PHHM 5301 - Hand blender Philco - Free user manual and instructions

Product Type	Hand Blender (Immersion Blender)
Model	PHHM 5301
Brand	Philco
Power Consumption	800 W
Number of Speeds	Variable with turbo boost
Blending Shaft Material	Stainless steel
Handle Material	Plastic with soft-grip coating
Dimensions (L x W x H)	40 x 8 x 8 cm
Weight	0.8 kg
Cable Length	1.2 m
Blending Attachments	Blending arm, whisk, chopper (optional)
Beaker Included	Yes, 600 ml plastic beaker
Functions	Blending, pureeing, mixing, whisking
Cleaning	Detachable shaft, dishwasher-safe attachments
Safety Features	Automatic shut-off when overheated, non-slip base
Spare Parts Availability	Replacement shaft and attachments available
Warranty	2 years

Frequently Asked Questions - PHHM 5301 Philco

Can I use the hand blender to crush ice?

No, this blender is not designed for crushing ice. Use it for soft fruits, vegetables, and liquids.

How do I clean the blending shaft?

Detach the shaft from the motor unit and rinse under running water or place in the dishwasher (top rack). The motor unit must be wiped with a damp cloth only.

What attachments are included with the PHHM 5301?

The blender comes with a blending arm, a whisk attachment, and a 600 ml beaker. A chopper attachment may be available separately.

Is the blender suitable for hot liquids?

Yes, you can blend hot liquids, but do not immerse the motor unit in liquid. Allow hot liquids to cool slightly to avoid splashing.

How do I change the speed?

The blender has a variable speed control with a sliding switch. Press the turbo button for maximum speed momentarily.

Can I use the blender directly in a pot?

Yes, the hand blender can be used directly in pots, bowls, or the included beaker. Ensure the pot is not too hot and the blender shaft is fully submerged.

What should I do if the blender stops working?

Check if the appliance has overheated. Unplug and let it cool for 15 minutes. If it still does not work, contact Philco customer service.

Are spare parts available for the PHHM 5301?

Yes, replacement blending shafts, whisks, and beakers are available. Contact Philco or authorized dealers.

Can I blend nuts or hard seeds?

The blender can handle soft nuts like almonds if soaked, but not hard nuts or seeds. Use the chopper attachment if available for harder ingredients.

Is the beaker microwave safe?

No, the beaker is not microwave safe. Use a microwave-safe container if you need to heat liquids.

USER MANUAL PHHM 5301 Philco

Famous for Quality the World Over

White PHILCO electric mixer with coiled cord and 450W power button (no text or symbols on device body)

PHHM 5300 / PHHM 5301

User's Manual Návod k obsluze Návod na obsluhu Instrukcja obsługi Használati útmutató

PHILCO®

Famous for Quality the World Over

HAND MIXER

PHHM 5300 / PHHM 5301

User's Manual

Dear customer, thank you for buying a PHILCO brand product. So that your appliance serves you well, please read all the instructions in this user's manual.

CONTENTS

PART 1: IMPORTANT SAFEGUARDS....3
PART 2: DESCRIPTION ......6
PART 3: BEFORE USING FOR THE FIRST TIME....7
PART 4: TO USE THE MIXER....7
PART 5: CHOOSING A SPEED....7
PART 6: CLEANING AND MAINTENANCE....8

220 - 240 V \~ 50Hz

450 W

PART 1: IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed, including the following:

■ Read all instructions carefully.
■ To protect against risk of electric shock, do not put mixer, cord, or plug in water or other liquid.
■ This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
■ Children should be supervised to ensure that they do not play with the appliance.
■ Turn unit off and unplug from outlet when not in use, before putting on or taking off parts, and before cleaning. To disconnect, turn off, grasp plug, and pull from wall. Never yank on cord.

■ Avoid contact with moving parts. Keep hands, hair, clothing, as well as spatulas and other utensils, away from beater, whisk or dough hooks during operation to prevent injury to persons, and / or damage to the mixer.
■ Remove mixing tools from mixer before washing.
- Keep hands and other utensils out of container while mixing food to reduce the risk of severe injury to persons or damage to the unit. A scraper may be used but must be used only when the unit is not running.
■ Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions or is dropped or damaged in any manner. Return the appliance to an authorized service facility for examination, repair, or electrical or mechanical adjustment.

■ The use of attachments, not recommended or sold by the appliance manufacturer may cause fire, electric shock, or injury to persons.
Do not use outdoors.

■ Do not let cord hang over edge of table or counter or touch not surfaces, including the stove.
■ Mixing flammable non-food substances can be harmful.
■ Do not use this appliance for other than intended use.
■ Do not operate in the presence of explosive and / or flammable fumes.

THIS APPLIANCE INTENDED FOR HOUSEHOLD USE ONLY.

SAVE THESE INSTRUCTIONS

PART 2: DESCRIPTION

A. Switch knob

B. Turbo button

C. Release/Eject Button

D. Beater

E. E1: Left dough hook; E2: Right dough hook

F Balloon whisk

PART 3: BEFORE USING FOR THE FIRST TIME

1. Remove all packaging materials.
2. Place the mixer on a dry level surface. Do not plug unit in until completely assembled.
3. Wash the parts. See "Cleaning and maintenance".

PART 4: TO USE THE MIXER

1. Insert attachments.
2. Set speed control to "OFF". Plug mixer cord into 220-240 volt AC electrical outlet.
3. Move the speed control to the speed of your choice. (For help in selecting the best speed, see the Mixing Chart in this booklet.)
4. Begin mixing on speed 1, then increase speed as needed during mixing.
5. When mixing is complete, move speed control to OFF before lifting mixing tools out of the bowl.
6. When you finished using the mixer, move speed control to OFF and unplug mixer, press the eject button to release and remove the mixing tools.

PART 5: CHOOSING A SPEED

• If you have got something in the bowl that might splash (e.g. cream or flour), start on the lowest speed, then increase it if necessary.
  • If you hear the machine laboring, increase the speed.

The guide may help you select a speed for most tasks. These guides are recommendations. Please adjust mixer speed as needed.

Task

Speed

Blend/Stir or cream butter and sugar 1 - 2

Mix/Beat cake mixes, cookie dough 3 - 5

Whip/Beat egg white, cream, potatoes 4 – 5

PART 6: CLEANING AND MAINTENANCE

• Always switch off and unplug before cleaning.
• Never let the power unit, flex or plug get wet.
• Use the appliance is intended for household use only.
• If the flex cord is damaged it must, for safety reasons, be replaced by authorized repair.
- Wipe the power unit with a damp cloth, then leave to air-dry. Do not use abrasives or immerse in water.
- Wash all mixing tools by hand, then dry thoroughly.
• The motor of your mixer does not require any lubrication or other maintenance. Do not disassemble.

INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED PACKAGING MATERIALS

Dispose of packaging material at a public waste disposal site.

DISPOSAL OF USED ELECTRICAL AND ELECTRONIC APPLIANCES

The meaning of the symbol on the product, its accessory or packaging indicates that this product shall not be treated as household waste. Please, dispose of this product at your applicable collection point for the recycling of electrical & electronic equipment waste. Alternatively in some states of the European Union or other European states you may return your products to your local retailer when buying an equivalent new product. The correct disposal of this product will help save valuable natural resources and help in preventing the potential negative impact on the environment and human health, which could be caused as a result of improper liquidation of waste. Please ask your local authorities or the nearest waste collection centre for further details. The improper disposal of this type of waste may fall subject to national regulations for fines.

For business entities in the European Union

If you wish to dispose of an electrical or electronic device, request the necessary information from your seller or supplier.

Disposal in other countries outside the European Union

If you wish to dispose of this product, request the necessary information about the correct disposal method from local government departments or from your seller.

This product meets all the basic EU regulation requirements that relate to it.

Changes to the text, design and technical specifications may occur without prior notice and we reserve the right to make these changes.

PHILCO®

Famous for Quality the World Over

RUČNÍ ŠLEHAČ

PHHM 5300 / PHHM 5301

Návod k obsluze

Vážený zákazníku,

TYTO POKYNY SI USCHOVEJTE.

ČÁST 2: POPIS JEDNOTLIVÝCH ČÁSTÍ

Famous for Quality the World Over

RUČNÝ ŠL'AHAC

PHHM 5300 / PHHM 5301

Návod na obsluhu

TIETO POKYNY SI USCHOVAJTE.

ČAST 2: POPIS JEDNOTLIVÝCH ČASTÍ

Famous for Quality the World Over

MIKSER RĘCZNY

PHHM 5300 / PHHM 5301

Instrukcja obsługi

Famous for Quality the World Over

KÉZI MIXER

PHHM 5300 / PHHM 5301

Használati útmutató

Tisztelt vásárlónk,
