Product Type	Freestanding Refrigerator
Brand	Gaggenau
Model	RF471305
Dimensions (H x W x D)	1770 x 900 x 650 mm
Weight	120 kg
Power Supply	220-240 V, 50/60 Hz, 1.5 A
Energy Efficiency Class	E
Annual Energy Consumption	250 kWh
Climate Class	SN-T
Noise Level	38 dB
Total Net Capacity	400 L
Refrigerator Net Capacity	300 L
Freezer Net Capacity	100 L
Freezing Capacity	12 kg/24h
Star Rating	4
Defrost System	Automatic in refrigerator, manual in freezer
Control Type	Electronic with display
Connectivity	Home Connect (Wi-Fi)
Special Functions	SuperCool, SuperFreeze, Vacation Mode
Safety Features	Child lock, Door alarm
Maintenance & Cleaning	Cleaning with soft cloth and mild detergent
Warranty	2 years
Spare Parts Availability	10 years after model discontinuation

Frequently Asked Questions - RF471305 GAGGENAU

How do I set up the Wi-Fi connection on my Gaggenau RF471305?

Download the Home Connect app, create an account, then follow the in-app instructions. On the fridge, press S to open the main menu, navigate to Basic settings > Home network, and choose either Automatic (WPS) or Manual connection as prompted.

What should I do if the fridge does not connect to Wi-Fi?

Ensure the fridge is within range of your Wi-Fi router. Verify that the router supports WPS if using automatic mode. For manual connection, make sure your smartphone is connected to the same home network. Restart the setup process.

How can I reset the fridge's network settings?

Go to Basic settings > Home network and select Reset network settings. Confirm the action. The fridge will then restart the Wi-Fi setup.

What is the purpose of SuperCool and SuperFreeze?

SuperCool rapidly cools down the refrigerator compartment, ideal for cooling large amounts of fresh food. SuperFreeze quickly freezes items in the freezer, preserving quality and preventing existing items from thawing.

How do I activate Vacation Mode?

Press the S button, navigate to Basic settings > Vacation mode, and confirm. This sets the fridge to a power-saving temperature while you are away, keeping minimal cooling.

The display shows an error code. What does it mean?

Common error codes: E1 = temperature sensor failure; E2 = defrost heater fault. Refer to the manual for full list. If persistent, contact Gaggenau customer service.

How often should I clean the fridge and what products to use?

Clean every 2-3 months with a soft cloth and mild dish soap. Avoid abrasive cleaners. Wipe the interior with a mixture of water and vinegar to remove odors.

What is the recommended temperature for the refrigerator and freezer?

Set the refrigerator to 4°C (39°F) and the freezer to -18°C (0°F) for optimal food preservation.

Can I replace the water filter myself?

Yes, the model RF471305 has an internal water filter. Locate the filter compartment inside the refrigerator, twist the old filter counterclockwise to remove, and insert a new one until it clicks.

Where can I purchase spare parts or accessories?

Visit the Gaggenau website or authorized dealers. Spare parts are available for up to 10 years after the model is discontinued. Use the model number RF471305 for identification.

USER MANUAL RF471305 GAGGENAU

Hand holding smartphone with floating icons of kitchen appliances on a dark screen (no text or symbols)

EN Connect your refrigerator to the future. 8

Welcome to the connected home!

Congratulations on your new smart appliance with Home Connect, designed to simplify your life and make it more enjoyable.*

Home Connect helps you to manage your home appliances with ease and comfort, providing a variety of functions beyond simple remote control.

The Home Connect app gives you important and useful information about your home appliance, allowing you to customize and trigger certain functionalities and actions. Furthermore, the app offers support on how to properly maintain your home appliance and also inspires with a variety of recipes. Explore our ecosystem of partners and gain even more functionalities and services.

Home Connect opens up a world of possibilities exceeding your expectations of a home appliance.

* The availability of the Home Connect function depends on the availability of Home Connect services in your country. Home Connect services are not available in every country. You can find more information on www.home-connect.com

Explore: With the Home Connect app you can...

Manage your appliance

In the app's appliance section you have an overview of your connected home appliances, offering a variety of functions beyond simple remote control. Monitor the home appliance's progress, change or pause programs, change settings, trigger actions, and receive notifications.

Be inspired

The recipe section provides a variety of inspiring recipes, tips and videos, that will make cooking and baking even more enjoyable.

Get support

The service section gives helpful information on how to maintain and operate your home appliance properly.

Discover even more benefits

We are constantly expanding our ecosystems of partners. Please refer to www.home-connect.com for an overview of all partners.

Let's get started!

What you need

1 | Your refrigerator must be installed properly and turned on.
2 | A smartphone or tablet equipped with a current version of iOS or Android operating system.
3 | Your refrigerator within the Wi-Fi signal of your home network.
4 | The name of your Wi-Fi network (SSID) and its password (key).
5 | This installation guide.

Important information:

Data security: Home Connect values customer data, ensuring the transfer of data is encrypted. Home Connect utilizes a variety of security measures, which are periodically reviewed. For further information visit www.home-connect.com

Appliance safety: To ensure safe operation of your appliance with Home Connect functionality, please consult the safety information in the appliance instruction manual.

Step 1: Download the Home Connect app and create a user account

1 | Open the App Store (Apple devices) or Google Play Store (Android devices) on your smartphone or tablet.
2 | Search for the "Home Connect" app in the store's search and install it.

The Home Connect app:

3 | Open the app and register to create a Home Connect account.

4 | Write down your Home Connect account credentials (user account and password), you will need them later.

√ The app will guide you through the steps of adding your appliance to Home Connect. It will refer to this guide only when needed.

Step 2: Connect your refrigerator with your home network

1 | Your dishwasher must be installed properly and turned on.
2 | Open your Home Connect app to add your refrigerator.
3 | Please follow the directions in the app and refer to this guide only when prompted to by the app.

Information:

We are constantly working to improve the Home Connect app, which may lead to differences in the setup steps. Please rely on the instructions in the latest version of the Home Connect app to guide you through the setup process.

Step 2.1: Connect the refrigerator to your home network with WPS

Please enter step 2.1 only when prompted to by the app. The following steps describe operations at the home appliance itself.

1 | Press the S button to open the main menu.

2 | Press button < to scroll to the Basic settings menu item.
3 | Press button √ to open the menu item.

4 | Press button < to scroll to the Home network menu item.
5 | Press button _ to open the menu item.

√ The following message appears on the control panel of your refrigerator: Check whether a WPS function is available on the router.

6 | Press button √ to confirm.

7 | Select Automatic (WPS) to start the automatic network connection.
8 | Activate the WPS function on your home network router within the next 2 minutes.

√ The following message appears on the control panel of your refrigerator: Network connection successful.
√ The app will get notified once your refrigerator has been successfully connected to your Wi-Fi network.

9 | Follow the instructions in the app.

Information:

If the connection could not be established within 2 minutes, make sure your refrigerator is within the range of your Wi-Fi network.

For some appliances the WPS mode is also called "automatic mode".

Step 2.2: Manually connecting your refrigerator to your home network (Wi-Fi)

Please enter step 2.2 only when prompted to by the app. The following steps describe operations at the appliance itself.

1 | Press the S button to open the main menu.

2 | Press button < to scroll to the Basic settings menu item.

3 | Press button √ to open the menu item.

4 | Press button < to scroll to the Home network menu item.

5 | Press button _ to open the menu item.

√ The following message appears on the control panel of your refrigerator: Check whether a WPS function is available on the router.

6 | Press button √ to confirm.

7 | Select Manual to start the automatic network connection.

√ The following message appears on the control panel of your refrigerator: Continue with manual network connection in the app.

8 | Press button √ to confirm.

√ The appliance will open a temporary Wi-Fi network, "Home Connect" for 2 minutes.

Using this temporary Wi-Fi network, the app will transfer the name (SSID) and the password of your home network to the refrigerator, thereby enabling the refrigerator to connect to your home network.

√ The following message appears on the control panel of your refrigerator: Network connection successful.

9 | Follow the instructions in the app.

Information:

For some appliances the step-by-step mode is also called "SAP mode" or "manual mode". If the step-by-step mode does not work please check:

• Your appliance is in the range of the Wi-Fi network.
• Your smartphone/tablet is connected to your home Wi-Fi network.
• Your smartphone/tablet and appliance are connected to the same home Wi-Fi network.

Step 3: Connect your refrigerator to the Home Connect app

Please enter step 3 only when prompted to by the app. The following steps describe operations at the appliance itself.

1 | Open the Home network menu on your refrigerator.
2 | Press button < to move to menu item Connect to app.
3 | Press _ button to open the menu item.

4 | The following message appears on the control panel of your refrigerator:. Connect to mobile device.
5 | Press button √ to confirm.

√ The app will now attempt to connect to the refrigerator. The following message appears on the control panel of your refrigerator: Synchronization is running.

6 | Follow the instructions in the app to complete the process.

√ When connection is successful, the following message appears on the control panel of your refrigerator: Connection to app successful.

7 | Press button √ to confirm.

√ The following message appears in the status bar of the control panel

8 | Follow the instructions in the app.

Information:

If the connection could not be established make sure your smartphone/tablet is within range of your Wi-Fi network.

Home Connect opens up a world of possibilities exceeding your expectations of a home appliance.

To learn more about smart appliances with Home Connect and the partner ecosystem visit www.home-connect.com

Three colored circles representing documents, a kitchen, and a person (no text or symbols)

Installation instructions in other languages can be found under "Home Connect" in the instruction manual supplied with your appliance.

If you have any questions, just visit us at www.home-connect.com

Home Connect is a service of BSH Home Appliances Corporation.

Apple App Store and iOS are Apple Inc. trademarks, Google Play Store and Android are Google Inc. trademarks, Wi-Fi is a Wi-Fi Alliance trademark.
