Product Type	Universal VPN-router with VDSL2/ADSL2+ and 802.11n WiFi
Dimensions (W x H x D)	Approximately 265 mm x 40 mm x 170 mm
Power Supply	Internal, 100-240V AC, 50-60Hz, 0.7A
Power Consumption (Idle)	Less than 5 W
Housing Material	Metal, fanless design for high MTBF
Mounting Options	Desktop or 19-inch rack (brackets included)
Ethernet Ports	5x Gigabit Ethernet (10/100/1000 Mbps), configurable as LAN/WAN
USB Ports	1x USB 2.0 host (for LTE/UMTS modem), 1x USB console (Type B)
Wireless Standards	802.11 a/b/g/n (dual-band 2.4 GHz and 5 GHz)
Maximum Wireless Data Rate	Up to 300 Mbps (40 MHz channel, 2 streams, short guard interval)
VPN Tunnels	5 IPSec tunnels included (hardware accelerated)
Firewall	Stateful Inspection Firewall with packet filtering
DSL Interface	VDSL2/ADSL2+ (Annex A), vectoring ready
Warranty	2-year manufacturer warranty with advanced replacement
Software Updates	Free-of-charge updates for BOSS and DIME Manager

Frequently Asked Questions - RS353AW Bintec

How do I reset the router to factory settings?

Press and hold the Reset button on the housing for a few seconds until the LEDs indicate a reset. This restores the default configuration.

Can I use a 4G/LTE USB modem with this router?

Yes, the router has a USB 2.0 host port that supports LTE (4G) or UMTS (3G) USB sticks for backup or remote configuration.

How many VPN tunnels are included?

The RS353AW includes 5 active IPSec tunnels with hardware acceleration. Additional tunnels may be available via PPTP, L2TP, or GRE.

Does the router support IPv6?

Yes, it is prepared for IPv6 and allows gradual migration to the new internet protocol.

What wireless standards does the router support?

It supports 802.11 a/b/g/n in both 2.4 GHz and 5 GHz bands, with MIMO 2x2 for up to 300 Mbps.

Can I mount the router in a 19-inch rack?

Yes, the package includes 19-inch brackets and screws for rack mounting. The device height is exactly one rack unit.

How do I update the router’s firmware?

Firmware updates are free and can be performed via the web-based interface (FCI) using local file upload, HTTP, TFTP, or direct download from bintec elmeg’s server.

What is the maximum wireless data rate?

With a 40 MHz channel, 2 spatial streams, and short guard interval, the raw data rate can reach 300 Mbps. At 20 MHz, up to 150 Mbps.

Is the router compatible with VDSL vectoring?

Yes, it is vectoring ready (ITU-T G.993.5) to improve VDSL2 performance.

What security features does the router provide?

It includes a Stateful Inspection Firewall, IPSec VPN with certificate support (X.509), NAT/PAT, content filtering (optional), and authentication via RADIUS.

USER MANUAL RS353AW Bintec

Universal VPN-router with VDSL2/ ADSL2+ and 11n WIFI

bintec RS353aw

• VDSL2/ ADSL2+ Modem (Annex A)
• WIFI 802.11n, 2,4 and 5 GHz
- Vectoring ready
- 5x IPSec tunnels, HW acceleration
• Prepared for IPv6
- Flexible mounting: Desktop or 19" Rack
• Stateful Inspection Firewall

Interior view of a data center with rows of server racks and tiled floor (no visible text or labels)

bintec RS353aw

Universal VPN-router with VDSL2/ ADSL2+ and 11n WIFI

--- Availability: May 2014 ---

The bintec RS353a with its combined VDSL/ADSL2+ Modem (Annex A) and dual band WIFI (802.11n) is ideal for use in home offices and at small branch locations.

Product description

The bintec RS353aw is a powerful professional VPN router for high-speed internet access. With its combination VDSL2 and ADSL 2+ modem, this model gives small and mid-sized companies the foundation they need to establish state-of-the-art, robust internet connectivity. The integrated 802.11n wireless module also provides wireless data connectivity for enterprise applications.

The RS353aw delivers advanced security, flexibility, and exceptional performance across a wide range of applications. The combination VDSL2 and ADSL2+ modem supports the Annex A standard (ADSL over POTS) according to ITU standard G992.1. The system also has a state-of-the-art dual-band wireless module which operates at 2.4 and 5 GHz. This module supports all current wireless standards including 802.11 a/b/g/n. The MIMO 2x2 technology allows for maximum raw data rates of up to 300 Mbps.

This router boasts a fan-less metal housing, offers long-term reliability for business-critical applications, and makes an ideal access router for small and mid-sized enterprises (SMEs), branch locations, and home offices.

Thanks to the included 19-inch rackmount conversion bracket, customers can easily integrate this model into 19-inch server racks or operate it on the desktop. Rack mounting is further simplified by the device height of exactly one rack unit and the integrated power supply.

In addition to the VDSL2 /ADSL2+ modem, the bintec RS353aw also provides five Gigabit Ethernet ports which can be independently configured for use in a LAN, WAN, or DMZ. The included five licenses for hardware-accelerated IPSec tunnels provide comprehensive high-speed VPN functionality and allow for secure connections to branch locations and off-site employees. An LTE(4G) or UMTS(3G) USB modem (stick) connected to the USB port can be used as a remote configuration access and as a backup interface.

With its wide range of WAN connectivity options, the RS353aw raises the bar for flexibility among access routers.

Smart design

The fan-free metal housing is a proven, rugged design that has set bintec devices apart from the competition for years. The integrated power supply and 19" conversion bracket now also make it easy to install in a 19" rack.

Maximum performance

The bintec RS353aw is based on a powerful platform with unrivaled capabilities. Customers with VDSL2 connections can double their data transfer rates by taking advantage of VDSL vectoring

technology. High speed interfaces handle heavy local network traffic with ease.

Airtight security

The bintec RS353aw not only delivers outstanding performance, it also provides a comprehensive range of security features. With five simultaneous IPSec channels available, you can establish secure links between branch locations, subsidiaries, and home offices. The integrated IPSec implementation in bintec routers allows the use of pre-shared keys as well as digital certificates as recommended by Germany's Federal Office for Information Security. This lets you use a public key infrastructure and ensures maximum security. An object-oriented stateful inspection firewall offers packet filtering to provide additional protection against attacks.

Professional management

A graphical user interface is the primary means of configuring the router. This fast, web-based interface makes it easy to set up routers using the integrated configuration wizard. Administrators can also manage the devices locally or remotely using configurable telnet, SSH, or GSM dial-in. The bintec DIME Manager is a free software tool that allows administrators to manage up to 50 devices at once.

Ready for the future

Businesses can easily integrate the RS353aw into existing company networks. This bintec router also allows for a gradual migration to the new IPv6 internet protocol. The integrated VDSL2 modem of the bintec RS353aw supports the asymmetric VDSL bandplan 998 including profiles 8b, 17a, and 30a, the standards used in Germany and most other European countries. The modem also supports automatic failover to ADSL2+. With easy migration from ADSL2+ to VDSL2 and support for VDSL vectoring, the professional-grade bintec RS353aw router is a sound investment in your organization's future.

Variants

bintec RS353aw (5510000344)

IP Access Router; Desktop device with op.19"Rack; incl. VDSL2/ADSL modem (Annex A, POTS); 11n WLAN; IPSec (5 tun.), certificates, HW encryption; 4+1 Gbit Eth.switch; USB (Typ B); USB port; no use with Deutsche Telekom equipment; german and intern.version

Features

DSL

VDSL Vectoring Vectoring ready by ITU-T G.993.5

VDSL Backward compatible to ADSL/ADSL2/ADSL2+ over POTS, Annex A

ADSL 2 / ADSL 2+ ADSL over POTS (ITU G.992.1, ITU G.922.2, ITU G.992.3, ITU G.992.5 Annex A)

DSL

VDSL VDSL2 ITU G.993.2

VDSL Profile VDSL Profile 8a, 8b, 8c, 8d, 12a, 12b, 17a, 30a

ADSL Support of Dying Gasp

ATM Support of layer 1 protocol AAL5, PVCs, RFC 1483

ATM Support of up to 7 virtual channels (VC)

ATM Support of OAM F4/F5 line monitoring

ATM Support of ATM traffic management (COS - CBR, VBR, UBR)

Wireless LAN

DTIM Period Adjustable

Advanced 11n performance Beamforming, MRC (Maximum Ratio Combining), Block-Acknowledge features

Power Management for Clients Registering of up to 250 clients simultaneously in access point mode.

Bandwidth (802.11n) 20/40 MHz (bundling of two adjoining 20 MHz channels to one 40 MHz channel)

Multi SSID Depending on the complexity of configuration up to 8 service sets per radio module, with virtual access points and own MAC address per SSID.

Country-specific settings Channel settings according regulatory domain (802.11d) permitted.

Short guard interval (802.11n) On/off switchable; increase of throughput by reduction of the guard intervals from 800ns to 400ns

Number of spatial streams 1 or 2 (802.11n)

Broadcast SSID On/off switchable

RTS/CTS RTS/CTS threshold adjustable

Transmission rate Automatic fallback or fixed transmission rate selectable

WLAN standards 802.11n (Mimo 2x3); 802.11b; 802.11g; 802.11a; 802.11h

Frequency bands 2.4 GHz 2.4 GHz Indoor/Outdoor (2412-2472 MHz) max. 100 mW EiRP. The permitted transmission power indoor/outdoor (EU) may vary in countries outside the EC.

Frequency bands 5 GHz indoor (EU) 5 GHz indoor (5150-5350 MHz) max. 200 mW EiRP allowed (Germany). The permitted transmission power may vary in other countries.

Frequency bands 5 GHz outdoor (EU) 5 GHz outdoor (5470-5725 MHz) max. 200 mW EiRP allowed (Germany). The permitted transmission power may vary in other countries.

WLAN operation WLAN Accesspoint operation

WLAN modes 2.4 GHz operation: 802.11b only; 802.11g only, 802.11b/g/n mixed; 802.11b/g/n mixed long; 802.11b/g/b mixed short; 802.11b/g/n; 802.11g/n; 802.11n only; 5 GHz Operation: 802.11a only; 802.11a/n; 802.11n only

Automatic Rate Selection (ARS) Automatic usage of the optimized data rate

Data rates for 802.11b,g (2.4 GHz) 11, 5.5, 2 und 1 Mbps (DSSS modulation); 54, 48, 36, 24, 18, 12, 9 and 6 Mbps (OFDM modulation)

Data rates for 802.11a,h (5 GHz) 54, 48, 36, 24, 18, 12, 9 and 6 Mbps (OFDM modulation)

Wireless LAN

Data rates for 802.11n (2.4 / 5 GHz)

MCS0-15 enables physical rates up to 150 Mbps at 20 MHz channels bandwidth, 2 streams, short guard interval; MCS0-15 enables physical data rates up to 300 Mbps at 40 MHz channels bandwidth, 2 streams, short guard interval

WLAN Electric Characteristics

TX power @ 5 GHz 802.11n 40 MHz	MCS0/8 19 dBm; MCS1/9 19 dBm; MCS2/10 19 dBm; MCS3/11 19 dBm; MCS4/12 19 dBm; MCS5/13 18 dBm; MCS6/14 17 dBm; MCS7/15 17 dBm
Receiver Sensitivity @ 5 GHz 802.11a/h	6 Mbps -95 dBm;9 Mbps -94dBm; 12 Mbps -93 dBm; 18 Mbps -90 dBm; 24 Mbps -88 dBm; 36 Mbps -84 dBm; 48 Mbps -82 dBm; 54 Mbps -81 dBm
TX power @ 2,4 GHz 801.11b/g 1 Mbps 19 dBm; 2 Mbps 19 dBm; 5,5 Mbps 19 dBm; 11 Mbps 19 dBm; 6 Mbps 19 dBm;9 Mbps 19 dBm; 12 Mbps 19 dBm; 18 Mbps 19 dBm; 24 Mbps 19 dBm; 36 Mbps 19 dBm; 48 Mbps 19 dBm; 54 Mbps 19 dBm
Receiver Sensitivity @ 2.4 GHz 802.11n 40 MHz	MCS0 -92 dBm; MCS1 -91 dBm; MCS2 -89 dBm; MCS3 -86 dBm; MCS4 -82 dBm; MCS5 -79 dBm; MCS6 -77 dBm; MCS7 -75 dBm; MCS8 -91 dBm; MCS9 -91 dBm; MCS10 -89 dBm; MCS11 -85 dBm; MCS12 -82 dBm; MCS13 -78 dBm; MCS14 -77 dBm; MCS15 -74 dBm
TX power @ 5 GHz 801.11a/h 6 Mbps 19 dBm;9 Mbps 19 dBm; 12 Mbps 19 dBm; 18 Mbps 19 dBm; 24 Mbps 19 dBm; 36 Mbps 19 dBm; 48 Mbps 19 dBm; 54 Mbps 19 dBm
TX power @ 2,4 GHz 802.11n 40 MHz	MCS0/8 19 dBm; MCS1/9 19 dBm; MCS2/10 19 dBm; MCS3/11 19 dBm; MCS4/12 19 dBm; MCS5/13 19 dBm; MCS6/14 19 dBm; MCS7/15 19 dBm
Receiver Sensitivity @ 2.4 GHz 802.11n 20 MHz	MCS0 -95 dBm; MCS1 -94 dBm; MCS2 -92 dBm; MCS3 -88 dBm; MCS4 -85 dBm; MCS5 -81 dBm; MCS6 -80 dBm; MCS7 -78dBm; MCS8 -95 dBm; MCS9 -94 dBm; MCS10 -91 dBm; MCS11 -87 dBm; MCS12 -84 dBm; MCS13 -81 dBm; MCS14 -79 dBm; MCS15 -77 dBm
Receiver Sensitivity @ 2.4 GHz 802.11b/g	1 Mbps -92 dBm; 2 Mbps -92 dBm; 5,5 Mbps -92 dBm; 11 Mbps -92 dBm; 6 Mbps -95 dBm;9 Mbps -95 dBm; 12 Mbps -94 dBm; 18 Mbps -92 dBm; 24 Mbps -90 dBm; 36 Mbps -85 dBm; 48 Mbps -83 dBm; 54 Mbps -80 dBm
Receiver Sensitivity @ 5 GHz 802.11n 20 MHz	MCS0 -96 dBm; MCS1 -93 dBm; MCS2 -91 dBm; MCS3 -88 dBm; MCS4 -85 dBm; MCS5 -81 dBm; MCS6 -79 dBm; MCS7 -77 dBm; MCS8 -94 dBm; MCS9 -92 dBm; MCS10 -90 dBm; MCS11 -87 dBm; MCS12 -84 dBm; MCS13 -80 dBm; MCS14 -78 dBm; MCS15 -76 dBm
TX power @ 2,4 GHz 802.11n 20 MHz	MCS0/8 19 dBm; MCS1/9 19 dBm; MCS2/10 19 dBm; MCS3/11 19 dBm; MCS4/12 19 dBm; MCS5/13 19 dBm; MCS6/14 19 dBm; MCS7/15 19 dBm
Receiver Sensitivity @ 5 GHz 802.11n 40 MHz	MCS0 -91 dBm; MCS1 -89 dBm; MCS2 -87 dBm; MCS3 -84 dBm; MCS4 -81 dBm; MCS5 -78 dBm; MCS6 -76 dBm; MCS7 -74 dBm; MCS8 -90 dBm; MCS9 -89 dBm; MCS10 -87 dBm; MCS11 -83 dBm; MCS12 -80 dBm; MCS13 -77 dBm; MCS14 -75 dBm; MCS15 -73 dBm
TX power @ 5 GHz 802.11n 20 MHz	MCS0/8 23 dBm; MCS1/9 23 dBm; MCS2/10 22 dBm; MCS3/11 21 dBm; MCS4/12 20 dBm; MCS5/13 19 dBm; MCS6/14 18 dBm; MCS7/15 18 dBm

Routing

RIP Support of RIPv1 and RIPv2, separated configurable for each interface

Multicast IGMP Proxy For easy forwarding of multicast packets via dedicated interfaces

Extended RIP Triggerd RIP updates according RFC 2091 and 2453, Poisened Rerverse for a better distribution of the routes; furthermore the possibility to define RIP filters for each interface.

Routing

Multicast inside IPSec tunnel Enables the transmission of multicast packets via an IPSec tunnel

Policy based Routing Extended routing (Policy Based Routing) depending of different criteria like IP protocols (Layer4), source/destination IP address, source/destination port, TOS/DSCP, source/destination interface and destination interface status

Multicast IGMP Support of Internet Group Management Protocol (IGMP v1, v2, v3) for the simultaneous distribution of IP packets to several stations

Protocols / Encapsulations

PPPoA Point to Point Protocol over ATM for establishing of PPP connections via ATM/DSL

DYN DNS Enables the registering of dynamic assigned IP addresses at adynamic DNS provider, e.g. for establishing of VPN connections

MLPPPoE (Server/Client) Multilink extension MLPPPoE for bundeling several PPPoE connections (only if both sides support MLPPPoE)

DHCP DHCP Client, Server, Proxy and Relay for simplified TCP/IP configuration

DNS DNS client, DNS server, DNS relay and DNS proxy

PPP/MLPPP Support of Point to Point Protocol (PPP) for establishing of standard PPP connections, inclusive the Multilink extension MLPPP for the bundeling of several connections

IPoA Enables the easy routing of IP via ATM

DNS Forwarding Enables the forwarding of DNS requests of free configurable domains to assigned DNS server.

Packet size controlling Adaption of PMTU or automatic packet size controlling via fragmentation

PPPoE (Server/Client) Point-to-Point Protocol over Ethernet (Client and Server) for establishing of PPP connections via Ethernet/DSL (RFC 2516)

Quality of Service (QoS)

TCP Download Rate Control For reservation of bandwidth for VoIP connections

Layer2/3 tagging Conversion of 802.1p layer 2 priorisation information to layer 3 diffserv attributes

DiffServ Priority Queuing of packets on the basis of the DiffServ/TOS field

Policy based Traffic Shapping Dynamic bandwidth management via IP traffic shaping

Bandwidth reservation Dynamic reservation of bandwidth, allocation of guaranteed and maximum bandwidths

Redundancy / Loadbalancing

BRRP Optional: Bintec Router Redundancy Protocol for backup of several passive or active devices with free selectable priority

BoD Bandwidth on Demand: dynamic bandwidth to suit data traffic load

Redundancy / Loadbalancing

VPN backup Simple VPN backup via different media. Additional enables the bintec elmeg interface based VPN concept the application of routing protocols for VPN connections.

Load Balancing Static and dynamic load balancing to several WAN connections on IP layer

Layer 2 Functionality

Proxy ARP Enables the router to answer ARP requests for hosts, which are accessible via the router. That enables the remote clients to use an IP address from the local net.

VLAN Support of up to 256 VLAN (Virtual LAN) for segmentation of the network in independent virtual segments (workgroups)

Bridging Support of layer 2 bridging with the possibility of separation of network segment via the configuration of bridge groups

Interfaces

VDSL2/ ADSL 2+/ ADSL xDSL over POTS

Ethernet 5 x 10/100/1000 Mbps Ethernet Twisted Pair, autosensing, Auto MDI/MDI-X, up to 4 ports can be switches as additional WAN ports incl. load balancing, all Ethernet ports can be configured as LAN or WAN.

USB 2.0 host USB 2.0 full speed host port for connecting LTE(4G) or UMTS(3G) USB sticks (supported sticks: see www.bintec-elmeg.com)

USB-Console Service-Interface USB 2.0 plug B (driver: see www.bintec-elmeg.com)

Hardware

Status LEDs Power, Status, 10 * Ethernet, VDSL, WLAN, USB

Realtime clock System time persists even at power failure for some hours.

Wall mounting Integrated in housing

Desktop operation Possible, rubber pad included the package

Environment Temperature range: Operational 0°C to 40°C; storage -25°C to 70°C; Max. rel. humidity 10 - 95% (non condensing)

Protection Class IP20

Power supply Internal power supply 100-240V / 50-60Hz; 0,7 A, with energy efficient switching controller; complies with EuP directive 2008/28/EC

Power consumption (idling) Less than 5 Watt

Housing Metal case, opening for Kensington lock, prepared for wall mounting

Dimension Ca. 265 mm x 40 mm x 170 mm (W x H x D)

Fan Fanless design therefor high MTBF

Reset button Restart or reset to factory state possible

Standards and certifications

R&TTE directive 1999/5/EG; EN 55022; EN 55024 + EN 55024/A1; EN61000-3-2; EN 61000-3-3; EN 61000-4-4; EN 60950-1; EN 300 328; EN 301 489-17; EN 301 489-1; EN 301 893

Content of Delivery

Ethernet cable 1 Ethernet cable, 2m

Safety Instructions Safety Instructions

Power cable Netzstecker 100-240V / 12 V DC, 1.5 A, with high efficient switching controller

Installation Poster Guide for the Installation

19" brackets and screws Two 19" brackets for the switch panel mounting

VDSL/ADSL cable VDSL/ADSL cable (RJ45-RJ11), 3m

Service

Warranty 2 year manufacturer warranty inclusive advanced replacement

Software Update Free-of-charge software updates for system software (BOSS) and management software (DIME Manager)

VPN

Number of VPN tunnels Inclusive 5 active VPN tunnels with the protocols IPSec, PPTP, L2TP and GRE v.0 (also in combination possible)

PPTP (PAC/PNS) Point to Point Tunneling Protocol for establishing fo Virtual Privat Networks, inclusive strong encryption methods with 128 Bit (MPPE) up to 168 Bit (DES/3DES, Blowfish)

GRE v.0 Generic Routing Encapsulation V.0 according RFC 2784 for common encapsulation

L2TP Layer 2 tunnelling protocol inclusive PPP user authentication

IPSec Internet Protocol Security establishing of VPN connections

IPSec Algorithms DES (64 Bit), 3DES (192 Bit), AES (128,192,256 Bit), CAST (128 Bit), Blowfish (128-448 Bit), Twofish (256 Bit); MD-5, SHA-1, RipeMD160, Tiger192 Hashes

IPSec hardware acceleration Integrated hardware acceleration for IPSec encryption algorithms DES, 3DES, AES

IPSec IKE	IPSec key exchange via preshared keys or certificates
IPSec IKE Config Mode	IKE Config Mode server enables dynamic assignment of IP addresses from the address pool of the company. IKE Config Mode client enables the router, to get assigned dynamically an IP address.

IPSec IKE XAUTH (Client/Server)

Internet Key Exchange protocol Extended Authentication client for login to XAUTH server and XAUTH server for logging of XAUTH clients

IPSec IKE XAUTH (Client/Server)

Inclusive the forwarding to a RADIUS-OTP (One Time Password) server (supported OTP solutions see www.bintec-elmeg.com).

IPSec NAT-T

Support of NAT-Traversal (Nat-T) for the application at VPN lines with NAT

IPSec IPComp

IPSec IPComp data compression for higher data throughput via LZS

VPN

IPSec certificates (PKI)	Support of X.509 multi-level certificates compatible to Microsoft and Open SSL CA server; upload of PKCS#7/8/10/12 files via TFTP, HTTP, HTTP, LDAP, file upload and manual via FCI
IPSec SCEP Certificates management via SCEP (Simple Certificate Enrollment Protocol)
IPSec Certificate Revocation Lists (CRL)	Support of remote CRLs on a server via LDAP or local CRLs
IPSec Dead Peer Detection (DPD)	Continuous control of IPSec connection
IPSec dynamic IP via ISDN Transmission of dynamic IP address in ISDN D or B channel; free-of-charge licence necessary
IPSec dynamic DNS Enables the registering of dynamic IP addresses by a dynamic DNS provider for establishing a IPSec connection.
IPSec RADIUS Authentication of IPSec connections at a RADIUS server. Additionally the IPSec peers, which were configured on a RADIUS server, can be loaded into the gateway (RADIUS dialout).
IPSec Multi User Enables the Dial-in of several IPSec clients via a single IPSec peer configuration entry
IPSec QoS The possibility to operate Quality of Service (traffic shaping) inside of an IPSec tunnel
IPSec NAT By activating of NAT on an IPSec connection it is possible, to implement several remote locations with identical local IP address networks in different IP nets for the VPN connection
Number of IPSec tunnels Inclusive 5 active IPSec tunnels

Security

NAT/PAT Symmetric Network and Port Address Translation (NAT/PAT) with randomly generated ports inclusive Multi NAT (1:1 translation of whole networks)
Policy based NAT/PAT	Network and Port Address Translation via different criteria like IP protocols, source/destination IP Address, source/destination port
Policy based NAT/PAT For incoming and outgoing connections and for each interface variable configurable
Content Filtering Optional ISS/Cobion Content filter (30 day test license inclusive)
Stateful Inspection Firewall	Packet filtering depending on the direction with controlling and interpretation of each single connection status
Packet Filter Filtering of IP packets according to different criteria like IP protocols, source/destination IP address, source/destination port, TOS/DSCP, layer 2 priority for each interface variable configurable

Logging / Monitoring / Reporting

Internal system logging	Syslog storage in RAM, display via web-based configuration user interface (http/https), filter for subsystem, level, message
External system logging Syslog, several syslog server with different syslog level configurable
E-Mail alert Automatic E-Mail alert by definable events
SNMP traps	SNMP traps (v1, v2, v3) configurable
IPSec monitoring	Display of IPSec tunnel and IPSec statistic; output via web-based configuration user interface (http/https)

Logging / Monitoring / Reporting

Interfaces monitoring Statistic information of all physical and logical interfaces (ETH0, ETH1, SSIDx, ...), output via web-based configuration user interface (http/https)

IP accounting Detailed IP accounting, source, destination, port, interface and packet/bytes counter, transmission also via syslog protocol to syslog server

RADIUS accounting RADIUS accounting for PPP, PPTP, PPPoE and ISDN dialup connections

Keep Alive Monitoring Control of hosts/connections via ICMP polling

Tracing Traces can be stored in PCAP format, so that import to different open source trace tools (e.g. wireshark) is possible.

Tracing Detailed traces can be done for different protocols e.g. ISDN, PPPoE, ... generation local on the device and remote via DIME Manager

Administration / Management

RADIUS Central check of access authorization at one or several RADIUS server, RADIUS (PPP, IPSec inclusive X-Auth and login authentication)

RADIUS dialout On a RADIUS server configured PPP und IPSec connection can be loaded into the gateway (RADIUS dialout).

TACACS+ Support of TACACS+ server for login authentication and for shell comando authorization

Time synchronization The device system time can be obtained via ISDN and from a SNTP server (up to 3 time server configurable). The obtained time can also be transmitted per SNTP to SNTP clients.

Automatic Time Settings Time zone profiles are configurable. That enables an automatic change from summer to winter time.

Supported management systems DIME Manager, XAdmin

Configurable scheduler Configuring of time and event controlled tasks, e.g. reboot device, activate/deactivate interface, activate/deactivate WLAN, trigger SW update and configuration backup

Configuration Interface (FCI) Integrated web server for web-based configuration via HTTP or HTTPS (supporting self created certificates). This user interface is by most of bintec elmeg GmbH products identical.

Software update Software updates are free of charge; update via local files, HTTP, TFTP or via direct access to the bintec elmeg web server

Remote maintenance Remote maintenance via telnet, SSL, SSH, HTTP, HTTPS and SNMP (V1,V2,V3)

GSM remote maintenance Remote maintenance via GSM login (external USB UMTS (3G) modem required)

Device discovery function Device discovery via SNMP multicast.

On The Fly configuration No reboot after reconfiguration required

SNMP SNMP (v1, v2, v3), USM model, VACM views, SNMP traps (v1, v2, v3) configurable, SNMP IP access list configurable

SNMP configuration Complete management with MIB-II, MIB 802.11, Enterprise MIB

Configuration export and import Load and save configurations, optional encrypted; optional automatic control via scheduler

SSH login Supports SSH V1.5 and SSH V2.0 for secure connections of terminal applications

Administration / Management

HP OpenView Integration into Network Node Manager

XAdmin Support of XAdmin roll out and configuration management tool for larger router installations (IP+ISDN+GSM)

Configuration via USB Configuration interface is available

Accessoires

Software Licenses

VDSL License RS353ax (Annex A)(5500001622)	VDSL license for RS353a/aw (Annex A, ADSL over POTS)
BRRP-RS123x/RS35x-Series (5500001630)	Software License for bintec Router Redundancy Protocol (BRRP) for RS123x and RS35x-series
Cobion Content Filter Small (80551)	Cobion content filter for RSxxx, Rxx02, RTxx02 series; R230a(w), R232b(w), TR200, R1200(w/wu), R3000(w), R3400, R3800, R232aw, RV-Series; list price for one year

Pick-up Service / Warranty Extension

Service Package 'small' (5500000810)

Warranty extension of 3 years to a total of 5 years, including advanced replacement for bintec elmeg products of the category 'small'. Please find a detailed description as well as an overview of the categories on www.bintec-elmeg.com/servicepackages.

Product Services

HotSpotHosting 2yr 1 location (5500000861)	HotSpot solution hosting fee for 2 year and 1 location
HotSpotHosting 1yr 1 location (5510000198)	HotSpot solution hosting fee for 1 year and 1 location
Additional HotSpot location (5510000199)	Additional location for the HotSpot solution (551000198, 5500000861) valid for one year

Add-ons

bintec 4GE-LE (5530000119)

LTE (4G)/UMTS (3G) extension device for router; 1x Gbit Eth; Simcard slot; Wallmounting; PoE Injector inclusive
