LTV 2410 SMART - TV Trevi - Free user manual and instructions

Product Type	Smart TV
Brand	Trevi
Model	LTV 2410 SMART
Screen Size	24 inches (60 cm)
Display Type	LED LCD, 16:9 aspect ratio
Resolution	HD (1366 x 768 pixels)
Operating System	Android 14 "Down Cake"
RAM	1 GB
Internal Storage	8 GB
Tuners	DVB-T2 (terrestrial) and DVB-S2 (satellite), MPEG-2/MPEG-4
Video Codec	H.265/HEVC 10-bit
Connectivity	Wi-Fi 802.11 b/g/n, LAN RJ45
HDMI Inputs	3
USB Ports	2 (USB 2.0)
Audio Output	Digital audio output, headphone jack
Additional Features	SLEEP timer, HOTEL mode, TELETEXT
VESA Mount	100 x 100 mm
Power Supply	12V = 3A power adapter (110-240V, 50/60Hz)
Energy Consumption	18 kWh/1000h, Class E
Included Accessories	Cigarette lighter cable
Dimensions (with stand)	55.2 x 15 x 37.1 cm (L x D x H)
Package Dimensions	62.4 x 10.7 x 39 cm (L x D x H)
Colour	Black
EAN Code	8011000042121

Frequently Asked Questions - LTV 2410 SMART Trevi

How do I set up the Trevi LTV 2410 SMART TV for the first time?

Connect the power adapter and turn on the TV. Follow the on-screen setup wizard to select your language, connect to Wi-Fi or Ethernet, and sign in to your Google account to access Android TV features.

Can I connect the TV to the internet?

Yes, you can connect via Wi-Fi 802.11 b/g/n or using a LAN cable to the RJ45 port for a wired connection.

How many HDMI ports does the TV have?

The TV has 3 HDMI inputs for connecting devices like gaming consoles, Blu-ray players, or streaming sticks.

Can I use a USB drive to play media files?

Yes, plug a USB drive into one of the 2 USB 2.0 ports and navigate to the media player app to play videos, music, or view photos.

Does the TV support screen mirroring?

Yes, you can use Google Cast built-in to mirror your smartphone or tablet screen, or use third-party apps for Miracast support.

How do I mount the TV on a wall?

The TV supports VESA 100x100 mm wall mounts. Ensure you use a compatible mount and follow the mounting instructions for safety.

What is the power consumption of this TV?

The TV has an energy consumption of 18 kWh per 1000 hours, which corresponds to energy class E.

Can I use the TV in a caravan or vehicle?

Yes, the TV includes a cigarette lighter cable for use with 12V DC power supplies, making it suitable for mobile use.

How can I update the Android TV software?

Go to Settings > Device Preferences > About > System Update to check for and install the latest Android TV updates over the internet.

What should I do if the remote control stops working?

First, check the batteries. If still not working, try resetting the remote by removing batteries and pressing each button for 3 seconds. Alternatively, use the Android TV Remote Control app on your smartphone.

USER MANUAL LTV 2410 SMART Trevi

Side view of a black flat-screen TV with three legs and control buttons (no visible text or symbols)

•Smart Android TV

•OS Android 14 “Down cake”

•Schermo LED - LCD 24" (60 cm) 16:9

•Sistema Digitale Satellitare DVBS2 MPEG2 / MPEG4

•Sistema Digitale Terrestre DVBT2 MPEG2 / MPEG4

•Codec H.265 / HEVC 10 bit

•Memoria interna 8GB - RAM 1GB

•Connessione internet LAN RJ45 o Wi-Fi 802.11 b/g/n

•Digital Satellite System receiver DVB-S2 MPEG2/MPEG4

• HD DVBT-T2 tuner to receive free DVBT MPEG-2 and MPEG-4

• codec H.265 10Bit

•Internal memory 8GB - RAM 1GB

• Internet connections LAN RJ45 or Wi-Fi 802.11 b/g/n

•Function SLEEP, HOTEL, TELETEXT

-2 USB 2.0 input

•3x HDMI input

•Audio/Video

• Digital audio output, headphone socket

•Standard VESA 100x100 wall mount

•Cigarette light cable included

• Power supply: 12V = 3A power adaptor 110-240V \~50/60Hz

LTV 2410 SMART CODE / EAN

LOGISTIC INFORMATION

L 2410SM00 / EAN: 8011000042121

Shipping carton: Pcs

Shipping carton size: cm

Unit gross weight: Kg

Unit giftbox size: L 62,4 x P 10,7 x A 39 cm

Unit sizes with stand: L 55,2 x P 15 x A 37,1 cm

Colour: black

Web: www.trevi.it

E-mail: [e-mail]
