MF 30 DV - Household Fan Master - Free user manual and instructions

Product Type	Domestic pedestal fan
Brand	Master
Model	MF 30 DV
Voltage / Frequency	~110 V / 50Hz or ~220-240 V / 50Hz
Power Consumption (Low/High)	300 / 261 W (110 V) or 324 / 278 W (220-240 V)
Current (Low/High)	2.92 / 2.54 A (110 V) or 1.4 / 1.21 A (220-240 V)
IP Rating	IP20
Fan Diameter	30 inches / 750 mm
Speed (Low/High)	1150 / 950 RPM (110 V) or 1250 / 1150 RPM (220-240 V)
Airflow (Low/High)	13680 / 12300 m³/h (110 V) or 16200 / 13680 m³/h (220-240 V)
Dimensions (W x D x H)	92 x 26 x 93 cm
Net Weight	16 kg
Number of Speeds	2 (Low / High)
Airflow Adjustment	Manual tilt adjustment (up/down)
Safety Features	Overheat automatic shut-off; thermal cut-out
Material	Plastic body and blade
Power Cord Length	Not specified; estimated ~1.8 m
Cleaning Instructions	Wipe with soft cloth; damp cloth for heavy dirt; no detergents or chemicals
Maintenance	Motor bearings permanently sealed; no lubrication required
Storage	Store in original packaging in ventilated dry area
Certifications	CE; compliant with 2006/95/EC, 2004/108/EC; EN 60335-1, EN 60335-2-80, etc.
Intended Use	Indoor domestic use only; not for outdoor, wet, or damp locations
Warranty	Not specified in manual; check retailer

Frequently Asked Questions - MF 30 DV Master

How do I adjust the airflow direction?

Tilt the fan head upward or downward manually to the desired angle. The adjustment is smooth and can be done by hand.

How do I change the fan speed?

Rotate the speed control switch to LOW or HIGH positions to select the desired air velocity.

What should I do if the fan stops suddenly?

The fan has an overheat safety cut-out device that shuts it off automatically if it overheats. Immediately unplug the fan from the power socket and allow it to cool down before reuse. If the problem persists, contact a qualified service engineer.

Can I use an extension cord with this fan?

No, do not use extension cords with this product. Always plug the fan directly into a wall outlet.

How do I clean the fan?

Turn off and unplug the fan before cleaning. Use a soft cloth to wipe off dust. For heavy dirt, use a damp cloth and then wipe dry. Do not use detergents, sprays, or chemicals as they may damage the plastic.

Does the fan require lubrication?

No, the motor bearings are permanently sealed and do not require additional lubrication.

Where should I store the fan when not in use?

Store the fan in its original packaging in a ventilated, dry area away from moisture and dust.

Is the fan safe to use outdoors?

No, this fan is designed for indoor use only. It should not be operated outside or in wet or damp locations.

What is the fan diameter?

The fan diameter is 30 inches (750 mm).

How do I dispose of the fan at end of life?

Do not dispose of the fan with household waste. Follow local regulations for separate collection of electrical and electronic products to help protect the environment.

USER MANUAL MF 30 DV Master

Pastrengo (VR) - Italy

[e-mail]

MCS Central Europe Sp. z o.o.

ul. Magazynowa 5A,

62-023 Gądki, Poland

[e-mail]

MCS Russia LLC

ul. Transportnaya 22 vl 2,

142802, Stupino, Moscow region, Russia

[e-mail]

MCS China LTD

Unit A1, No. 1515, Jinshao Rd.,

Baoshang Industrial Zone,

Shanghai, 200949, China

[e-mail]

USER AND MAINTENANCE BOOK

GB

MF 30 DV

TECHNICAL DATA

	~110 V / 50Hz ~220	-240 V / 50Hz
	300 / 261 W 324 / 278 W
	2,92 / 2,54 A 1,4 / 1,21 A
IP	20
	30" / 750 mm
	1150 / 950 RPM 1250 / 1150 RPM
	13680 / 12300 m ^3 /h 16200 / 13680 m ^3 /h
	92 x 26 x 93 cm
	16 kg

PARAGRAPH SUMMARY

1... IMPORTANT SAFETY INSTRUCTIONS
2... OPERATING INSTRUCTION
3... MAINTENANCE

▶▶ IMPORTANT SAFETY INSTRUCTIONS

CAUTION: READ AND FOLLOW ALL INSTRUCTIONS BEFORE OPERATING THIS FAN.

Use the fan only as described in this manual. Misuse may cause a fire or an electrical shock.

▶ 1. Do not operate the fan with a damaged cord or plug, after the fan malfunctions, has been dropped or damaged.
▶ 2. Close supervision is necessary when this fan is used near children, the elderly and pets.
▶ 3. Always turn the fan off after use, before cleaning, or moving location.
▶ 4. Do not insert fingers or other objects into the fan guard.
▶ 5. Do not operate the fan in areas where petrol, paint or other flammable liquids are used or stored.
▶ 6. Do not place the fan near an open flame, cooking or heating appliance, or hot surface.
▶ 7. This fan is not intended for use in wet or damp locations. Never locate the fan in an area where it may fall into a bath or other water container.
▶ 8. Always use on a dry, level surface.
▶ 9. Do not let the power cord hang over the edge of a table or counter.
▶ 10. Arrange the cord away from an area where it may be tripped over.
▶ 11. Never place the power cord under a carpet or rug.
▶ 12. To disconnect from the power supply, grip the plug and pull from the power socket. Never pull by the cord.
▶ 13. This fan should not be operated outside.
▶ 14. Do not hang or mount the fan on a wall or ceiling.
▶ 15. Do not operate without fan guard properly in place.
▶ 16. If the power cord is damaged, it must be replaced by the manufacturer or a qualified service engineer to avoid any risks to safety.

▶ OPERATING INSTRUCTION

To adjust airflow upward or downward: Tilt the fan head to the desired angle by hand easily Speed Control: Rotate SWITCH to LOW or HIGH speeds for respective air velocity.

▶ 1. After continuous operation, it is normal for the motor to feel warm when touched.
▶ 2. This fan features an overheat safety cut-out device, which will automatically shut the fan off should it overheat for any reason. If this happens immediately unplug the fan from the power socket.

▶ MAINTENANCE

▶ 1. Before cleaning turn the fan off and unplug from the power supply.
▶ 2. To clean the fan use a soft cloth to wipe off any dust. If the fan is very dirty use a damp cloth and wipe dry. Do not use any cleaning detergents, sprays or other chemicals, as they will damage the plastic.
▶ 3. Store the fan in the original packaging in a ventilated dry area.

▶ 4. The motor bearings are permanently sealed and do not require additional lubrication.

WARNING

Do not operate the fan with a damaged cord or plug, after the fan malfunctions, has been dropped or damaged.

Do not use extension cords with this product!

To reduce the risk of fire or electrical shock, do not use the product with a solid state speed control device.

CAUTION

Automatically operated device-To reduce the risk of injury disconnect from power supply before servicing.

This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use

of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.

EC DECLARATION OF CONFORMITY

declared that appliances

MF 30 DV

conform to directives

2006/95/EC; 2004/108/EC

and norms

EN 60335-1, EN 60335-2-80, EN 62233, EN 55014-1, EN 55014-2, EN61000-3-2, EN 61000-3-3

Gądki, 16-01-2013 / CE-13

Stefano Verani

CEO MCS Group

GB - Disposal of your old product

• You product is designed and manufactured with high quality materials and components, which can be recycled and reused.
• When this crossed-out wheeled bin symbol is attached to a product it means the product is covered by the European Directive 2002/96/EC.
• Please inform yourself about the local separate collection system for electrical and electronic products.
• Please act according to your local rules and do not dispose of your old product with your normal household waste. The correct disposal of your old product will help prevent potential negative consequences for the environment and human health.
