PA0218 - Phone Charger LOGILINK - Free user manual and instructions

Product Type	2-Port USB Wall Charger
Brand	LogiLink
Model	PA0218
Input Voltage	100-240V AC, 50/60Hz
Input Current	1A max
Output Voltage	5V DC
Output Current (Total)	2.1A max
Total Output Power	10.5W
Number of USB Ports	2
Efficiency Level	V
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 85°C
Operating Humidity	25% to 90% (non-condensing)
Storage Humidity	10% to 90% (non-condensing)
Dimensions (Diameter x Height)	045 x 63mm
Weight	40g
Package Dimensions	95 x 75 x 50mm
Package Weight	0.07kg
Protection Features	Overcurrent, overvoltage, overheating, short circuit
Charging Capability	Simultaneous charging of two devices
Travel Compatibility	Compact and portable design
Maintenance	Clean with a dry cloth. Do not use liquid or abrasive cleaners.
Safety	Do not expose to water or moisture. Use only in dry environments. Do not cover during use.
Spare Parts & Repairability	No user-serviceable parts. Do not attempt to repair. Contact manufacturer if defective.
Package Contents	1x 2-Port USB Wall Charger, 1x User Manual

Frequently Asked Questions - PA0218 LOGILINK

Can I charge my phone and tablet simultaneously?

Yes, the LogiLink PA0218 features two USB ports that allow simultaneous charging of two devices. The total output is 2.1A (10.5W), so charging speed may be shared.

Is it safe to leave the charger plugged in when not in use?

While the charger has built-in protection against overcurrent, overvoltage, overheating, and short circuits, it is recommended to unplug it when not in use to save energy and reduce risk.

What devices are compatible with this charger?

The charger is compatible with most USB-powered devices such as smartphones, tablets, Bluetooth headphones, power banks, and more. It supports a wide range of voltages (100-240V) for international use.

Is the charger suitable for international travel?

Yes, the input voltage range of 100-240V AC makes it suitable for use worldwide. However, you may need a plug adapter depending on the country's outlet type.

What protection features does the charger have?

The charger includes protection against overcurrent, overvoltage, overheating, and short circuits to ensure safe charging of your devices.

What is the maximum output current per USB port?

The total output current is 2.1A shared between both ports. If only one port is used, it can deliver up to 2.1A. When both are used, the current is split (e.g., 1.05A each).

Does this charger support fast charging?

The charger provides 5V output with a total of 2.1A (10.5W), which is standard charging speed. It does not support quick charge protocols like Qualcomm Quick Charge or USB-PD.

Is the charger energy efficient?

Yes, the charger meets Efficiency Level V standards, meaning it consumes minimal standby power and is designed for energy efficiency.

What are the dimensions and weight of the charger?

The charger has a diameter of 45mm and height of 63mm, weighing only 40g. It is compact and travel-friendly.

Does the package include a charging cable?

No, the package includes only the charger and user manual. You will need to use your own USB cables to connect your devices.

USER MANUAL PA0218 LOGILINK

Black LogiLink brand electronic device with two metallic pins (no visible text or symbols on body)

LogiLink®

2-Port USB Wall Charger, 10.5W

Art. No.: PA0218

Portable USB wall charger perfect for charging multiple USB devices simultaneously!

Simultaneous Charging

Fast Charging 2 devices with 2.1A output.

Multiple Protection

Supports overcurrent, overvoltage, overheating and short circuit protections.

Black LogiLink brand electronic device with two metallic pins (no visible text or symbols on body)

LogiLink®

2-Port USB Wall Charger, 10.5W

Art. No.: PA0218

Product display image showing a Logitunk-branded battery, smartphone, tablet, and battery pack (no text or symbols on devices)

Universal Compatibility

Suited for a wide variety of USB devices, and equipped with international voltage compatibility.

Hands placing a red NEZ water bottle into a blue backpack with a white watch and plug, placed on grass (no text or symbols visible)

Travel-Ready

The portable size fits easily in your laptop bag or backpack, making it the perfect mobile accessory for traveling.

Black LogiLink brand plug with two terminal pins (no visible text or symbols on body)

LogiLink®

2-Port USB Wall Charger, 10.5W

Art. No.: PA0218

Specifications:

Input 100-240V AC 50/60Hz 1A max.
Output 2 USB ports, 5V 2.1A (10.5W) max.
Efficiency Level V
Operating Temperature 0~40°C
Storage Temperature -40°C~85°C
Relative Humidity 25%~90% non-condensing
Storage Humidity 10%~90% non-condensing
Dimension ∅45 x 63mm
Weight 40g

Package Contents:

» 1 x 2-Port USB Wall Charger
» 1 x User Manual

Package Information:

» Packing Dimension: 95 x 75 x 50mm
» Packing Weight: 0.07kg
» Carton Dimension: 520 x 266 x 175mm
» Carton Q'ty: 40pcs
» Carton Weight: 3.5kg
