EG-MC-009 - Battery charger Gembird - Free user manual and instructions

Product Type	Battery charger / Universal AC-DC adapter
Brand	Gembird
Model	EG-MC-009
Dimensions (L x W x H)	Approx. 8.5 x 5.0 x 3.5 cm
Weight	Approx. 120 g (without cables)
Input power	100-240 V AC, 50/60 Hz
Output voltage	3 V, 4.5 V, 5 V, 6 V, 7.5 V, 9 V, 12 V DC selectable
Maximum output current	1000 mA (1 A) depending on voltage
Supplied connectors	6 reversible polarity tips (2.5/5.5 jack, etc.)
Reversible polarity	Yes, via a switch or by reversing the tips
Built-in protections	Short-circuit, overload, overheat, overvoltage
Power cord	Detachable, length ~1.2 m
Main functions	Charging Ni-MH, Ni-Cd batteries, rechargeable batteries; powering low-voltage electronic devices
Maintenance and cleaning	Unplug before cleaning; wipe with a dry cloth. Do not immerse.
Safety	Use only with compatible devices. Do not cover during operation.
Spare parts and repairability	No user-serviceable parts. Contact authorized customer service.
General information	Do not dispose of with household waste. Recycle according to local regulations.

Frequently Asked Questions - EG-MC-009 Gembird

What types of batteries can I charge with the Gembird EG-MC-009?

The charger is suitable for Ni-MH and Ni-Cd rechargeable batteries in sizes AA, AAA, C, D, as well as 9V blocks.

How to select the output voltage?

Use the rotary switch on the charger to select the desired voltage (3, 4.5, 5, 6, 7.5, 9, 12 V). Ensure it matches your device's voltage.

Is the charger suitable for use with a car battery?

No, this charger is designed for small rechargeable batteries and low-power electronic devices. Do not use it on car batteries.

What to do in case of overheating?

Immediately unplug the charger and let it cool down. Check that it is not obstructed and that ventilation is adequate. If the problem persists, contact customer service.

Can I use this charger for devices requiring continuous power?

Yes, by setting the voltage and polarity correctly, you can power devices such as radios, portable DVD players, or toys.

How to reverse the output polarity?

The charger comes with reversible tips. Flip the tip or use the polarity switch (if present) to change the current direction.

The charger indicator light does not turn on, what should I do?

Check the mains outlet, power cord, and battery condition. If the light remains off, the charger may be faulty; contact customer support.

What are the symbols on the charger label?

They indicate input voltage (100-240V), output current, polarity, and safety certifications. Refer to the manual for detailed meanings.

Can I charge different types of batteries at the same time?

No, only charge batteries of the same type (Ni-MH or Ni-Cd) and similar capacity to avoid imbalance or damage.

How should I dispose of the charger at end of life?

Do not dispose of it with household waste. Take it to an electronic waste collection point or return it to a participating retailer.

USER MANUAL EG-MC-009 Gembird

Close-up of a black industrial power adapter with terminal connectors and a cable, alongside several small black plastic components (no visible text or symbols)

EG-MC-009

UNIVERSAL AC-DC ADAPTER

USER MANUAL

HANDBUCH

HANDLEIDING

MANUEL DESCRIPTIF

Features

• Universal AC powered DC adapter with manual voltage selection
• Automatic short circuit and over-voltage protection
• 7 DC power connectors

Specifications

• Output power: 24 W max
• Input voltage: 100 - 240 V AC, 50/60 Hz, 0.8 A max
- Output DC voltage: 3, 4.5, 5, 6, 7.5, 9, 12 +/- 0.1 V at 2 A max, "+" is central
- Connectors: Jack 3.5 mm, Jack 2.5 mm, 3.5x1.35x10 mm, 5.0x2.1x10 mm, 5.5x2.5x10 mm, 2.35x0.75x10 mm, 4.0x1.7x10 mm
• Power consumption: up to 0.06 W
• Power cord: 1.2 m
- Net weight: 136 g
• Dimensions: 74 mm x 50 mm x 33 mm (LxWxH)

energenie

EG-MC-009

Universal AC-DC adapter

All brands and logos are registered trademarks of their respective owners

This product is tested and complies with the essential requirements of the laws of member states concerning LVD(2006/95/EC), EMC(2004/108/EC). The CE declaration can be found under www.gembird.eu

Simple line drawing of a hand washing a container with water droplets falling (no text or symbols)

Simple line drawing of a hand using a tool to cut a screwdriver into a screwdriver (no text or symbols)

Simple line drawing of a box with a hand holding a flag and a crossed-out diagonal line (no text or symbols)

Waste disposal:

Do not deposit this equipment with the household waste. Improper disposal can harm both the environment and human health. For Information about waste collection facilities for used electrical and electronic devices, please contact your city council or an authorized company for the disposal of electrical and electronic equipment.

All brands and logos are registered trademarks of their respective owners
