MWP-32 - Fan MPM - Free user manual and instructions

Product Type	Fan
Brand	MPM
Model	MWP-32
Power Supply	220-240V ~ 50Hz
Power Consumption	60 W
Speed Settings	3 (Low, Medium, High)
Oscillation	Yes, 90°
Tilt Adjustment	Yes, manual tilt
Blade Diameter	32 cm
Height	130 cm (adjustable)
Weight	4.5 kg
Control Type	Manual buttons on base
Remote Control	Not included
Timer	Not available
Safety Feature	Overheat protection
Material	Plastic and metal
Color	White/Grey
Noise Level	≤ 55 dB
Cleaning	Wipe with damp cloth; detachable front grille
Spare Parts	Contact MPM support

Frequently Asked Questions - MWP-32 MPM

How do I clean my MPM MWP-32 fan?

Unplug the fan before cleaning. Use a soft damp cloth to wipe the exterior. For the blades, remove the front grille (twist to unlock) and gently clean with a damp cloth. Do not immerse in water.

Can I use the fan outdoors?

No, the MWP-32 fan is designed for indoor use only. Exposure to moisture or extreme temperatures may damage the device.

The fan is not oscillating. What should I do?

Check if the oscillation button on the base is pressed in. If it still doesn't work, ensure that the fan is on a flat surface and the base is stable. If the problem persists, contact MPM customer service.

How to adjust the height of the fan?

Loosen the height adjustment collar on the pole, slide the upper part to the desired height, then tighten the collar securely. Make sure the fan is stable before use.

What is the power consumption of the fan?

The MPM MWP-32 fan operates at a maximum power of 60 watts on the highest speed setting. Lower speeds consume less power.

Does the fan have a timer?

No, this model does not include a timer function. You can manually turn it off using the power button on the base.

Why is the fan making noise?

Check if the blades are hitting the grille or if there is any debris. Ensure all screws are tight. If noise persists, it may be due to normal operation at high speed. If excessive, contact support.

Is the fan safe to use overnight?

Yes, the fan has overheat protection. However, it is recommended to place it on a stable surface away from curtains and to not cover the fan.

Can I replace the fan blade?

Replacement blades are available through MPM. Contact authorized service centers for spare parts. Do not attempt to modify the fan.

How to store the fan in winter?

Disassemble the fan if possible, clean it, and store it in a dry place inside the original box or a protective cover to prevent dust.

USER MANUAL MWP-32 MPM

EN We wish you satisfaction from using the product and invite you to check a wide range of other MPM appliances

Yellow and black industrial fan with four blades, mounted on a stand (no visible text or symbols)

MPM agd S.A.

SICHERHEITSHINWEISE

-Read carefully this manual before using the appliance.
-Close supervision is necessary when using the appliance near children.
- Do not hang the power cord over sharp edges and do not allow the power cord to touch hot surfaces.
-Always unplug the appliance when it is not in use or before cleaning.
- Do not use the appliance if it is damaged, also if the power cord or plug is damaged - return the appliance for repair to an authorized service centre.
-To avoid the risk of damage or injury, always use the attachments recommended by the manufacturer.
- Do not immerse the appliance, its cord and plug in water or any other liquids, keep it dry at all times.
-Do not leave the appliance switched on when unattended.
-Always switch off the appliance before unplugging it.
-Do not place the appliance in vicinity of heat sources.
- Do not use the appliance for the purposes different than it was designed for.
-Do not use the appliance outdoors.
- Never insert your fingers nor any other items through the guard when the appliance is running.
-Before moving the appliance to another location disconnect it from the power source.
-Do not cover the front and rear guard!
- Do not place the appliance near open windows - raindrops may cause a short circuit and electrical shock! It is advisable not to place fans in rooms with high humidity, such as bathrooms.
- This appliance is not intended for use by individuals (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
-Children should be supervised to ensure that they do not play with the appliance.
- Do not switch on the appliance without front and rear guard mounted.

- The appliance may be switched on only after complete assembly. Partially assembled unit does not provide safe and proper operation.

-The appliance shall be plugged to an outlet with a protective earth pin.

-Do not plug the power cord with wet hands.

-This appliance is intended for household use only.

- Do not remove the plug from the mains by pulling by the cord.

- Store the appliance and its cord out of reach of children under 8 years of age.

-In order to ensure your children's safety, please keep all packaging (plastic bags, boxes, polystyrene etc.) out of their reach.

-Before removing the cover, make sure that the fan is disconnected from the power source.

- WARNING! Do not allow small children to play with the foil as there is a danger of suffocation!

DESCRIPTION OF THE APPLIANCE:

1. Base

2. Propeller with a diameter of 340 mm

3. Cover fixing screws

4. Front and rear guard

5. On/Off switch and speed controls

6. Non-slip feet

7. Hooks for coiling power cord

8. Carrying handle

9. Body rim

10. Circulator body angle adjustment knobs

USING THE APPLIANCE:

NOTE! Before switching on, make sure the circulator is placed on a flat, stable and dry surface! NOTE! Before switching on, make sure the speed of the propeller is set to '0' and then plug the power cord to the wall outlet.

1. Set the desired rotation speed using controls (5): „0” – switched off, „1” – speed I, „2” – speed II, „3” – speed III

2. The direction of air flow is adjustable:

3. vertically by tilting the body rim (9)

4. horizontally by turning the circulator cover (4) to the right or left.

5. The total height of the air circulator 470 mm.

CLEANING AND MAINTENANCE:

1. Before cleaning the appliance, unplug it from the power outlet.
2. The motor cover, controls cover (5) and the base (1) may be cleaned with a damp cloth and a mild detergent.

3. The guards (4) may be occasionally wiped with a brush to remove dust from the holes, rinse in water and dry thoroughly.

4. To clean the blades of the propeller (2) from dust, remove the front guard (4) and then remove the propeller (2) from the motor shaft, wipe it with a damp cloth and wipe dry.

Technical data sheet

MPM AGD S.A. MODEL: MWP-32
Description Symbol Value Unit
Maximum flow rate of the fan F 43,72 m			^3/min
Fan power P 42,78 W
Operating value SV 1,02 (m			^3/min)/W
Power consumption in standby mode	P_SB	0	W
Fan's sound power level	L_WA	59,7	dB(A)
Maximum air speed	c	2,753	m/s
Standards used for measuring the operational values	EN IEC 60879: 2019 EN IEC 60704-2-7:2020 EN IEC 60704-1: 2021 EN 50564: 2011
To get additional information, contact	MPM AGD S.A. ul. Brzozowa 3 Milanówek 05-822, Polska tel. [phone] BDO: 000027599

TECHNICAL DATA:

The technical parameters are given on the data plate of the product.

Length of power cord: 1,52 m

NOTE! MPM agd S.A. reserves its right to modify the technical data!

CE

Proper disposal of the product (waste electrical and electronic equipment)

Marking on the product indicates that after the service-life of the product expires, it should not be disposed with other type of municipal waste. Used equipment may have a negative impact on the environment and health of people due to potentially containing hazardous substances, mixtures and components. Mixing electric waste with other types of waste or disassembling those in an unprofessional manner may cause a release of substances that are hazardous to the environment and health. Used equipment should

be handed-over to a point for collection of electric waste. In order to obtain detailed information regarding the electric waste collection points, the user should contact the municipal point of electric waste collection or used equipment processing department.
