Marketeer - Digital Scale OneConcept - Free user manual and instructions

Brand	OneConcept
Model	Marketeer
Product Type	Digital parcel scale
Item Numbers	10030715, 10030716
Power Supply	220-240 V power adapter or 9 V battery
Platform Dimensions	27 x 2.5 x 27 cm
Control Unit Dimensions	18 x 4 x 9 cm
Package Contents	Device, user manual
Main Functions	Weighing, tare, counting, unit selection (kg/lbs)
Display	Digital screen
Auto-off	After 2 hours of inactivity
Care and Cleaning	Clean with a dry cloth only
Safety	Do not open, do not expose to moisture or extreme heat, keep out of reach of children (packaging)
Recycling	Do not dispose with household waste, deposit at a collection point for electrical appliances
Manufacturer and Importer (UK)	Provided in the manual (QR code for updated version)

Frequently Asked Questions - Marketeer OneConcept

How to turn on the scale?

Press the ON/OFF switch. All segments of the screen light up, then wait until 0 is displayed.

How to use the tare function?

Place the empty container, then press the TARE button until the display shows 0. Then add the item to be weighed; the net weight is displayed.

How to change the unit of measurement?

Press the MODE button to switch between kilograms (kg) and pounds (lbs).

How to use the counting function?

Place a reference weight on the scale, then press pcs until 100 is displayed. You can choose between 100, 75, 50, or 25 by pressing pcs multiple times.

How to clean the scale?

Use a dry cloth to clean the surface. Do not use volatile liquids or insecticide sprays.

What to do if the display shows nothing?

First check the power supply: if using a battery, insert a new 9V battery observing polarity. If using the power adapter, make sure it is properly plugged into a 220-240 V outlet.

How to turn off the scale?

You can use the ON/OFF switch. The scale also turns off automatically after 2 hours of inactivity.

Can I use rechargeable batteries?

The device is designed for a standard 9V battery. 9V rechargeable batteries can be used, but their voltage may be slightly lower, which could affect accuracy.

How to transport the scale?

Keep the original packaging and place the device back in it for transport. Avoid shocks and drops.

What to do in case of a defect?

Do not open the device yourself. Contact customer service or a qualified dealer. Any intervention by a third party voids the warranty.

USER MANUAL Marketeer OneConcept

INHALTSVERZEICHNIS

Member of Berlin Brands Group

Handwerkerstr. 11

15366 Dahlwitz-Hoppegarten

Deutschland

Symbol of a trash bin crossed with a diagonal line, no text or numbers present

Berlin Brands Group UK Limited PO Box 42 272 Kensington High Street London, W8 6ND United Kingdom

Dear customer,

Congratulations on the purchase of your unit. Please read the following instructions carefully and follow them to prevent potential damage. We accept no liability for damage caused by disregarding the instructions and improper use. Please scan the QR code to access the latest operating instructions and further information about the product.

CONTENTS

Safety Instructions 10

Operation 11

Disposal Considerations 12

Manufacturer & Importer (UK) 12

TECHNICAL INFORMATION

Article number 10030715, 10030716
Power supply Mains adapter for 220-240V or battery 9 V
Platform dimensions (W x H x D) 27 x 2.5 x 27 cm
Dimensions control element (W x H x D)	18 x 4 x 9 cm
Scope of delivery Device, operating instructions

SAFETY INSTRUCTIONS

• These operating instructions are intended to familiarise you with the operation of this product. Therefore, always keep these instructions in a safe place so that you can access them at any time.
• Please use the product only in its intended manner. Any other use may lead to damage to the product or in the vicinity of the product.
• Modifying or changing the product will compromise product safety. Attention: risk of injury!
• Never open the unit without authorisation and never carry out repairs yourself!
• Handle the product carefully. It can be damaged by bumps, blows or falls from a small height.
• Be sure to keep the product away from moisture and extreme heat.
• Do not drop metal objects into this device.
• Do not place any heavy objects on the device.
• Only clean the device with a dry cloth.
• Do not block any ventilation openings.
• Only use accessories recommended by the manufacturer or a qualified service professional.
• The warranty is void if the unit is tampered with by third parties. No liability is accepted for damage or malfunction resulting from incorrect use or installation of the appliance.

Small objects/packaging parts (plastic bags, cardboard):

Keep small objects and packaging parts (e.g. screws and other mounting material, memory cards) out of the reach of children so that they cannot be swallowed by them. Do not let small children play with plastic film. There is a danger of suffocation!

Transporting the device:

Please keep the original packaging. To achieve sufficient protection when transporting the unit, pack the unit in the original packaging.

Cleaning the outer surface:

Do not use volatile liquids such as bug sprays. Excessive pressure when wiping the surface can cause damage. Rubber or plastic parts should not be in contact with the appliance for a long period of time. Use a dry cloth.

OPERATION

Battery:

The unit is operated with a 9 V battery. Insert the battery as indicated on the battery compartment.

Setting up:

Make sure to place the unit in a horizontal position.

Simple weighing:

Switch on the unit by pressing the "On/Off" button. First, all segments of the display are shown. Wait until the value "0" is shown on the display before weighing.

Tare function:

Press the "Tare" button during the first measurement until the value "0" is shown on the display. Now you can start a second measuring process which will only show the added weight.

Switching off the unit:

You can use the "On/Off" switch. Alternatively, the unit switches off automatically after 2 hours of non-use.

Unit selection:

You can switch between the kilogram (kg) or pound (lbs) scale by pressing the "Mode" button.

Counting function:

Place a reference weight on the scale. Press the "pcs" button until the value "100" is shown on the display. You can alternate between the values 100, 75, 50 and 25 by repeatedly pressing the "pcs" button.

DISPOSAL CONSIDERATIONS

Symbol of a trash bin crossed with a diagonal line, no text or numbers present

If there is a legal regulation in your country regarding the disposal of electrical and electronic equipment, this symbol on the product or on the packaging indicates that this product must not be disposed of with household waste. Instead, it must be taken to a collection point for the recycling of electrical and electronic equipment. By disposing of this product in accordance with the regulations, you protect the environment and the health of those around you from negative consequences. For information on recycling and disposal of this product, contact your local government or household waste disposal service.

MANUFACTURER & IMPORTER (UK)

Manufacturer:

Chal-Tec GmbH, Wallstraße 16, 10179 Berlin, Germany.

Importer for Great Britain:

Berlin Brands Group UK Limited

PO Box 42

272 Kensington High Street

London, W8 6ND

United Kingdom
