XPE-2500 - Network card / adapter Luxul - Free user manual and instructions

Product Type	Gigabit Power-over-Ethernet (PoE/PoE+) Injector
Brand	Luxul
Model	XPE-2500
Connectivity Technology	Wired
Data Transfer Rate	10/100/1000 Mbps
Power over Ethernet	IEEE 802.3af/at compliant, PoE: 15.4W, PoE+: 30W
Standards Compliance	IEEE 802.3, 802.3u, 802.3ab, 802.3af/at
Input Voltage	AC 100-240V, 0.8A, 50/60Hz
Output Voltage	51V DC, 0.6A
Output Power	PoE: 15.4W, PoE+: 30W
Number of Ports	2 x RJ45 (Data In, Data & Power Out)
Cable Type	Cat5e or better
LED Indicators	PWR (power connected), PoE (power delivery)
Maximum Distance	330 ft (100 m)
Dimensions (W x D x H)	5.25 x 2.375 x 1.3125 in (133.35 x 60.32 x 33.34 mm)
Weight (with power cord)	0.75 lb (0.34 kg)
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Operating Humidity	0% to 90% (non-condensing)
Storage Humidity	10% to 90% (non-condensing)
Green Design	Low power consumption
Installation	Plug and play
Package Contents	Injector, Power Cord, Quick Install Guide
Safety Precautions	Avoid heat, humidity, direct sunlight; ensure ventilation; check ground connection

Frequently Asked Questions - XPE-2500 Luxul

What is the Luxul XPE-2500?

The Luxul XPE-2500 is a Gigabit Power-over-Ethernet (PoE/PoE+) Injector that delivers both data and power over a single Ethernet cable to compatible devices.

What PoE standards does the XPE-2500 support?

It supports IEEE 802.3af (PoE) and IEEE 802.3at (PoE+) standards, delivering up to 15.4W or 30W respectively.

How much power can the XPE-2500 deliver?

The XPE-2500 delivers up to 15.4W for PoE devices and up to 30W for PoE+ devices, with an output voltage of 51V DC.

What is the maximum cable length for data and power?

The maximum cable length is 330 feet (100 meters) using Cat5e or better Ethernet cable.

What do the LEDs on the XPE-2500 indicate?

The PWR LED illuminates when power is connected. The PoE LED illuminates when power is being delivered to a connected 802.3af/at device.

Is the XPE-2500 plug and play?

Yes, it features simple plug-and-play installation. Just connect the power, data source, and PoE device.

What type of Ethernet cable is required?

Use Cat5e or better Ethernet cable for proper data and power transmission.

Can the XPE-2500 be used with non-PoE devices?

Yes, data will still be transferred, but the PoE LED will not illuminate and no power will be delivered.

What are the environmental operating conditions?

Operating temperature: 32°F to 104°F (0°C to 40°C). Operating humidity: 0% to 90% non-condensing.

How do I install the XPE-2500?

Connect the power cord to the injector and a grounded outlet. Connect your data source to the DATA IN port, and your PoE device to the DATA & PWR OUT port using Cat5e or better cable.

USER MANUAL XPE-2500 Luxul

Black rectangular electronic device with network ports and a logo on the front panel (no visible text or symbols on body)

Gigabit Power-over-Ethernet (PoE/PoE+) Injector

XPE-2500

Includes:

XPE-2500 Gigabit Power-over-Ethernet (PoE/PoE+) Injector

Power Cord

Quick Install Guide

GIGABIT POWER-OVER-ETHERNET (POE/POE+) INJECTOR

MODEL NUMBER: XPE-2500

No part of this publication may be modified or adapted in any way, for any purposes without permission in writing from Luxul. The material in this manual is subject to change without notice. Luxul reserves the right to make changes to any product to improve reliability, function, or design. No license is granted, either expressly or by implication or otherwise under any Luxul intellectual property rights. An implied license only exists for equipment, circuits and subsystems contained in this or any Luxul product.

DOCUMENT CONVENTIONS

The following alerts are used to indicate notable situations:

NOTE: Tips, hints, or special requirements that you should take note of.

CAUTION: Care is required. Disregarding a caution can result in data loss or equipment malfunction.

WARNING!: Indicates a condition or procedure that could result in personal injury or equipment damage.

CONTACT LUXUL

Phone: [phone]

Email Sales: [e-mail]

Email Support: [e-mail]

Product Description

The XPE-2500 Gigabit Power-over-Ethernet (PoE/PoE+) Injector is fully compliant with IEEE 802.3af/at standards. It delivers up to 30W of output power to the PoE port. When using this device, both data and electrical power can be simultaneously delivered to your 802.3af/at PoE enabled device through a single Ethernet cable. This eliminates the need of a separate power cable, makes installation easier and reduces cost.

PRODUCT FEATURES

Complies with IEEE 802.3af/at standards

Provide 10/100/1000Mbps connection rates

Simple "plug and play" installation

Delivers both data and power over a single Ethernet cable

Green design, low power consumption

Power Overload Protection

100-240 AC wide-range voltage input, 51V DC output voltage

Compact size for ease of installation

Delivers data up to 330' (100 meters) away

INSTALLATION AND SETUP

1 Setup

To avoid potential malfunction, do not expose the XPE-2500 to excessive heat, humidity, vibration or dust.
Make sure there is adequate space around the XPE-2500 for adequate ventilation and proper heat dissipation. At least 12" (30cm) is recommend.
Keep the XPE-2500 at least 12" (30cm) from any heat source
▶Avoid placement in direct sunlight.
Do not place heavy articles on the XPE-2500.
- Verify the ground connection of the power outlet is functioning properly
Check the power cord to confirm a secure connection.
Check your PoE device documentation to be sure it is 802.3af/at compatible.

2 Physical Installation

1. Connect the included power cable to the XPE-2500 power port
2. Connect the power cable to a properly grounded power outlet
3. Connect your Ethernet cable (Cat 5, or better) from your data source to the DATA IN port of the XPE-2500
4. Connect your Ethernet cable (Cat 5, or better) from the DATA & PWR OUT port of the XPE-2500 to your PoE Enabled device.

NOTE: The power and data Ethernet cable should not exceed 330' (100 meters).

HARDWARE SPECIFICATIONS

General Specifications
Standards	IEEE802.3, IEEE802.3u, IEEE802.3ab, and IEEE802.3af/ at standards
Output Voltage	51V 0.6A
Output Power	PoE: 15.4W PoE+: 30W
Input Voltage	AC100-240V 0.8A 50 60Hz
Ports	2-10/100/1000Mbps RJ451-Power Input
Cable	Cat5e or better
LEDs	PoE: Indicates power is being passed to the Connected 802.3af/at PoE devicePWR: Power is connected to the PoE Injector
Dimensions	W x D x H:5.25" (133.35mm) x 2.375" (60.32mm) x 1.3125 (33.34mm)
Weight	Item: .75 lbs (.34Kg) with power cordPackaging: 1 lbs (.46Kg)

Environmental Specifications
Operating Temp.	32°F to 104°F (0°C to 40°C)
Storage Temp.	-40°F to 158°F (-40°C to 70°C)
Operating Humidity	0% to 90% (Relative Humidity Non-condensing)
Storage Humidity	10% to 90% (Relative Humidity Non-condensing)

LED Indicators

Port/LED Function
PoE LED	On: Indicates the PoE Injector is delivering power to the connected 802.3af/at PoE enabled deviceOff: Indicates no power is being delivered to the connected deviceFlashing: An error indicating a power fault
PWR LED	On: Power is connected to the PoE InjectorOff: Injector is not receiving power
DATA & PWR OUT	Delivers power and data (via Ethernet cable) to the connected PoE enabled device
DATA IN	Connects to your data source over Ethernet cable
Power	100-240V input voltage

NOTE: If the PWR LED does not illuminate it, indicates that power may not be connected properly or the cable is loose or unplugged.

NOTE: If the injector is connected to a device and the PoE LED does not illuminate, this is an indication the connect device in not PoE enabled or not a 802.3af/at compatible device. Data will still be transferred.

LED and RJ45 connections

Power connection

Line drawing of a rectangular electronic device with a black connector and 'W' logo on top (no text or symbols beyond the label)

Sales

P: 801-822-5450

E: [e-mail]

Technical Support

P: 801-822-5450 Option 3

E: [e-mail]

Copyright and Trademark Notices

No part of this document may be modified or adapted in any way, for any purposes without permission in writing from Luxul. The material in this document is subject to change without notice. Luxul reserves the right to make changes to any product to improve reliability, function, or design. No license is granted, either expressly or by implication or otherwise under any Luxul intellectual property rights. An implied license only exists for equipment, circuits and subsystems contained in this or any Luxul product.

© Copyright 2017 Luxul. All rights reserved. The name Luxul, the Luxul logo, the Luxul logo mark and Simply Connected are all trademarks and or registered trademarks of Luxul Wireless, Inc. All other trademarks and registered trademarks are property of their respective holders.

LUX-QIG-XPE-2500-v6 0627170235

A brand of legrand®
