Always unplug from the plug socket when not in use and before cleaning.

- Do not operate the appliance if damaged, after an appliance malfunctions or it has been damaged in any manner, return to at authorized service engineer for repair.

- In the interest of safety, regular periodic close checks should be carried out on the supply cord to ensure no damage is evident.

Should there be any signs that the cord is damaged in the slightest degree, the entire appliance should be returned be authorized service engineer.

- Do not let the cord hang over the edge of a table or counter or touch hot surfaces. Allow unit to cool before storage.

- Do not touch any hot surfaces, do not store or cover the appliance until it has full cooled down.

- Do not use harsh abrasives, caustic cleaners or oven cleaners when cleaning this appliance.

• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.
• Do not leave the kettle switched on if the temperature in the room may fall below zero. When the temperature is below zero, the thermostat of the device may spontaneously turn on and switch on the device.

ATTENTION!

• The surface of the device becomes very hot during operation.
  Be careful because you may burn yourself greatly by touching the surfaces of the cover, case, water of vapor.
• Do not open the cover of the kettle during boiling.
• Do not lift the kettle by its cover.
• Take and lift the kettle only keeping it for the handle, touch only the buttons of the device.
• Do not fill the kettle with the water level higher than the mark «MAX».
• Place the kettle only on a dry, stable, even, slip-resistant surface.
• Lift the kettle full with hot water with special care!

In case of failure to observe the above mentioned rules there arises the danger of burning!

- To avoid possible damages by vapor turn the kettle nose away from walls and furniture when it is boiling. Use the support to save the sensitive cover of furniture from damages.

- Do not place the kettle and its support on heating devices.

• Do not close the opening for the exit of vapor near the switch.
• Do not use the kettle without a cover.
• Do not switch the kettle on without water or when the water level is below the mark «MIN». If the kettle is empty or there is not enough water in it, it is automatically turned off by safety device. In such case, disconnect the device from the mains, let it cool down and then fill it with water again and turn it on; the kettle will begin to boil water and after the end of this process it will turn off in the regular regime.
• THIS APPLIANCE IS FOR HOUSEHOLD USE ONLY. DO NOT USE THE APPLIANCE FOR ANYTHING OTHER THAN INTENDED USE.

Purchase industrial devices for commercial use.

Actions in extreme situations:

• If a device tumbled into water, immediately, unplug the device, not touching to the device or water.
• In case of appearance from appliance of smoke, sparkling, strong smell of a burn isolation, immediately stop use the device, unplug the device, appeal to the nearest service center.

Operation

Before the first use:

• Remove packing and advertising materials and stickers.
• Inspect the kettle and make sure that there are no damages to the kettle, power line cord, plug and support.
• Unwind the power line cord completely.
• Place the support on a dry, even, stable surface.

CAUTION! Is required on surfaces where heat may cause a problem – an insulated heat pad is recommended.

• Connect the plug to the mains.
• Remove the kettle from the support.
• Press the button to open the cover, the cover will open.
• Fill the kettle with cold water up to the mark «MAX». Close the cover (until it clicks).
• Place the kettle on the support.
• Turn the switch (C/ Fig.1) to the position «I». The indicator will light signaling that the device has turned on, and the kettle shall begin warming the water.
• When the water begins to boil, the switch will be turned to the position «O» (off), the light will fade and the kettle will be automatically turned off.
• You must pour out the first portion of water and repeat the boiling procedure again.
• Now the kettle is ready for use.

ATTENTION! Do not fill the kettle with cold water until cools down; let it get cool before filling with cold water.

The taste of plastic

• Usually the taste of plastic appears during the first boiling.
• Pour out the water boiled for the first time and repeat the procedure several times.
• If the taste of plastic persists, fill the kettle with water till the mark «MAX» and add 2 tea-spoons of soda. Boil the water and pour it out.

Further boil water as specified above.

The level of water in the kettle must be somewhere between the marks «MIN» and «MAX».

The process of warming the water can be interrupted at any moment by pressing on the switch.

ATTENTION! If your kettle switches off before the water begins

to boil, you should clean it of scale (see cleaning and maintenance). The kettle can continue operation if its cover is open.

Cleaning and maintenance

Regular cleaning improves the performance of the device.

The quantity and the speed of forming the scale, and consequently, the necessity of cleaning depend on the water hardness in your region and the intensity of the device usage. All over fur of scale in your kettle is not allowed!

It is recommended to clean the kettle at least 2 times a year but however until the appearance of all over scale.

ATTENTION!

• Never clean a kettle connected to mains.
• Before cleaning, disconnect the kettle and let it cool down.
• Do not use abrasive and aggressive detergents.
• Never submerge the kettle, its support, power line cord and plug in water or other liquids.

Cleaning the filter (for the models with removable filter)

-Clean the filter from lime scale with a nylon brush under a flow of water. Soak dirty filter in vinegar or special liquid for removing the scale before cleaning.

Cleaning the kettle from scale

Clean the kettle from scale with special agents sold in the open market. Cleaning from scale can be also performed by the methods described below:

METHOD 1

- Fill the kettle to maximal level with a mixture consisting of 1 part of usual vinegar and 2 parts of water. Switch on the kettle and let is boil and automatically switch off.

• Let the mixture settle during 10-12 hours and pour it out.
• Fill the kettle with fresh water up to maximal level and boil it again. Pour out this water too to remove the smell of vinegar.

-Wash the internal part of the device with clean water, wipe it and dry the kettle.

METHOD 2

• Fill the kettle with the above mentioned mixture of water and vinegar and boil it 2 or 3 times running. Rinse it with water and rub it dry.
• For usual cleaning wipe the kettle case from the inside and outside with a soft wet sponge or cloth. Soapy water can be used.
• Rinse the kettle and wipe it dry.
• Let the device get fully dry before using.
• Any other kinds of maintenance should be performed by qualified personnel in a servicing center.

Storage

- Switch off the kettle and let it completely cool before storage.

- Wipe and dry the kettle before storage.

- Do not wind the power line cord around the kettle until it is completely cooled down.

- Store the kettle in a cool, dry and clean place beyond the assess of children and people with limited physical and mental abilities.

Environmental protection

Old appliances contain valuable materials that can be recycled. Please arrange for the proper recycling of old appliances. Please dispose your old appliances using appropriate collection systems.

Subject to technical modifications!

Current electric alternativ;

Frecventa nominala: 50 Hz;

Made in P.R.C. for Maestro

Apollo Corporation Limited ADD: Unit C, 13/F.,

Charmhill Centre, 50 Hillwood Road TST., Kln., Hong Kong,
