USER MANUAL C1500 Platinum NZXT

NZXT C1500

C1500 PLATINUM

ATX 3.1 1500 WATT 80 PLUS PLATINUM FULLY

MODULAR LOW-NOISE POWER SUPPLY

TABLE OF CONTENTS

VERSION 2.0, 2024/01/23

COMPONENT LIST 01

PINOUT DIAGRAM 03

INSTALLATION 04

SPECIFICATIONS 13

NZXT GLOBAL WARRANTY POLICY 23

Line drawing of a computer power supply unit with front panel and buttons (no text or symbols)

B 24-pin(20+4) ATX Cable

×1

C 8-pin CPU Cable

8-pin CPU Cable x1 8-pin(4+4) CPU Cable x1

D 8-pin(6+2) PCIe Cable

×6

E 16-pin (12+4) 12V-2x6 PCIe Cable

×2

F SATA Cable (4 Connectors)

×3

G Peripheral Cable (4 Connectors)

×1

H 6-32 Screws

×4

I AC Power Cord

×1

A. C1500 Platinum

Install the power supply into the case using the provided screws.

The zero fan mode is activated automatically - the fan will not spin until the system load reaches 60%. Upon clicking the button, the zero fan mode will be deactivated.

Technical illustration of a mechanical component with a downward arrow indicating assembly or disassembly (no text or symbols present)

STEP 2

Connect the 24-pin power to the motherboard.

Diagram showing a connector assembly with a purple arrow indicating downward motion and a labeled point C.

STEP 3

Connect the 8-pin CPU power.

Diagram showing three stages of a connector assembly: pin alignment, internal structure, and final assembly with a purple arrow indicating process direction.

STEP 4 Option 1

Connect the PCI-E power to your graphics card as required.

Technical line drawing of a computer fan assembly with a cable inserted, showing internal components and a purple arrow indicating a component (no text or symbols present)

STEP 4

Option 2

To support Nvidia 40 Series graphics cards

Connect the 16-pin PCI-E power to your graphics card as required.

Connect the SATA and peripheral power as needed.

Technical diagram of a server rack with internal components and a cable connector (no text or symbols)

STEP 6

Connect the AC power cord to the wall and turn on the power switch.

Dimensions (WxDxH) 150mm x 180mm x 86mm
Material(s) Steel, PCB and plastic
Compliance Standard ATX12V v3.1 / EPS12V v2.92
PF Correction Active @ 0.99
Regulation & Certification FCC, Canada, CE, CB(IEC 62368-1), UKCA, CCC, BSMI, BIS, RCM, UAE, TUV, cTUVus, CP65
AC Input Rating
100 - 240Vac 15A-9A 50Hz-60Hz
200 - 240Vac 9A 50Hz-60Hz
DC Output Rating
Product Type Switching Power Supply
Model No. PS-2203
DC Output +3.3V +5V +12V +5Vsb
Max Load	22A 22A 125A 3A
Max Output Power	120W		1500W	15W
Total Power	1500W(115V-240V~) / 1300W(100V-115V~)
Fan Spec
Dimensions	140 x 140 x 25 mm
Speed	2500 ± 10% RPM
Airflow	125 CFM (Tpy.)
Noise	41.0 dBA max
Bearing	Magnetic Levitation Bearing (ML)
Operation
MTBF	100,000 hours
Temperature 0 - 50 °C
Energy Efficiency	80 Plus Platinum
	10% loading: 92% @115Vac
	20% loading: 94% @115Vac
	50% loading: 93.8% @115Vac
	100% loading: 90.8% @115Vac
Protections	OVP (Over Voltage Protection), UVP (Under Voltage Protection), SCP (Short Circuit Protection) OTP (Over Temperature Protection), OPP (Over Power Protection), OCP (Over Current Protection)
Cable Specs	24-pin ATX Power Cable: 600 mm with nylon sleeving, 4+4-pin CPU Power Cable: 700 mm with nylon sleeving, 8-pin CPU Power Cable: 700 mm with nylon sleeving, 6+2-pin PCIe Power Cable: 650 mm with nylon sleeving, 16-pin (12+4) 12V-2x6 PCIe Cable: 650 mm with nylon sleeving, SATA Cable: 500 + 150 mm with nylon sleeving, Peripherals Cable: 500 + 150 mm with nylon sleeving
Output Connections	24-pin ATX Power Cable: 1, 4+4-pin CPU Power Cable: 1, 8-pin CPU Power Cable:1, 6+2-pin PCIe Power Cable: 6, 16-pin (12+4) 12V-2x6 PCIe Cable: 2, SATA Cable:12, Peripherals Cable:4
Warranty	10 Years

SPECIFICATIONS

ESPECIFICACIONES	사양
SPÉCIFICATIONS	仕様
TECHNISCHE DATEN	規格
SPECIFICHE	規格
ESPECIFICAÇÕES

This NZXT Global Warranty Policy governs the sale of products by NZXT to you.

I. WARRANTY LENGTH

New NZXT Product Warranty Length

C1500 Platinum 10 Years

Any replacement product will be covered under warranty for the remainder of the warranty period or thirty days, whichever is longer. Proof of purchase is required for warranty service.

II. WHO IS PROTECTED

The Warranty covers only NZXT products purchased by the original consumer.

III. WHAT IS AND IS NOT COVERED

Please note that our warranty is not an unconditional guarantee. If the product, in NZXT's reasonable opinion, malfunctions within the warranty period, NZXT will provide you at its sole discretion with a repaired or replacement product, either new or refurbished, with a similar function that is equal or greater in value depending on supply. Our warranty does not cover the following:

• any product or serial number/warranty sticker modification applied without permission from NZXT;
• any damage that is not a manufacturing defect;
• damage, deterioration or malfunction resulting from: accident, abuse, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized product modification or failure to follow instructions included with the product;
• improper installation, unauthorized alterations or modifications, or repair or attempted repair by anyone not authorized by NZXT;
• shipping or transport damage (claims must be made with the carrier);
• normal wear and tear.

NZXT does not warrant that this product will meet your requirements. It is your responsibility to determine the suitability of this product for your purpose. For NZXT Store orders, we cover two way return shipping for all exchanges and returns. For all other authorized dealers, NZXT Support does not cover return shipping and only covers one way shipping from NZXT back to the end user for exchanges. Two way expedited shipping is provided for all PSUs covered under the Less Than Three program, indiscriminate of purchase location, provided the location is an approved NZXT reseller.

IV. EXCLUSION OF DAMAGES (DISCLAIMER)

NZXT's sole obligation and liability under this warranty is limited to the repair or replacement of a defective product with either a new or refurbished product with a similar function that is equal or greater in value at our option. NZXT shall not, in any event, be liable for any incidental or consequential damage, including but not limited to damages resulting from interruption of service and loss of data, business, or for liability in tort relating to this product or resulting from its use or possession.

V. LIMITATIONS OF IMPLIED WARRANTIES

There are no other warranties, expressed or implied, including but not limited to those of merchantability or fitness for a particular purpose. The duration of implied warranties is limited to the warranty length specified in Paragraph I.

VI. TO OBTAIN TECHNICAL SUPPORT

If you have already referenced your product owner's manual and still need help, you may contact us by phone at [phone], by email at [e-mail], or visit the NZXT Support site at nzxt.com/customer-support.

VII. HOW TO OBTAIN A WARRANTY SERVICE FROM NZXT

To receive a warranty service for your product when purchased directly from NZXT, you must submit a request via the NZXT Support site outlining the problem. If a technician deems the product defective or requiring testing, you will be required to provide a copy of your proof of purchase, which will enable you to submit a Return Merchandise Authorization "RMA" request.

Once approved, you'll receive an RMA number, upon which you will be asked to ship the defective item back to NZXT with the RMA number clearly marked or labelled on the package. NZXT recommends that appropriate measures are taken to safeguard the product from damage during shipping.

VIII. APPLICABLE LAW AND ADDITIONAL LEGAL RIGHTS FOR CONSUMERS

This warranty gives you specific legal rights. These conditions are governed and construed in accordance with the laws of California (with exception of its conflict of law provisions), and the application of the United Nations Convention of Contracts for the International Sale of Goods is expressly excluded. The non-exclusive jurisdiction of the courts of California is agreed, which means that you may bring a claim to enforce your consumer protection rights in connection with this Global Warranty in the country which you have your habitual residence where you may have additional rights. These rights may vary.

For original consumers who are covered by consumer protection laws or regulations in their country, state, or province of purchase or, if different, their country, state, or province of residence, the benefits conferred by this warranty are in addition to all rights and remedies conveyed by such consumer protection laws and regulations. To the extent that liability under such consumer laws can be limited, NZXT's liability is limited, and its sole option, to repair or replacement, either new or refurbished, with a similar function that is equal or greater in value depending on supply.

In the United Kingdom:

• For NZXT products sold to customers in the UK, during the expected lifespan of your product your legal rights entitle you to the following:

Up to 30 days: if your goods are faulty, then you can get an immediate refund.
Up to six months: if your goods can't be repaired or replaced, then you're entitled to a full refund, in most cases.
Up to six years: if your goods do not last a reasonable length of time you may be entitled to some money back.
- If the person seeking to rely on the guarantee is not the original consumer, the NZXT Warranty will cover the product in relation to that person provided that they are able to provide proof of the transfer of the benefit of the guarantee from the original consumer.
- The implied warranties under the Consumer Rights Act 2015 says that your goods must be as described, fit for all purposes for which such goods are usually supplied, and of satisfactory quality.

In the EU:

- If you are a consumer and have your habitual residence in the EU, you additionally enjoy the protection afforded to you by provisions that cannot be derogated from by agreement by virtue of the law where you have your habitual residence.

IX. WARRANTY SERVICE FROM RESELLERS

In the event that a warranty service is sought, you must provide proof of purchase (store receipt or invoice) in order to receive the service and if deemed necessary, repair or replacement product.

In North America:

Within the first 60 days after purchase, please return your product (or for power supplies installed within our enclosures, just the failed power supply) to your dealer or reseller for a replacement. If the product is still within warranty and you can no longer return it to your dealer, please contact NZXT Customer Support (see above) for assistance and instructions. NZXT will not accept returns without prior approval and an RMA number.

In Europe:

Within the first year after purchase, please return your product (or for power supplies installed within our enclosures, just the failed power supply) to your dealer or reseller for a replacement. If the product is still within warranty and you can no longer return it to your dealer, please contact NZXT Customer Support (see above) for assistance and instructions. NZXT will not accept returns without prior approval.

In Australasia:

Within the first two years after purchase, please return your product (or for power supplies installed within our enclosures, just the failed power supply) to your dealer or reseller for a replacement. If the product is still within warranty and you can no longer return it to your dealer, please contact NZXT Customer Support (see above) for assistance and instructions. NZXT will not accept returns without prior approval.

The cost of shipping will be borne at the first instance by you; however, if the purchased item is defective, NZXT will reimburse reasonable postage or transportation of costs.

Outside North America, Europe, and Australasia:

If your product needs to be returned within the warranty period, please contact the retailer or distributor from whom you purchased the product.

X. NZXT.COM STORE RETURNS/EXCHANGE POLICY

Eligible products under this NZXT Warranty qualify for a full refund or exchange only with an authorized RMA number and if the item is returned to the NZXT.com store inventory within 30 days of purchase. Returns are not allowed beyond 30 days of the purchase date. The NZXT.com Store reserves the right to deny any return or exchange. Refunds will be credited to the original method of payment. To initiate a return, simply submit a request via NZXT support site.

Visit nzxt.com/warranty and support.nzxt.com for information on warranty coverage and service.
Visite el sitio Web nzxt.com/warranty y support.nzxt.com para obtener información sobre la cobertura y el servicio de la garantía.
Visitez nzxt.com/warranty et support.nzxt.com pour les informations de la couverture de la garantie et du service.
Informationen zu Geltungsbereich und Service der Garantie finden Sie unter support.nzxt.com und nzxt.com/warranty.
Visitare il sito nzxt.com/warranty e support.nzxt.com per informazioni sulla copertura e sul servizio della garanzia.
Visite nzxt.com/warranty e support.nzxt.com para obter informações sobre a cobertura da garantia e assistência.
제품 보증 범위와 서비스 정보를 확인하시려면 nzxt.com/warranty 또는 support.nzxt.com을 방문해 주시기 바랍니다.
保証範囲およびサービスに関する情報については、support.nzxt.comとnzxt.com/warrantyにアクセスしてください。
请造访 nzxt.com/warranty 和 support.nzxt.com 了解保修范围和服务的信息。
請訪問 nzxt.com/warranty 和 support.nzxt.com 了解產品保固範圍和更多服務訊息。

NZXT, Inc. | 15736 E. Valley Blvd, City of Industry, CA 91744, USA

NZXT UK Ltd. | First Floor 5 Fleet Place London EC4M 7RD, GB United Kingdom

[phone] / [e-mail] / nzxt.com

REGULATORY STATEMENT

DECLARATION OF CONFORMITY

The device complies with the requirements set out in the Council Directives relevant Union harmonisation legislation:

• EMC Directive 2014/30/EU
• LVD Directive 2014/35/EU
• RoHS Directive 2011/65/EU & (EU) 2015/863

DÉCLARATION DE CONFORMITÉ

KONFORMITETSDEKLARATION

UKCA Declaration of Conformity

The object of the declaration described above is in conformity with the relevant UK harmonization legislation:

• Electromagnetic Compatibility Regulations 2016
• Electrical Equipment (Safety) Regulations 2016
• The Ecodesign for Energy-Related Products and Energy Information (Amendment) (EU Exit) Regulations 2019
• The Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment Regulations 2012

RoHS Statement

This product is compliant to implemented RoHS (Restriction of Hazardous Substances) type regulations worldwide, including but not limited to China, India, Korea and European Union.

WEEE

Disposal of Waste Electrical and Electronic Equipment and/or Battery by users in private households in the European Union.

This symbol on the product or on the packaging indicates that this can not be disposed of as household waste. You must dispose of your waste equipment and/or battery by handling it over to the applicable take-back scheme for the recycling of electrical and electronic equipment and/or battery. For more information about recycling of this equipment and/or battery, please contact your city office, the shop where you purchased the equipment or your household waste disposal service. The recycling of materials will help to conserve natural resources and ensure that it is recycled in a manner that protects human health and environment.

Recycling information: See http://www.benq.com/support/recycle for details.

EU REACH SVHC Disclosure on Candidate List

REACH (Registration, Evaluation, Authorization and Restriction of Chemicals, EC 1907/2006) is the European Union's (EU) chemical substances regulatory framework. REACH requires NZXT Inc. to provide customers with sufficient information on Substances of Very High Concern (SVHC) contained in products in concentration above 0.1% weight by weight (w/w) to allow safe use of the product.

REGULATORY STATEMENT

IMPORTANT SAFETY INFORMATION CAUTION ELECTRIC SHOCK HAZARD!

1. Install in accordance with all manufacturer instructions and safety warnings.
   Failure to do so may result in damage to your power supply or system, and may causes serious injury or death.
2. High voltages are present in the power supply.
   Do not open the power supply case or attempt to repair the power supply; there are no user-serviceable components.
3. This product is designed for indoor use only.
4. Do not use the power supply near water, or in high temperature or high humidity environments.
5. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus that produce heat.
6. Do not insert any objects into the open ventilation or fan grill area of the power supply.
7. Do not modify the cables and/or connectors included with this power supply.
8. If this power supply uses modular cables, use only manufacturer supplied cables.
9. The 24-pin main power connector has a detachable 4-pin connector.
   This 4-pin connector is not a P4 or ATX 12V connector.

Do not force this cable in the P4 or ATX +12V socket on motherboard.

1. Failure to comply with any manufacturer instructions and/or any of these safety instructions will immediately void all warranties and guarantees.

If you have any questions or problems with the NZXT product you purchased, please don't hesitate to contact us using our support system. [e-mail] support.nzxt.com

Please include a detailed explanation of your problem and your proof of purchase. For comments and suggestions, you can e-mail our design team, [e-mail].

Lastly we would like to thank you for your support by purchasing this product. For more information about NZXT, please visit us online. NZXT Website: NZXT.com
