| Product Type | Digital Matrix Switcher |
| Model | Enova DVX-2210HD |
| Brand | AMX |
| Dimensions (W x H x D) | 17.0 x 3.5 x 12.0 inches (rack mount) |
| Weight | 10.0 lbs |
| Power Supply | 100-240VAC, 50/60Hz, internal |
| Video Inputs | 4x HDMI, 2x VGA, 1x Composite |
| Video Outputs | 2x HDMI, 1x VGA |
| Max Video Resolution | 1920x1200 @ 60Hz |
| Audio Support | Embedded and de-embedded, stereo analog |
| Control Interfaces | Ethernet, RS-232, IR, USB |
| Switching Function | Matrix switching with audio breakaway |
| Scaling | Built-in scaler for resolution conversion |
| Mounting | 19-inch rack mountable |
| Operating Temperature | 32-104°F (0-40°C) |
| Storage Temperature | -4-158°F (-20-70°C) |
| Humidity | 10-90% non-condensing |
| Maintenance | Clean with dry, lint-free cloth; avoid liquids |
| Safety | ESD precautions; use grounded outlets |
| Spare Parts | Contact AMX support for replacement parts |
| General Info | Professional AV switcher for commercial installations |
Frequently Asked Questions - Enova DVX-2210HD AMX
How do I connect the Enova DVX-2210HD to my display?
Use an HDMI cable from the HDMI output of the switcher to your display. Ensure both devices are powered off before connecting.
Can I control the switcher via a computer?
Yes, you can control it via Ethernet using the built-in web interface or Telnet commands. The default IP is 192.168.1.100.
What video resolutions are supported?
The device supports resolutions up to 1920x1200 at 60Hz, including standard 1080p and WUXGA.
How do I switch between inputs?
You can switch using the front panel buttons, IR remote, or via RS-232 commands. The switcher allows independent audio and video routing.
Does the switcher scale the video signal?
Yes, it features a built-in scaler that can convert input resolutions to the desired output resolution.
What audio formats are supported?
It supports embedded HDMI audio (PCM, Dolby Digital) and analog stereo audio input/output.
How do I update the firmware?
Download the latest firmware from the AMX website and upload via the web interface. Ensure a stable power supply during the update.
Is the device rack mountable?
Yes, it is designed for 19-inch rack mounting and includes rack ears.
What should I do if the device does not power on?
Check the power cable and outlet. Ensure the power switch on the rear is on. If still no power, contact AMX support.
Can I use the switcher without a network connection?
Yes, it can be controlled manually via front panel buttons or via RS-232 without a network.
