CO402E - Freezer SMEG - Free user manual and instructions

Product Type	Freezer
Brand	Smeg
Model	CO402E
Refrigerant	R600a (isobutane), environmentally friendly
Defrosting	Manual defrost required
Interior Lighting	Yes, with replaceable bulb
Temperature Control	Adjustable thermostat
Air Circulation Around Unit	Ensure free airflow for normal operation
Refrigerating Circuit	Sealed system - do not damage
Installation	Follow setting up instructions in manual
Electrical Connection	Standard household mains supply
Power Off	Has switch-off procedure
Food Storage	Frozen food compartment
Food Conservation	Advice provided for proper food storage
Cleaning	Warm water and mild detergent
Light Bulb Replacement	User-replaceable interior bulb
Troubleshooting	Defects finding guide included
Recycling Advice	Instructions for old appliance and packing disposal
Transport Instructions	Guidelines for safe transport
Warnings	Safety warnings and special advice provided

Frequently Asked Questions - CO402E SMEG

How do I defrost my SMEG CO402E freezer?

Defrosting should be done manually. Switch off the appliance, remove food and leave the door open. Do not use mechanical devices to accelerate defrosting. Follow the manual's defrosting section.

What type of refrigerant does this freezer use?

It uses R600a (isobutane), an environmentally friendly refrigerant that is flammable under certain conditions. Ensure free air circulation around the appliance and do not damage the refrigerating circuit.

How do I clean the freezer?

Clean the interior and exterior with warm water and a mild detergent. Avoid abrasive cleaners. Follow the cleaning instructions in the manual.

How do I replace the interior light bulb?

Turn off the appliance and unplug it. Replace the bulb with the same type. Refer to the 'Replacing the interior light bulb' section.

Can I use an extension cord with this freezer?

The manual does not recommend using mechanical devices or extension cords unless specified. For safety, plug directly into a properly earthed socket.

What should I do if the freezer is not cold enough?

Check the temperature control setting, ensure the door is sealed properly, and that air circulation around the appliance is not obstructed. Consult the defects finding guide.

How should I transport the freezer after moving?

Follow the transport instructions in the manual, keep it upright, and allow it to stand for a period before connecting to power (typical advice).

Can I store hot food in the freezer?

No, allow hot food to cool before placing it in the freezer to avoid raising the internal temperature and affecting other food.

How do I ensure energy efficiency?

Keep the freezer full, avoid frequent door openings, ensure proper air circulation, and set the correct temperature. Defrost regularly.

Is it safe to use electrical appliances inside the freezer?

No, do not use electric appliances inside the food storage compartment unless recommended by the manufacturer.

USER MANUAL CO402E SMEG

WARNING!

In order to ensure a normal operation of your refrigerating appliance, which uses a completely environmentally friendly refrigerant the R600a (flammable only under certain conditions) you must observe the following rules:

• Do not hinder the free circulation of the air around the appliance.
• Do not use mechanical devices in order to accelerate the defrosting, others than the ones recommended by the manufacturer.
• Do not destroy the refrigerating circuit.
  Do not use electric appliances inside the food keeping compartment, other than those that might have been recommended by the manufacturer.

ATTENTION!

Advice for recycling of the old appliance /1

Packing Recycling /2

Transport instructions /2

Warnings and special advice /2

Setting up /3

Electric connection /3

Switching off /3

Appliance description /4

Freezer operation /4

Advice for food conservation /4

Defrosting of the appliance /5

Cleaning of the appliance /4

Replacing the interior light bulb /6

Defects finding guide /6

FR

Table de matieres

Figures that take place in this instruction manual are schematic and may not correspond exactly with your product. If the subject parts are not included in the product you have purchased, then it is valid for other models.
Les illustrations présentées dans cette notice d'utilisation sont schématiques et peuvent ne pas correspondre exactement à votre produit. Si certains fonctions ne sont pas inclus dans le produit que vous avez acheté, ils concerneront d'autres modèles.
① Abbildungen und Angaben in dieser Anleitung sind schematisch und können etwas von Ihrem Gerät abweichen. Falls Teile nicht zum Lieferumfang des erworbenen Gerätes zählen, gelten sie für andere Modelle.
i Le illustrazioni contenute in questa guida sono schematiche e potrebbero non corrispondere esattamente all'apparecchio in uso. Se le parti in oggetto non sono incluse nell'apparecchio acquistato, significa che sono da intendersi per altri modelli.
As figuras que aparecem neste manual de instruções são esquemáticas e podem não corresponder exactamente ao seu produto. Se as partes referidas não estiverem incluídas no produto que adquiriu, é porque são válidas para outros modelos.
Иллюстрации в данной инструкции являются схематичными и могут отличаться от вашей модели. Если в приобретенном вами изделии нет каких-либо из показанных компонентов, значит, они используются в других моделях.
Las ilustraciones incluidas en el presente manual de instrucciones son esquemáticas y puede que no se adecúen a su aparato con exactitud. Si alguno de los elementos reflejados no se corresponde con el aparato que usted ha adquirido, entonces será válido para otros modelos.
Bilder som förekommer i den här bruksanvisningen är exempel och kanske inte överensstämmer helt med din produkt. Om delar inte medföljer produkten du har köpt så gäller det för andra modeler
Tallene i denne manual er skematiske og svarer måske ikke helt til dit produkt. Hvis delene ikke er indeholdt i det produkt, du har købt, findes de i andre modeller.
De afbeeldingen in deze gebruiksaanwijzing zijn schematisch en hoeven niet exact met uw product overeen te komen. Wanneer onderdelen niet tot het product behoren dat u hebt gekocht, gelden deze voor andere modellen.

2

3

4

5

1

2

3

4
