ACH301W - Mobile Device Charger GoGen - Free user manual and instructions

Product Type	Mobile Charger
Brand	GoGen
Model	ACH301W
Dimensions (approx)	5.0 x 4.5 x 2.8 cm
Weight	50 g
Material	ABS plastic
Color	White
Input Power	100-240V, 50/60Hz, 0.5A
Output Voltage	5V DC
Output Current	2.1A
Output Power	10.5W
Connector Type	USB-A (female)
Compatible Devices	Smartphones, tablets, GPS, Bluetooth devices
Fast Charging	No (standard 5V)
Protection Features	Overcurrent, overvoltage, short circuit, overheat
Operating Temperature	0°C to 40°C
Certifications	CE, RoHS
Package Contents	Charger unit, user manual
Maintenance	Wipe with dry cloth, avoid liquids
Safety Notes	Unplug when not in use, keep away from water
Repairability	Non-reparable, no spare parts available

Frequently Asked Questions - ACH301W GoGen

What devices can I charge with the GoGen ACH301W?

The GoGen ACH301W can charge any device that draws up to 2.1A via USB-A, such as smartphones, tablets, GPS units, and Bluetooth devices.

Is the GoGen ACH301W compatible with fast charging?

No, this charger provides standard 5V 2.1A output and does not support fast charging protocols like Qualcomm Quick Charge or USB Power Delivery.

Can I use the device while it is charging?

Yes, you can use your device while charging, but the charging speed may be slower if the device is under heavy use.

What is the input voltage range for the charger?

The charger accepts an input of 100-240V AC at 50/60Hz, making it suitable for use in most countries with the appropriate plug adapter.

Is it safe to leave the charger plugged in when not in use?

While the charger has protective features, it is recommended to unplug it when not in use to save energy and reduce any potential risk.

How should I clean the GoGen ACH301W charger?

Clean the charger with a soft, dry cloth. Do not use water, solvents, or abrasive cleaners, and avoid getting moisture into the ports.

Does the charger come with a USB cable?

No, the package includes only the charger unit and user manual. You will need your own USB cable to connect your device.

Can I use this charger with an iPhone?

Yes, you can charge an iPhone by connecting a Lightning cable to the charger's USB-A port.

Can I use the GoGen ACH301W abroad?

Yes, the charger supports a wide input voltage range (100-240V). You may need a plug adapter for the specific country's outlet shape.

What safety protections does the charger have?

The charger includes protections against overcurrent, overvoltage, short circuit, and overheating to ensure safe operation.

USER MANUAL ACH301W GoGen

Abstract logo with a stylized white 'S' inside a circle (no text or symbols)

GoGEN

ACH 301W

ACH 301B

Black GoGEN smartphone with three ports and a power outlet, no visible text or symbols on body

NABÍJECÍ ADAPTÉR

NABÍJACÍ ADAPTÉR

ŁADOWARKA

CHARGING ADAPER

TÖLTÖ ADAPTER

NÁVOD K POUŽITÍ

NÁVOD NA POUŽITIE

INSTRUKCJA OBSŁUGI

USER MANUAL

HASZNÁLATI UTASÍTÁS

	EN - English
Charging adapter
A	Manufacturer's name or trademark,business registration numberand address	ETA a.s., náměstí Práce 2523, 760 01 Zlín, CZ
B	Model identifier GOGACH301W, GOGACH301B
C	Input voltage 100-240 V (AC)
D	Input frequency 50/60 Hz
E	Output voltage 5.0 V (DC)
F	Output current 3.1 A
G	Output power 15.5 W
H	Average efficiency in active mode 83.2 %
I	Low load efficiency (10%) 79.1 %
J	Power consumption without load 0.07 W

ATTENTION! Read the instructions completely and carefully. They contain important notes for usage and it is part of the product. Keep this document for later look-up!

SAFETY INSTRUCTIONS

ATTENTION! Only skilled and trained electricians may disassemble and assemble the product's housing.

DANGER! Risk of life by electric shock! Avoid contacting mains voltages by all means!

ATTENTION! Risk of burning by overloading! Attend to the maximum output currents of the product before use!

DANGER! Do not use the product in case of damage, do not touch electrically live parts.

ATTENTION! Risk of short-circuit! Contacts must never be bridged! Do not put things into ventilation slots or ports! Never cover ventilation slots!

NOTICE! Indoor dry environment use, please do not use in wet or humid or get wet in the rain. Please don't use near heat source environment. Please try with dry cloth to wipe clean. Do not leave it unattended This product is not suited for children. In the product nameplate marking under the maximum load of work, don't long time overload.

DESCRIPTION AND FUNCTION

Your charging adaptor is made for charging compatible devices. Compare the specifications of your device with those of this product for being compatible.

WARRANTY AND RESPONSIBILITY

As the manufacturer has no influence on installation, warranty only applies to the product itself. The manufacturer is not liable for damages to persons or property caused by improper installation, maintenance or operation, that are not described in this manual. Do not modify or alter the product or its accessories. Do not modify or alter the product or its accessories. Any use other than described in this user's manual is not permitted and causes loss of warranty, loss of guarantee, and non-liability.

WE RESERVE THE RIGHT TO CHANGE TECHNICAL SPECIFICATIONS.

GWARANCJA I ODPOWIEDZIALNOŚĆ

To avoid danger of suffocation, keep the plastic bag away from babies And children. Do not use this bag in cribs, beds, carriages or playpens. This bag is not a toy.

Disposal of old Electrical & Electronic Equipment

This symbol on the product or on its packaging indicates that this product shall not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help

prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. The recycling of materials will help to conserve natural resources. For more detailed information about recycling of this product, please contact your local Civic Office, your household waste disposal service or the shop where you purchased the product.

Abstract logo design with white stylized 'S' inside a black circle (no text or symbols)

GoGEN

www.GoGEN.cz
