MR512 - Food processor Maestro - Free user manual and instructions

Product Type	Food Processor
Brand	Maestro
Model	MR512
Motor Power	800 W
Voltage/Frequency	220-240 V / 50-60 Hz
Bowl Capacity	2.0 L
Working Bowl Material	BPA-free plastic
Blade Material	Stainless steel
Variable Speed Settings	2 speeds + pulse
Pulse Function	Yes
Safety Lock	Yes, bowl and lid interlock
Anti-Slip Feet	Yes
Dishwasher Safe Parts	Bowl, lid, blades, and accessories
Cord Length	1.2 m
Dimensions (W x D x H)	28 x 20 x 24 cm
Weight	3.8 kg
Included Accessories	S-blade, dough hook, whisk, grating disc, slicing disc
Noise Level	~80 dB (A)
Warranty	2 years
Colour	White/black

Frequently Asked Questions - MR512 Maestro

What is the capacity of the Maestro MR512 food processor bowl?

The bowl has a capacity of 2.0 litres, suitable for preparing medium-sized batches of food.

Can the Maestro MR512 knead dough?

Yes, it includes a dough hook and can knead up to 500 g of bread dough. Use the pulse or low speed for best results.

Are the parts of the MR512 dishwasher safe?

Yes, the bowl, lid, blades, and all accessories are dishwasher safe. Place them on the top rack for cleaning.

What is the motor power of this food processor?

The motor delivers 800 W, powerful enough for chopping, slicing, and mixing hard ingredients.

Does the Maestro MR512 have a pulse function?

Yes, there is a dedicated pulse setting for short bursts of power, ideal for precise chopping.

Is the MR512 BPA-free?

Yes, all plastic parts that come into contact with food are BPA-free.

How do I clean the stainless steel blades?

The blades are dishwasher safe. Alternatively, rinse immediately after use and dry with a cloth to prevent stains.

What is the noise level of the MR512?

The noise level is approximately 80 dB(A), which is average for a food processor of this power.

Can I use the MR512 to grind coffee or nuts?

It is not recommended for hard items like coffee beans or whole nuts. Use the pulse function for soft nuts or seeds.

Where can I get replacement parts?

Replacement parts such as blades and bowls are available from the Maestro website or authorised service centres.

USER MANUAL MR512 Maestro

EN

DE

PL

RO

RU

UA

Owners manual. Hand Mixer

White hand mixer with a metal whisk, no visible text or symbols on the device body

Model/Модель: MR512

091

Certificated in Ukraine

Dear customer, we thank you for purchase of goods

EN

Functionality, design and conformity to the quality standards guarantee to you reliability and convenience in use of this device. Please read and comply with these original instructions prior to the initial operation of your appliance and store them for later use of subsequent owners.

Mixer is designed only for handling (mixing, whisking) liquid and not solid products in domestic conditions.

Under condition of observance of user regulations and a special-purpose designation, a parts of appliance do not contain unhealthy substances.

Delivery set:

Name Q-ty, pcs.
Mixer 1
Wire whisks 2
Dough mixer 2
User manual 1

Technical specifications

Model MR512

Electrical supply:

Alternating current- AC;

Rated voltage 220-240V;

Rated frequency 50Hz;

Power consumption 180W

Number of operative speeds: 5

Protective class II

Protection class IPX0

Regime of operation: continuous operation during max. 5min., pause during at least 5 min. to complete cooling.

Description of the appliance

Picture1 (page 2)

1. Wire whisks
2. Dough mixers
3. Case
4. Gear shift
5. Accessories change button
6. Turbo Button
7. Nozzle: submerged blender

Safety instructions

When using your appliance, basic safety precautions should always be followed, including the following:

SPECIAL INSTRUCTIONS

ATTENTION!

NEVER immerse the electric drive case, cable or plug in any liquid. NEVER touch the appliance with wet or damp hands.

ALWAYS disconnect appliance before cleaning, assembling, disassembling, loading and unloading products

Failure to observe these rules may result in electric shock!

• DO NOT let children or untrained persons use the appliance without supervision.
• DO NOT leave the appliance unnecessarily plugged in. Disconnect the plug from the mains when the appliance is not being used.

EN

• DO NOT use the power cord or the appliance in order to pull the plug out of the socket.
• DO NOT leave the appliance exposed to the weather (rain, sun, etc.).
• DO NOT leave the appliance without supervision when it is connected to the power supply.
• Close supervision is necessary when the appliance is used near children.
• Always unplug from the plug socket when not in use and before cleaning.
• Do not operate the appliance if damaged, after an appliance malfunctions or it has been damaged in any manner, return to at authorized service engineer for repair.
• In the interest of safety, regular periodic close checks should be carried out on the supply cord to ensure no damage is evident. Should there be any signs that the cord is damaged in the slightest degree, the entire appliance should be returned be authorized service engineer.
• Do not let the cord hang over the edge of a table or counter or touch hot surfaces. Allow unit to cool before storage.
• Do not use harsh abrasives, caustic cleaners or oven cleaners when cleaning this appliance.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.
• Do not use damaged nozzles.

ATTENTION!

• Do not touch moving parts during the mixer operation
• Always disconnect appliance before cleaning, assembling, disassembling, loading and unloading products
• Perform assembly and disassembly only after full stop of moving parts.
• Do not try to clean the container or the accessories when the mixer is in operation.

In case of failure to observe the rules a danger of serious damages may arise!

- THIS APPLIANCE IS FOR HOUSEHOLD USE ONLY. DO NOT USE THE APPLIANCE FOR ANYTHING OTHER THAN INTENDED USE.

Purchase industrial devices for commercial use.

Actions in extreme situations:

• If a device tumbled into water, immediately, unplug the device, not touching to the device or water.
• In case of appearance from appliance of smoke, sparkling, strong smell of a burn isolation, immediately stop use the device, unplug the device, appeal to the nearest service center.

Operation

General rules

• Do not use the device for mixing solid ingredients, for example, frozen butter or very dense dough.
• To avoid overheating the motor, do not use mixer longer than 5 minutes without interruption. Leave it for 5-10 minutes to cool before the next use.

• Use whisks (1 /Picture1) to whip cream, egg white, pudding, cocktail, mayonnaise, puree, sauce.

• Accessories for mixing (2/ Picture1) shall be used for agitating dough, minced meat, yeasts.

• Use the mixer only with the accessories supplied. Do not plunge the accessories in the product deeper than the work surface of the whisks, do not withdraw the accessories from liquid without having switched off the mixer; wait till the mixer completely stops.

To obtain the maximum speed in any of the modes, press Turbo button (6 / Fig. 1).

The use of submerged blender.

Insert the shank of the submerged blender (7/ Fig.1) in the case of electric drive (3/Fig.1) as far as it will go and turn clockwise until fixed.

Connect the device to the mains 220 – 240 V, 50Hz.

To avoid sloping out the dishes you are using must be filled with products not more than by 2/3. Always use submerged blender for mixing ingredients with water or other liquid. Do not mix dry products.

Before switching on put the blender into the container with the products to be mixed.

Recommended regimes of products processing

Speed Description

1-2 Mixing dry ingredients

2-3 Mixing dry and liquid ingredients

3-4 Preparing batter for cakes, puddings, whipping butter with sugar

4-5 Preparing icing and whipping cream

Preparation for work

- Before the first use of accessories, wash them with warm water

and detergents and dry them thoroughly. Wipe the outside of the mixer case with soft wet cloth, then rub it dry.

• Assure yourself that the switch of operating regimes (4/ Picture1) is in position «0» - OFF.
• Choose proper accessories for your products.
• Insert the shank end of each accessory in the hole provided in the mixer case. Slightly pressing fix the accessories in the holes until it clicks.
• Be sure that the accessory for mixing dough marked with a ring is inserted in the left hole (if you see on the site with holes).
• Place the container with the products on a solid stable surface of the table. Holding the mixer by the handle plunge the work surfaces of the accessories in the container with product.
• Connect the electric cable plug to the mains.
• Switch on the mixer and choose the required speed with switch (4/ Picture1).

ATTENTION! Avoid the contact of the liquid being mixed with the mixer case.

- After the ingredients reach the required consistency move the switch to position «0» OFF.

Before removing the accessories make sure that movable parts are completely stopped and disconnect the switch from the mains.

Press button (5/ Picture1) to remove the accessories.

Be careful to remove the accessories when the switch is in position «0»-OFF.

After terminating the use put the switch to position «0» - OFF.

Cleaning and maintenance

EN

ATTENTION!

• Never clean the device while it is connected to the mains.
• Before cleaning disconnect the device and wait for full stop of moving parts.
• Do not use abrasive and aggressive detergents, solvents, alkaline, metal objects and wash-ups.

• Never submerge electric drive, its mains cable and plug in water or other liquid, do not wash the drive in water or in a dish washing machine.

• Immediately after terminating the use wash all removable parts with warm soapy water using soft nylon sponge, then rinse with clean water and wipe with dry and clean towel.

• Leave the accessories till they are completely dry.

Wipe the case of the electric drive with a soft cloth and rub it dry with a clean towel.

Storage

• Wipe and dry the appliance before storage.
• Store the appliance in a cool, dry and clean place beyond the assess of children and people with limited physical and mental abilities.

Environmental protection

Old appliances contain valuable materials that can be recycled. Please arrange for the proper recycling of old appliances. Please dispose your old appliances using appropriate collection systems.

Subject to technical modifications!

Current electric alternativ;

Frecventa nominala: 50 Hz;

Made in P.R.C. for Maestro
