Even 1 - Treadmills Spokey - Free user manual and instructions

Product Type	Electric Treadmill
Brand	Spokey
Model	Even 1
Assembled Dimensions (L x W x H)	147 x 59 x 15 cm
Running Belt Size (W x L)	41 x 115 cm
Maximum User Weight	90 kg
Power Supply	220-240 V ~ 50/60 Hz
Speed Range	1 - 6 km/h
Speed Adjustment Steps	0.5 km/h increments
Display Type	LED Display
Display Information	Speed, Time
Connectivity	Bluetooth (GFIT app compatible)
Remote Control	Included
Folding Mechanism	Handrail folds down, transport wheels
Safety Features	Auto-stop on release, child lock (not specified but caution)
Included Accessories	Remote controller, silicone oil, 5mm wrench, 6mm wrench, multi-wrench, M6x10 screws, M6 washers, lock screws
Recommended Maintenance	Lubricate belt every 30 hours; clean belt and deck weekly; vacuum under monthly; inspect screws
Belt Adjustment	Adjust tension and centering via rear screws
Indoor Use Only	Yes
Sleep Mode	After 10 minutes of inactivity

Frequently Asked Questions - Even 1 Spokey

How do I assemble the Spokey Even 1 treadmill?

Assembly requires two people. Lift the handrail and fasten it to the main frame using the provided M6x10 screws and flat washers, then secure with lock screws. Adjust the pad holder, plug in, and power on. For folding, reverse the steps.

What is the maximum user weight for this treadmill?

The maximum user weight is 90 kg (approx. 198 lbs).

How do I connect the treadmill to the GFIT app via Bluetooth?

Download the GFIT app on your iOS or Android device. Turn on Bluetooth on your device, search for the treadmill, and select it. Open the app, press 'Connect', and start your workout. The default password is 0000.

How do I adjust the running belt if it drifts to the left or right?

Run the treadmill at 5-6 km/h without load. Use the supplied wrench to turn the rear adjustment screw on the side where the belt is drifting: 1/4 turn for left drift (see fig2) or right drift (see fig1). Let it run for 1-2 minutes, repeat until centered.

How often should I lubricate the treadmill belt?

Lubricate every 30 hours of use. Apply silicone oil to the running board while the belt is lifted, then run the machine without load for 3 minutes.

What does the LED display show?

The display shows current speed (1-6 km/h) and training time (with a glowing diode indicating which value is active).

Can I use the treadmill outdoors?

No, the treadmill is designed for indoor use only. Avoid slant surfaces, sunlight, heaters, and damp areas.

What should I do if the running belt is too tight or too loose?

If the belt is logjammed (too tight), turn both rear adjustment screws 1/2 turn clockwise to loosen. If too loose, tighten both screws evenly. Ensure the belt is centered and not slipping.

How do I clean and maintain the treadmill?

Disconnect power. Wipe the belt and deck weekly. Vacuum under the machine monthly. Check and tighten screws annually. Remove motor cover yearly to remove dust.

What safety precautions should I take?

Do not stand on the belt when starting. Keep children, elderly, and pregnant women away. Wear sports shoes. Start at low speed. Do not use near water or flammable materials. Stop if feeling unwell.

USER MANUAL Even 1 Spokey

C

D

EN INSTRUCTION

Thank you very much for purchasing our product. Please read this instruction carefully before use it and keep the instruction at proper place.

1. CAUTION

To avoid any hurts, please read this manual carefully before using.

• For safety purpose do not stand on running belt while start.
• Please stop immediately for any feeling of vomit jerky during using.
• Children elder pregnant women patients are prohibited to use the machine.

2. SAFETY NOTIICE

• Please put the machine on flat ground. It is unsuitable to put the machine at following places:
• Outdoors.(The machine is specially designed for indoor use only)
• Slant ground or slant places on balcony.
• Sunlight area or near heater

• Error may be appeared if the power is not stable. Please do not use the same socket together with computer air conditioner etc.

• It is suggested to wear sports shoes and gym suit when use the machine.

• Please increase or decrease speed slowly.
• Do not put the machine near to wet object. Error maybe caused by waterdrop.

3. CAUTION DURING USE

• If you do not feel well before using, please consult with your doctor or coach.
• It is not our company's responsibility for any improper use by user to cause body injured.
• Please place the machine on flat places. Do not locate any objects 2M behind the machine.
• Do not start the machine when it is folded.
• Waterdrop is prohibited to run into the machine, especially to motor, power line and plug.
• Danger may cause if wearing long dress or other unsuitable dresses during use.
• Encloser spaces, air uncirculated places and with flammability places are prohibited to use the machine.
• Do not put any objects on the machine.
• Please switch off all functions and pull out plug after using.
• Please make sure the running belt is fastened before using.

4. LIST OF PARTS

Nr Fittings szt.
1 remote controller 1
2 Silicone oil 1
3 5mm wrench 1
4 6mm wrench 1
5 Multi- wrench 1
6 M6*10 screws 4
7 M6 washers 4
8 Lock screws 2

5. TECHNICAL SPECIFICATIONS

• Dimensions of the assembled exercise machine:
  147 x 59 x 15cm (EVEN)
  147 x 68 x 109cm(EVEN+)
• Running belt: 41 x 115 cm
  • Maximum weight of the user - 90 kg
  • Voltage: \~ 220-240 V (50/60Hz)

6. ASSEMBLY INSTRUCTIONS (B-C) EVEN +

ATTENTION! Do not connect the device to the power source until you finish the assembly

STEP 1 Carry out the machine from the package by two persons and place it lightly on flat floor, and put other fittings beside the machine.

Lift the handrail up and fasten it to the main frame with M6*10 screws and flat washers. Lock with 2pcs lock screws.

STEP 2 Adjust the pad holder to the right angle, then plug on and turn power on to use the machine.

STEP 3 When not using the handle, unlock and

undo the screws, then lower the handrail to the initial position and lock it to the main frame.

7. FOLDING

AND TRANSPORT OF THE TREADMILL (D)

8. COUNTER

ACTIVATION

Connect the plug to the socket, the counter display turns on and the track goes into standby mode.

SLEEP MODE

After 10 minutes of inactivity, the track goes into sleep mode and the counter is turned off. Press any button to resume the track.

BUTTON FUNCTIONS

START/STOP press to start the training or a chosen programme. 3 seconds after the start, the running belt will start moving at the lowest possible speed or at the speed corresponding to a chosen programme. Press to stop the training. The treadmill will be slowing down until it stops completely.

LED display: Speed range 1 KM - 6 KM.

Press "Speed +" key, speed will go up by 0.5 km. Press "Speed -" key, speed will go down by 0.5 km.

DISPLAY INFORMATION

SPEED: current speed.

TIME: the screen displays the value marked with a glowing diode: time, during the current training session.

MEASUREMENT RANGE

Speed – adjustable between 0 and 6 km

9. BLUETOOTH GFIT

GFIT

Download app "Gfit" and login in, can control the machine on app through bluetooth

THE USE OF EQUIPMENT

Switch on the Bluetooth in the tablet, look for the equipment and press Connect.

Switch on the application GFIT, also on the tablet, and then press the "connect" button to start workout with the tablet. (Password: 0000)

10. USAGE OF SILICONE OIL

Pull up tightly of the running belt. Then put the silicone oil to running board. Then start the machine to running 3 minutes without loading. It is better to maintain like this every 30 hours working of the machine. This can save lifetime of parts properly.

11. RUNBELT ADJUSTION

1. Running belt deviate to left

Start the machine by speed at 5-6km/h without loading, use die nut to make the screw go 1/4 circle(see fig1). Then make the machine running without loading 1-2 minutes. Please adjust like this to make the belt till to mid place.

2. Running belt deviate to right

Start the machine by speed at 5-6km/h without loading, use die nut to make the screw go 1/4 circle (see fig2). Then make the machine running without loading 1-2 minutes. Please adjust like this to make the belt till to mid place.

3. Running belt logjam

If the running belt is in dead condition, use die nut to make the screw 1/2 circle both left and right till this logjam solved.

12. DAILY MAINTAINANCE

1. Please disconnect power before checking the machine or cleaning.
2. Clear belt and dial plate after use, at least once a week.
3. Check and tighten screws and spines at fixing point.
4. Vacuum under the equipment at least once a month to prevent dust from accumulating. Once a year, it is recommended to remove the cover of the engine in order to remove any dust that may accumulate there.

PL INSTRUKCJA OBSŁUGI

INFORMACE NA DISPLEJI

INFORMATIONEN AM DISPLAY

1. Bežecký pás odbieha dol'ava

Čvrsto povucite traku za trčanje. Nakon toga nanesite silikonsko ulje. Zatim pustite uređaj 3 minute bez opterećenja. Gornji postupak preporučuje se ponoviti svakih 30 sati rada uređaja. To će vam pomoći produžiti život dijelova.

11. PODEŠAVANJE TRAKE

1. Traka uređaja se naginje ulijevo

Pustite uređaj da radi brzinom 5-6 km/h bez opterećenja, koristite ključ, da zategnete vijak za 1/4 okretaja (vidi sliku 2). Zatim pokrenite uređaj bez opterećenja na 1-2 minute. Podesite tako da se traka nađe na sredini.

2. Traka uređaja se naginje udesno

Pokrenite uređaj brzinom 5-6 km/h bez opterećenja, koristite ključeve, da okrenete vijak za 1/4 okretaja (vidi sliku 1). Zatim pokrenite uređaja bez opterećenje na 1-2 minute. Podesite tako da se traka nađe u sredini

3. Blokiranje trake

U slučaju blokiranja trake, koristite ključ da okre- nete vijak za 1/2 okretaja (slika 2) ulijevo a zatim udesno da se traka odblokira.

12. DNEVNO ODRŽAVANJE
