Product type	Chest freezer
Brand	Elcold
Model	EL SS 53
Approximate capacity	53 L
Dimensions (W x D x H) approx.	55 x 50 x 50 cm
Net weight approx.	20 kg
Power supply	230 V / 50 Hz
Power consumption	100 W
Refrigerant	R600a (isobutane)
Minimum temperature	-18 °C
Super freeze function	Yes (yellow indicator)
Temperature alarm	Yes (red indicator > -13 °C)
Adjustable thermostat	Yes
Defrosting	Manual (plastic scraper recommended)
Security lock	Yes (key supplied)
Casing material	Painted steel
Recommended cleaning	Warm water with mild detergent
Adjustable feet	Yes (for floor ventilation)
Climate class	N (ambient temperature 16-32 °C)
Required room volume (R600a)	1 m³/8 g of refrigerant

Frequently Asked Questions - EL SS 53 Elcold

How to correctly install the Elcold EL SS 53 freezer?

Place the freezer on a flat surface, at least 50 mm from the wall and 100 mm on the right side for ventilation. The plastic feet ensure a minimum height of 15 mm under the appliance. Avoid direct sunlight or near heat sources. Let it rest for 1 hour before connecting.

How to adjust the freezer temperature?

Turn the thermostat knob clockwise to lower the temperature, counterclockwise to increase it. The recommended temperature is at least -18 °C. Use a thermometer to check. In case of large quantity of food or ambient variation, adjust the setting.

What do the indicator lights on the control panel mean?

The green light indicates the appliance is powered on. The red light comes on if the temperature exceeds -13°C (alarm). The yellow light indicates the super freeze function is activated, the compressor runs continuously to freeze quickly.

How to freeze large quantities of fresh food?

Activate the super freeze function (yellow light) about 24 hours before placing the food. Do not exceed the freezing capacity indicated on the rating plate. Place the food against the inner walls for faster freezing. Deactivate the function after 24 hours.

How often should the freezer be defrosted?

Defrost when the frost layer reaches about 5 mm. Use a plastic or wooden scraper, never metal tools. Activate super freeze 24 hours before to keep food frozen longer. Disconnect power, open the lid, and clean with mild detergent. The water outlet facilitates draining.

How to clean the freezer?

Clean the interior with warm water and dish soap. Dry with a clean cloth. Never use alkaline or abrasive detergents. For the exterior, a damp cloth is sufficient. Before first use, also clean the interior.

What to do if the freezer does not work?

First check the power supply: is the power off? Has the fuse blown? Is the plug properly inserted? If the problem persists, contact your dealer. In the meantime, keep the lid closed to limit temperature rise.

Why is the inside temperature too high?

Check the thermostat setting, frost thickness (defrost if >5 mm), and if the door is properly closed. Ensure the ventilation is not blocked. If the problem continues, contact a professional.

The compressor runs continuously, is that normal?

This may be due to the super freeze function being activated (yellow light on) or incorrect thermostat setting. Also check that the appliance is not placed in a too warm location. If continuous running persists, consult the manual.

What are the important safety instructions?

Do not allow children to play in or near the freezer. Do not consume food directly from the freezer (risk of frostbite). Do not store pressurized containers or flammable gases. Use additional electrical protection (circuit breaker). Keep the lock key out of reach of children.

USER MANUAL EL SS 53 Elcold

Congratulations on your new appliance, we trust that it will serve you for many years to come. In order to gain optimum benefit from your appliance, please read the following instructions thoroughly and act accordingly.

Environmental protection and disposal.

The packaging is designed to protect the appliance and its components during transportation, and it is made of recyclable materials.

Please return the packaging to an official collection point for recycling.

Old appliances contain reusable materials and should not be disposed of together with household refuse.

Remove the spring-action hinges from the appliance, in order to prevent children from being entrapped in the appliance.

Ensure that no part of the refrigeration tubing is damaged as the refrigerant in the appliance risks escaping to the environment.

Information about refrigerant type and amount will be found on the type plate on the rear of the appliance (Fig. 3).

Safety instructions.

In order to prevent injuries and or damage to the appliance, it should be unpacked and set up by min. two people.

If upon unpacking the appliance is found damaged, do not connect to the mains, but contact the supplier.

Interference with or repair to the appliance should only be carried out by authorized personnel, in order to avoid any injuries.

- Do not let children play with or close to the appliance, e.g. do not allow them to sit inside the appliance or swing on the lid.

Never put naked flames or other ignition sources inside the appliance.

Never consume products straight out of the appliance, e.g. ice lollies or ice cubes. Due to the low temperature there is a risk of damage to the skin (frost-bite).

Never consume products which have been stored for too long, there could be a risk of food poisoning. Keep the key to the appliance away from the appliance and out of the reach of children. Do not store explosives or spray cans containing combustible propellants in the appliance.

Setting up.

• Avoid placing the appliance in direct sunlight, close to heaters, radiators or other heat sources (Fig. 2).
• The appliance should be placed horizontally and level with a distance of min. 50 mm (2") to the nearest walls or obstacles. To the right-hand side the distance should be min. 100 mm (4"), to ensure sufficient ventilation of the compressor. Underneath the appliance there should be a gap of 15 mm approx. (½"). On a soft surface, e.g. carpet, it may be necessary to ensure the correct distance by means of spacers (Fig. 1).
  • The type of refrigerant could be a flammable gas, R600a (Isobutane). If your appliance is charged with this gas, please observe that the volume of the room where the appliance

is to be placed should be at least 1 m³/8 g of refrigerant (1. cu.yd./0.2 oz). Please check on the type plate on the rear of the appliance, whether your appliance is charged with R600a (Fig. 3).

Connection to the mains.

For safety reasons the appliance must be earthed. If you are in any doubt, please contact an authorized electrician.

The appliance should be left for 1/2 to 1 hour before it is connected to the mains. If the appliance is connected before that, there is a risk of damaging the compressor.

If for any reason the appliance is disconnected from the mains, please wait 10 minutes • before re-connecting. The electronic starting device needs this time to cool down, before a safe re-start can be made.

Before use.

Before use, the interior of the appliance should be cleaned with a mild soap solution, and • wiped off with a dry clean cloth.

- Prior to filling the appliance with products, it is advisable to let the appliance operate for approx. 6h. This ensures a sufficiently low temperature. The temperature should be -18°C (0° F) or lower.

The temperature inside the appliance can be adjusted by turning the knob in the panel (Fig. 4). Turning the knob clockwise will lower the temperature, and turning the knob anticlockwise will raise the temperature in the appliance. Changes to the ambient conditions and the amount of products stored will influence the setting required. Readjust, if necessary.

Control panel. (Fig.4)

The green lamp is illuminated when the appliance is connected to the mains.

The red lamp (Temperature alarm) is illuminated when the temperature inside the appliance is higher than -13° C ( 8.6° F). For the first-time start the red lamp will be illuminated until the temperature in the appliance has reached -13° C ( 8.6° F).

The amber lamp (fast freeze) is illuminated when the switch is activated. The cooling system will operate continuously.

Fast freezing.

Activate the amber fast-freeze knob 24h prior to introducing the products to be frozen.

Do not attempt to freeze larger amounts of products than specified as the freezing capacity in kg /24h. This information can be found on the type plate on the rear of the appliance.

The fastest freezing in is obtained when the products are placed in direct contact with the inner walls.

• Remember to switch off the fast freezing function after 24h.

Notes on energy saving.

• Never leave the lid open for any excessive period.
• Warm dishes should be allowed to cool down before being stored in the appliance.
- After some time a layer of ice will form inside the appliance. When the layer of ice has reached a thickness of approx. 5 mm (1/4"), the ice should be removed, by scraping it off with

a wooden or plastic scraper. Never use sharp tools, such as screwdrivers, as the interior of the appliance may be damaged. The removable partition panel in the appliance can be used as a drip tray when defrosting the appliance (Fig. 5).

The fast-freeze function (amber knob) on the panel should be activated 24h prior to the defrosting. In this way the temperature will be lowered to approx. -25° C ( -13° F). This will provide more time for the defrosting, before the frozen products reach critically high temperatures.

Never attempt to freeze in thawed products.

Trouble shooting.

The appliance is not operating. Please check:

Is the electrical plug connected to the mains (wall socket)?

Has the fuse blown?

The temperature inside the appliance is too high. Please check:

Is the temperature button (Fig. 4) set to the correct temperature?

Has an excess amount of ice formed inside the appliance?

The appliance is operating continuously. Please check:

Is the fast-freeze function activated?

Is the ambient temperature very high?

Has the appliance recently been loaded with a large amount of warm products?

If you have checked the above points and the appliance is still not working as expected, please contact your local dealer for further advice.
