Brand	KitSound
Model	Soul
Product Type	Portable Bluetooth Speaker
Dimensions (W x H x D)	225 x 115 x 53.5 mm
Weight	1.0 kg
Power Input	USB DC 5 V
Battery Type	Built-in rechargeable lithium battery
Charging Time	Approximately 4 hours
Playback Time	Up to 10 hours (at medium volume)
Bluetooth Version	v2.1
Bluetooth Range	Up to 10 m
Driver Size	50 mm
RMS Power Output	2 x 3 W
Frequency Range	90 Hz - 20 kHz
Controls	Volume dial (push for play/pause, press & hold for on/off and pairing)
Connectivity	Bluetooth, 3.5 mm aux-in
Hands-free Calling	Yes (press volume dial to answer/end call)
Materials	Untreated wood cabinet, leather handle
Box Contents	Soul speaker, leather handle, screwdriver, 2 screws, instruction manual
Care Instructions	Wipe with soft dry cloth; avoid water and damp environments

Frequently Asked Questions - Soul KitSound

How do I charge the KitSound Soul speaker?

Connect the USB power cable to the charging port on the unit and the other end to a PC or USB mains charger. The LED turns orange during charging and turns off when fully charged. Full charge takes about 4 hours.

How long does the battery last?

The battery provides up to 10 hours of playback time at medium volume. Actual playback time may vary depending on volume level and music type.

How do I pair the Soul with my phone via Bluetooth?

Press and hold the volume dial until the green light flashes and you hear a beep. On your phone, enable Bluetooth, search for devices, select 'Soul', and if prompted enter passcode '0000'.

Can I use the speaker while it is charging?

Yes, you can use the speaker while it is connected to a power source, but it is recommended to let it charge fully for optimal battery life.

How do I answer a call with the Soul speaker?

When a call comes in, press the volume dial down once to answer. Press it again to end the call. The speaker supports hands-free calling via Bluetooth.

Can I connect a non-Bluetooth device?

Yes, use a 3.5 mm aux-in cable to connect devices via the aux-in socket at the bottom of the unit. Plugging in the aux cable disconnects Bluetooth; unplugging resumes it.

How do I attach the leather handle?

Line up the holes on the handle with the screw holes on the speaker. Loosely tighten the two supplied screws using the included screwdriver, then tighten firmly until the handle does not rotate under mild force.

How should I clean and maintain the Soul speaker?

Wipe the unit with a soft dry cloth. Do not use wax, polish sprays, or abrasive cleaners. Avoid getting water or liquids on or inside the unit as the untreated wood can warp.

Is the Soul speaker waterproof?

No, the Soul is not waterproof. The cabinet is made from untreated wood, so it should be kept away from water and damp environments to prevent warping.

What is the Bluetooth range of the Soul?

The Bluetooth range is up to 10 meters (approximately 33 feet) in open space. Walls and obstacles may reduce the effective range.

USER MANUAL Soul KitSound

Exterior view of a beige portable electronic device with perforated grille and handle (no visible text or symbols)

Close-up of a multi-subset audio amplifier with multiple input knobs and capacitors (no visible text or labels)

We are craftspeople. We are musicians. We are KitSound "And we all commit ourselves to achieving one shared goat: Bringing people closer to their music. By truly understanding music we stay true to its craft. Pure, rich, incredible sound. We'll settle for nothing less."

At KS we believe your music deserves to be showcased on great quality products that don't cost the earth. We might not all share the same taste in music (the ferocious disputes on music forums prove that), but whether it's Irish folk, death metal or any number of obscure genres which seem to be multiplying by the minute, the artists responsible for connecting with you through their craft have bared their souls to do so. And we think that's worth celebrating.

Crowd of people raising hands at a concert with stage lighting (no visible text or symbols)

Charging the battery

The unit has a built-in rechargeable lithium battery.

Connect one end of the USB power cable to the charging port of the main unit and connect the other end to your PC or USB output mains charger. The battery will start charging.

Note:

• It takes approx. 4 hours to fully charge the battery
• Whilst charging, the LED will turn orange
• When fully charged, the LED will turn off
• A fully charged unit has up to 10 hours' of playback time

*At medium volume. Actual playback time will vary depending on volume and type of music played.

Attaching the handle

There are 2 screws supplied with the handle to attach it to the Soul.

Please follow these instructions:

1. Line up the hole on one side of the handle with one of the screw holes on the Soul.
2. Using the supplied screwdriver, loosely tighten the screw.
3. Follow steps 1 and 2 for the other side.
4. Tighten up both screws until the handle does not rotate under mild force.

Bluetooth pairing

Press and hold down the volume dial until the green light starts to flash and a beep is heard. When the green light is flashing, it means the Soul is in pairing mode. Go to the Bluetooth menu on your phone and make sure Bluetooth is switched on. Then search for new devices and 'Soul' should appear in the list. Select this and if asked for a passcode, enter '0000'. The Soul will then be paired to your device.

When turning the speaker back on again, it will automatically search for and connect to any paired devices within range. If no devices are found, the Soul will remain in pairing mode until a device is connected or the Soul is switched off.

Using the speaker

1. Turn on Press and hold down the volume dial until the green light comes on
2. Turn off Press and hold down the volume dial until the green light goes off
3. Volume + Twist the volume dial in a clockwise direction
4. Volume - Twist the volume dial in an anti-clockwise direction
5. Play/Pause Press down (do not hold) the volume dial

* This feature is only available if you phone supports Bluetooth profile AVRCP.

Check your handset/tablet manual if unsure.

Aux-in

Use a 3.5 mm aux-in cable to connect your Bluetooth speaker through the aux-in socket at the bottom of the unit.

Note:

When you plug the aux-in cable into the aux-in socket, the current Bluetooth connection will disconnect. When you unplug the aux-in cable, the Bluetooth connection will resume.

Hands-free

The Soul supports hands-free calling. When receiving a call, press the volume dial down (do not hold) to answer to call. To end a call, press the volume dial down again.

Care and maintenance

Wipe the unit with a soft dry cloth. Do not use any wax, polish sprays or abrasive cleaners.

Caution:

Never allow any water or other liquids to get on or inside the unit. The Soul is made from untreated wood so if it gets wet it will warp over time. Please do not store the Soul in a damp place as this will have the same effect as getting it wet.

Specifications

• Bluetooth v2.1
• Range: Up to 10 m
  • Power input: USB DC 5 V
• Driver size: 50 mm
  • RMS: 2 x 3 W
  • Frequency Range: 90 Hz - 20 kHz
• Unit size: W225 x H115 x D53.5 (mm)
• Weight: 1.0 kg

Box contents

• Soul wooden Bluetooth speaker
• Leather handle
• Screwdriver
• 2 screws
• Instruction manual
