Product Type	Stand Mixer (Blender)
Model	24001
Brand	KORONA
Power	600 W
Voltage	220-240 V ~ 50/60 Hz
Jug Capacity	1.5 L
Jug Material	Glass
Blade Material	Stainless steel
Speed Settings	2 speeds (Low, High) + Pulse (Ice Crush / Turbo)
Safety Features	Safety button, safety interlock
Continuous Operation Time (CO-Time)	1 minute
Cooling Time	3 minutes after 1 min use; 15 minutes after 3 cycles
Removable Lid with Cap	Yes, for adding ingredients during operation
Turbo Pulse Function	Yes (hold switch in Pulse position)
Ice Crush Function	Yes (Pulse position)
Cleaning Method	Hand wash only; autoclean function with water
Dishwasher Safe	No
Guarantee	2 years
Disposal	WEEE compliant, recycle separately
Accessories Included	Mixing attachment (pre-installed)

Frequently Asked Questions - 24001 KORONA

How do I install the mixing jug on the engine block?

Ensure the appliance is switched off (0-position). Place the mixing attachment (10) on the housing so the green arrow on the housing is above the open lock on the engine block. Turn it clockwise until the green arrow is above the locked lock. The mixing attachment is now locked. If not installed correctly, the blender will not start.

Why won't my blender start?

The blender will not start if the mixing jug is not installed correctly or if the safety button is not engaged. Make sure the glass jug (3) is properly locked onto the engine block and the speed control switch (8) is turned to a speed setting. The safety button (9) must be pressed if applicable.

What is the maximum capacity of the jug?

The maximum capacity of the glass jug is 1.5 liters. For liquid ingredients, do not fill above 1 liter to avoid overflow due to the mixing motion. For solid ingredients, fill only half full.

Can I blend hot liquids?

No, never use boiling liquids. Allow them to cool to lukewarm before blending to avoid serious burns. Only fill the mixing jug half full with hot liquids.

How do I crush ice cubes?

Add up to 8 ice cubes to the jug and close both lids. Hold the speed control switch (8) in the Pulse position for a few seconds, then release to the 0-position. Repeat until the ice is crushed to your preference. Only add ice when the engine is off.

How should I clean the blender?

Switch off and unplug. Clean the engine block with a damp cloth. The glass jug (3) and lids (1,2) can be washed with warm water and dishwashing liquid. Use the autoclean function: fill water in the jug and run on Pulse for a few seconds. The blades are very sharp; remove them carefully for cleaning. Do not put any parts in the dishwasher.

Can I wash the parts in a dishwasher?

No, the appliance and accessories are not dishwasher safe. Clean them individually by hand with warm water and mild detergent, then dry completely.

How long can I operate the blender continuously?

The maximum continuous operation time is 1 minute. After that, let the blender cool for 3 minutes before using again. This can be repeated 3 times, after which a 15-minute cooling period is required to prevent motor damage.

What is the safety button for?

The safety button (9) is an interlock that prevents the blender from starting unless the glass jug (3) is correctly installed on the engine block. This ensures safe operation.

How do I remove the blade for cleaning?

First, remove the mixing attachment (10) from the engine block by lifting it straight up. Then, turn the blades clockwise to unscrew them from the block. Caution: The blades are very sharp. Clean them carefully and reassemble by reversing the steps.

USER MANUAL 24001 KORONA

Glass of pink beverage with strawberries on top, surrounded by fresh strawberries and a green leaf (no text or symbols)

CE

Standmixer

24001

Produktbeschreibung

Close-up of a mechanical component with labeled parts 4 and 5, showing internal structure (no text or symbols beyond labels)

Close-up of a white ceramic kitchen appliance with a lock and directional arrows (no text or symbols visible)

Sicherheitsschalter

Close-up of a white plastic kitchen brush and a circular ring on a textured surface (no text or symbols visible)

Entsorgungshinweise

1 Removable lid for adding ingredients
2 Lid
3 Glass mixing jug
4 Sealing ring
5 Blade
6 Plastic housing
7 Engine block
8 Speed control switch
9 Safety button
10 Mounted mixing attachment (If the appliance is delivered, the mixing attachment is already mounted)
11 Turbo pulse function
12 Power cord and plug

Intended use

Before use, please read these instructions carefully and keep them in a safe place for future reference. When passing on the appliance to a third party, make sure to include these instructions for use.

This appliance is only intended and suitable for use as described in this manual. All other use or modification of the appliance is not intended by the manufacturer and might entail a risk of damage or injury. This appliance is not intended for commercial use!

Please follow the safety instructions to prevent any risk or danger caused by the use of electric appliances.

General Safety Instructions

Manufacturer takes no responsibility for any damage caused by incorrect use.

Incorrect or improper use can damage the appliance and cause injuries to the user.

Before connecting this appliance to the mains, make sure your local voltage matches the technical data of the appliance. Otherwise the appliance may overheat and get damaged.

Caution! Danger of electric shock!

• Never put the appliance, cord or plug into water or any other liquid.
• Do not use the appliance near a sink or wash basin.
• Do not use the appliance with wet hands.
• Do not use the appliance outdoors.

An electric appliance is not a toy!

• Never leave the appliance unattended during use.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.
  • Always unplug your appliance when it is not in use, and before cleaning.
• Always pull the plug – not the cord.
• Keep the appliance and the cord well away from any hot surfaces to avoid any damage to the appliance.
• Make sure the cord may not inadvertently be pulled or cause anyone to trip when in use.
• Do not allow the cord to hang over sharp edges.
• Do not bend the cord or wind it round the appliance.

Do not use the appliance,

• if the cord is damaged.
• in case of malfunction.
• if the appliance was dropped or is damaged otherwise.
• Have it checked and, if necessary, repaired by a qualified person/Customer Service. Never attempt to make any modifications to or repair the appliance yourself.
• Only use accessories evaluated for use with this appliance.
• Never attempt to drive any objects into the appliance.
• Never attempt to open the housing yourself!
• The appliance is not intended to be operated by means of an external timer or separate remote-control system.

Special safety instructions

• Only use this appliance to mix, puree or stir food, or to crush ice.
• Place the appliance on an even and heat-resistant surface.
• Before turning on the appliance, make sure the lid is put correctly on the mixing jug.
• While operating, never put your hand in the mixing bowl or touch the blades. The blades are extremely sharp.

Danger of injury!

• Operate the appliance only with closed lid. Before removing the lid, wait for the blades to stop completely.
• Never use any boiling liquids. Allow those liquids to cool down first (lukewarm) to avoid serious injuries/burns. Only fill the mixing jug half full.

Danger of burns!

• If the blade should experience any problems during operation, switch off the appliance, disconnect it from the mains and remove the blockage.
• Only fill the mixing jug half full since the food will rise up the jug because of the blender's circular movement. If you work with fluid ingredients, don't fill the mixing jug with more than 1 liter. Larger servings are to be processed in several operations.
• Never operate the blender with an empty mixing jug.
• Remove any contents from the mixing jug with a spatula. Appliance must be turned off. Never put your hands in the mixing jug while appliance is being operated.
• Do not place the appliance on hot surfaces or close to open flames.

Before first use

• Remove all packaging material and check whether the appliance is complete.
• Clean the appliance as specified under “Cleaning and Care”.
• Place the appliance on a table or another even, heat-resistant surface.

Operation

Installing the mixing jug on the plastic housing

• Make sure the appliance is switched off (0-position).
• Put the mixing attachment (10) on the housing so that the green arrow on the housing is above the open lock on the engine block. Now turn the mixing attachment clockwise until the green arrow on the housing is above the locked lock on

the engine block. The mixing attachment (10) is now locked. In case the mixing attachment (10) was not installed correctly, the blender will not start working.

Close-up of a white ceramic or ceramic object with a curved edge and small directional arrows, no visible text or symbols.

Safety button

The blender includes a safety button (9). The blender can only be switched on with the speed control switch (8) if the glass jug (3) was installed correctly on the engine block.

Handling foods

If you want to mix/puree solid ingredients, cut them into 2cm-3cm pieces. Do not fill the mixing jug with large quantities. Always pour some fluid into the mixing jug before filling the mixing bowl with solid ingredients. The max. capacity is 1.25 liters.

• Fill the ingredients in the glass jug (3) (fruit, vegetables, juices, etc.)
• Close the glass jug (3) with the lid (2). Place the removable lid (1) on the mixing attachment (10) as well. By turning it clockwise, it is locked.
  • Make sure the lid is closed.
• Connect the appliance to the mains and switch the appliance on by turning the speed control switch (8) to the desired speed.
• In order to add ingredients during the mixing process remove the smaller lid (1) from the main lid (2) and add ingredients through the open spot in the lid (2).
• During the mixing process you should place one hand on the appliance.

- When handling more solid or thick ingredients, we recommend to operate the appliance in Ice Crush/ Pulse- Position in order to prevent the blades from being blocked.

- After the mixing process, turn off the appliance (0-position) and disconnect it from the mains.

- In order to remove the mixing attachment (10) from the engine block, simply lift it straight up. Do not turn the mixing attachment while lifting it.

Speed positions

You control the speed of the engine with the speed control switch (8) by choosing the position 1,2 or Pulse (Ice-Crush function). The switch does not lock in the Pulse position. In order to work in the Pulse function, hold the switch in the Pulse position or turn it into Pulse position repeatedly.

Crushing ice cubes

Add the ice cubes to the jug (not more than 8) and close the glass jug (3) with both lids (1 and 2). Hold the speed control switch (8) in Pulse position for a few seconds, then turn it back to 0-position. When the ice cubes lie back at the bottom of the mixing jug, you can turn the speed control switch back in the Pulse position. Continue this process until the ice cubes have been crushed to preference.

Suggestion: Only fill ice cubes in the mixing jug when the engine is switched off.

Use of speed positions

(1) – Low – for easy use with fluids (e.g. drinks, cocktails, milkshakes, etc.)
(2) – High – for more solid ingredients – mixing/pureeing of fluids and foods

(Pulse) – use only for a few seconds – for crushing ice cubes or for mixing foods

(Turbo) - additional Pulse function with higher speed in position (1)

Caution: Never operate the blender longer than one minute without a break.

The blender needs to cool off for 3 minutes before it can be used again. This process may be repeated 3 times. Afterwards, the blender has to cool down for 15 minutes, otherwise it may cause damage to the appliance.

Cleaning and care

• Before cleaning, switch off the appliance and disconnect it from the mains (12). Let the appliance cool down.
• Clean the engine block with a damp cloth. Do not let water enter the appliance.
• Do not use any aggressive cleaning agents.
• When cleaning the glass jug (3), always disconnect it from the engine block (7). Glass jug (3) and lids (1 and 2) may be washed with warm water and dishwashing detergent or dishwashing liquid.

- After completely having emptied the mixing jug, immediately fill water in the jug and operate the blender in Pulse-position for a few seconds (Autoclean-function). Then take the mixing attachment of the engine block, wash it and rinse it off with clean water. Then dry it completely.

Danger of injury!

Caution: The blades are very sharp.

• Switch off the appliance and disconnect it from the mains (12).
• The appliance and accessories are not dishwasher safe. If any accessories need to be cleaned, they may be cleaned individually. Caution! Put all accessories back in its right place after cleaning process.
• After having removed the mixing attachment (10) as described above you can remove the blades. By turning the blades clockwise, you can remove the blades from the block. You can now clean the blades. Caution! The blades are very sharp, danger of injury!

Assembling the mixing attachment

Make sure the appliance is only operated if the mixing attachment (10) is completely and correctly installed. In order to do so, follow the above steps in reverse order

Close-up of a white plastic kitchen brush and a circular plastic ring on a textured surface (no text or symbols visible)

Disposal Instructions

Waste electrical devices marked with this sign must not be disposed of with your household waste, but – according to the EU directive on Waste Electric And Electronic Equipment of 24th March 2005 – are to be collected separately. Therefore, please return this device at the end of its life cycle to special collection points for disposal or your local dealer.

Your blender 24001 is packed in a retail box. Such boxes are recyclable waste, i.e. they are reusable or recyclable.

Technical Data

Voltage: 220-240 V \~ 50/60 Hz

Rated Power: 600 W

Capacity: 1.5 l

CO-Time*: 1 minute

Protection Class: II

Technical data subject to change!

* CO-Time: The CO-Time (Continuous Time) describes the time how long an appliances may be used without the motor being damaged or overheating. After the appliance has run for this period of time it must be switched off to allow the motor to cool down.

Guarantee

This product is guaranteed against defects in materials and workmanship for a period of 2 years.

This guarantee is not valid:

• if the appliance has not been used in accordance to the instructions
  • for damages due to wear and tear (batteries, etc.)
  • for damages known by customer at time of purchase
  • for damages caused by owner

This guarantee does not affect your statutory right, nor any legal right you may have as a costumer under applicable national legislation governing the purchase of goods.

In order to assert his/her right in a guarantee case during the guaranteed period, the customer must provide evidence of the date of purchase (receipt).

The guarantee is to be asserted against

KORONA electric GmbH, Sundern/Germany

Service Adress:

KORONA Service, Am Steinbach 9, 59872 Meschede, Germany

Telefon Hotline: Mail: web:

[phone] [e-mail] www.korona-electric.de

within 2 years after the date of purchase. In case of guarantee the customer is given the right to get the appliance repaired at our own or at an authorized shop. Further rights (due to guarantee case) are not given to the customer.
