FDHP 202000-E - Heat gun Fieldmann - Free user manual and instructions
Find the device manual for free FDHP 202000-E Fieldmann in PDF.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product Type | Heat Gun |
| Brand | Fieldmann |
| Model | FDHP 202000-E |
| Power | 2000 W |
| Voltage | 220-240 V ~ 50/60 Hz |
| Temperature Range | 50 – 650 °C |
| Air Flow | 250 / 500 L/min (2 stages) |
| Weight | 0.8 kg |
| Dimensions (L x W x H) | 26 x 18 x 8 cm |
| Main Functions | Paint stripping, shrink tubing, drying, soldering, bending plastics |
| Heating Element | Ceramic |
| Nozzle Diameter | 30 mm (standard) |
| Overheat Protection | Yes |
| Cool-down Rest | Integrated stand |
| Power Cord Length | 2 m |
| Material | High‑impact plastic housing |
| Maintenance | Clean air vents with brush; store in dry place |
| Safety Certifications | CE, RoHS |
| Spare Parts Availability | Nozzles, heating elements (contact Fieldmann) |
| Repairability | User‑replaceable heating element and nozzle |
| Included Accessories | 3 nozzles (concentrator, reflector, flat), manual |
Frequently Asked Questions - FDHP 202000-E Fieldmann
What is the maximum temperature of the Fieldmann FDHP 202000-E heat gun?
The maximum temperature is 650 °C, adjustable from 50 °C.
Can I use this heat gun for shrink tubing?
Yes, it works well for shrink tubing. Use the concentrator nozzle and set a medium temperature (around 200-300 °C).
How do I change the temperature on this heat gun?
The temperature is adjusted using the dial on the back of the handle. Turn to the desired setting; there is no digital display.
Does the FDHP 202000-E have two speed settings?
Yes, it has a two‑stage switch for air flow: 250 L/min and 500 L/min.
What safety precautions should I take while using the heat gun?
Always wear heat‑resistant gloves and work in a well‑ventilated area. Do not aim at flammable materials. Use the cool‑down rest after use.
How do I clean the heat gun after use?
Unplug the tool and let it cool completely. Use a dry brush to remove dust from the air vents. Do not use water or solvents.
Can I replace the heating element myself?
Yes, the heating element is user‑replaceable. Disconnect the power and remove the housing screws. Contact Fieldmann for spare parts.
What nozzles are included with the heat gun?
It comes with three nozzles: a concentrator, a reflector, and a flat nozzle.
Is the heat gun suitable for paint stripping?
Yes, it is ideal for paint stripping. Use the flat nozzle and set the temperature between 300-500 °C. Keep the nozzle moving to avoid damage.
What should I do if the heat gun overheats?
The tool has overheat protection that shuts it off automatically. Let it cool for 10-15 minutes before restarting. Check for blocked vents.
