USER MANUAL 49917 HAMILTON BEACH

1. Read all instructions.

2. This appliance is not intended for use by persons (including

children) with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless they are closely supervised and instructed concerning use of the appliance by a person responsible for their safety.

3. Close supervision is necessary when any appliance is used

by or near children. Cleaning and user maintenance shall not be made by children without supervision. Children should be supervised to ensure that they do not play with the appliance.

4. Do not touch hot surfaces. Use handles or knobs. Care

must be taken, as burns can occur from touching hot parts or from spilled, hot liquid.

5. To protect against electric shock, do not place cord, plug,

or coffee maker in water or other liquid.

6. Unplug from outlet when either the coffee maker or clock is

not in use and before cleaning. Allow to cool before putting on or taking off parts and before cleaning the appliance.

7. Coffee maker must be operated on a flat surface away from

the edge of counter to prevent accidental tipping.

8. Do not operate any appliance with a damaged supply

cord or plug, or after the appliance malfunctions or has been dropped or damaged in any manner. Supply cord replacement and repairs must be conducted by the manufacturer, its service agent, or similarly qualified persons in order to avoid a hazard. Contact Customer Service for information on examination, repair, or adjustment as set forth in the Limited Warranty.

9. The use of accessory attachments not recommended by

the appliance manufacturer may cause injuries.

10. Use only the carafe provided with the appliance.

11. Do not use outdoors.

12. Do not let cord hang over edge of table or counter or touch

hot surfaces, including stove.

13. Do not place coffee maker on or near a hot gas or electric

burner or in a heated oven.

14. The carafe is designed for use with this coffee maker. It

must never be used on a range top or in a microwave oven.

15. Do not set a hot carafe on a wet or cold surface.

16. Do not use a cracked carafe or one with loose or weakened

17. Do not clean carafe with cleansers, steel wool pads, or

other abrasive materials.

18. Be certain carafe lid is securely in place during brew cycle

and when pouring coffee. Do not use force when placing lid on carafe.

19. To disconnect coffee maker, turn controls to off ( ) and

then remove plug from wall outlet. To unplug, grasp the plug and pull from the outlet. Never pull from the power cord.

20. Warming plate may remain hot after the coffee maker is

21. WARNING! To avoid hot water spraying from the piercing

needle, do not lift the lid during the brew process.

22. Do not use appliance for other than intended use.

23. Scalding may occur if the lid is removed during the heating

cycle. When using electrical appliances, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and/or injury to persons, including the following:3

SAVE THESE INSTRUCTIONS

Other Consumer Safety Information This appliance is intended for household use only. w WARNING Electrical Shock Hazard: This appliance is provided with a polarized plug (one wide blade) to reduce the risk of electric shock. The plug fits only one way into a polarized outlet. Do not defeat the safety purpose of the plug by modifying the plug in any way or by using an adapter. If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, have an electrician replace the outlet. The length of the cord used on this appliance was selected to reduce the hazards of becoming tangled in or tripping over a longer cord. If a longer cord is necessary, an approved extension cord may be used. The electrical rating of the extension cord must be equal to or greater than the rating of the appliance. Care must be taken to arrange the extension cord so that it will not drape over the countertop or tabletop where it can be pulled on by children or accidentally tripped over. To avoid an electrical circuit overload, do not use another high-wattage appliance on the same circuit with this appliance.

24. WARNING! To reduce the risk of fire or electric shock, do

not remove the bottom cover. No user-serviceable parts are inside. Repair should be done by authorized service personnel only.

25. Do not place coffee maker in a cabinet when in use.

26. CAUTION! Cut Hazard: Removable single-serve pod

holder contains a sharp needle. Use caution when handling.

27. CAUTION! Cut Hazard: Piercing needle is sharp. Use

caution when cleaning.4 Parts and Features To order parts, visit: hamiltonbeach.com/parts Before first use: Wash all removable parts in hot, soapy water. Rinse and dry. Brew one cycle with water on each side and discard water. 1 Carafe Side Lid

Carafe Water Reservoir (with markings for measuring) 3 Brew Basket 4 Swivel Shower Head 5 Control Panel 6 Carafe 7 Warming Plate

Removable Cup Rest/Storage Container

Removable Single-Serve 56 oz. Water Reservoir with Removable Lid

Removable Single-Serve Brew Basket for Ground Coffee with Hinged Lid and Handle

Gray Removable Single-Serve Pod Holder with Handle

Gray Removable Needle Holder with Black Seal

How to Brew a Single-Serve Pod w WARNING Burn Hazard. If overflow occurs, unplug and allow coffee maker to cool. To avoid hot coffee overflowing:

• Fully insert cup or travel mug on cup rest.

• Do not lift lid during the brewing process.

• Use appropriate sized cup or travel mug for your brew size.

• If brew cycle is stopped early, the coffee must be drained. Return cup or travel mug to cup rest. Press BREW NOW I/ Button. Failure to drain the cup or travel mug can cause the next cup brewed to overflow. w CAUTION Cut Hazard. Removable single-serve pod holder has a sharp needle. Piercing needle on underside of lid is also sharp. Use caution when handling. NOTES:

• If Lid is opened after BREW NOW I/ or CARAFE ( ) button was pressed, discard contents of cup or travel mug. Discard used pod. Add new pod and press BREW NOW I/ button to restart brewing cycle.

• Use only cold water in Reservoir. Do not use hot water.

• Do not reheat coffee in machine.

• Do not use creamer or nondairy creamer in Reservoir.

• After brewing hot cocoa single-serve pods, immediately brew a water-only cycle without a single-serve pod to avoid possibility of clogging Piercing Needle.

• Press BREW NOW I/ button again to stop brewing midcycle.

• If brew indicator light flashes three times, Lid is not closed. Lower Lid until it clicks to lock. Press BREW NOW I/ button.

• Do not brew coffee without Removable Needle Holder locked into place.

1. Lift up Single-Serve Water Reservoir and

remove Lid. Add water to at least MIN fill line (15 oz. [444 ml]) or MAX fill line (56 oz. [1.65 L]). Add Lid and place Water Reservoir on to Coffee Maker.

4. Lift Lid Latch until Lid stays in place.

6. Place a pod into Single-Serve Pod

Holder. Do not remove foil.

7. Close Lid and snap in place to pierce

8. Press BREW STRENGTH button to

select Regular or Bold.

9. Use Cup Rest for a cup or mug and

button to start brewing. Brew indicator light will light up to show that Coffee Maker is brewing.

11. As the machine is brewing the display will show the volume of

12. Coffee Maker will shut off automatically when brewing is complete.

14. Single-Serve Pod Holder should be rinsed after every use.6

How to Brew Single-Serve Ground Coffee w CAUTION Cut Hazard. Piercing needle on underside of lid is sharp. Use caution when handling. NOTES:

• Use only cold water in Reservoir. Do not use hot water.

• Do not reheat coffee in machine.

• Do not use creamer or nondairy creamer in Reservoir.

• Do not use hot cocoa powder or mix in Brew Basket.

• If finer ground coffee is used, coffee will continue to drip after light has gone off.

• Press BREW NOW I/ button again to stop brewing midcycle.

• If brew indicator light flashes three times, Lid is not closed. Lower Lid until it clicks to lock. Press BREW NOW I/ button.

• Do not brew coffee without Removable Brew Basket in place.

• If you have sediment from coffee, add a #1 paper cone coffee filter to Removable Brew Basket.

• Do not brew coffee without Removable Needle Holder locked into place. w WARNING Burn Hazard. If overflow occurs, unplug and allow coffee maker to cool. To avoid hot coffee overflowing:

• Fully insert cup or travel mug on cup rest.

• To avoid overflow, keep ground coffee below MAX fill line.

• Do not lift lid during the brewing process.

• If brew cycle is stopped early, the coffee must be drained. Return cup or travel mug to cup rest. Place a mug on cup rest. Press the BREW NOW I/ button. Failure to drain the cup or travel mug can cause the next cup brewed to overflow.

1. Lift up Single-Serve Water Reservoir

and remove Lid. Add water to at least MIN fill line (15 oz. [444 ml]) or MAX fill line (56 oz. [1.65 L]). Add Lid and place Water Reservoir on to Coffee Maker.

2. Plug into outlet. Press SINGLE ( )

4. Lift Lid Latch until Lid stays in place.

5. Open Brew Basket Lid; then place

Removable Brew Basket on countertop.

6. Add ground coffee to Removable Brew

8. Close Lid and snap in place to latch Lid

9. Press BREW STRENGTH button to

change strength to Bold, if desired.

10. Use Cup Rest for a cup/mug, or remove

Cup Rest for a travel mug.

button to start brewing. Brew indicator light will light up to show that Coffee Maker is brewing.

12. As the machine is brewing the display will show the volume of

13. Coffee Maker will shut off automatically when brewing is complete.

15. Single-Serve Pod Holder should be rinsed after every use.7

How to Brew a Carafe

1. Plug into outlet.

2. Lift lid. Rotate Swivel Shower Head over

Water Reservoir and remove Brew Basket.

3. Place a basket-style paper filter in Brew

4. For each cup of coffee, place 1 tablespoon

(5 g) of coffee into filter. Maximum capacity is 60 g for up to 12 cups.

5. Fill Carafe with up to 12 cups of cold water

and pour into Carafe Water Reservoir.

6. Place Brew Basket into holder and lower

Lid. Shower Head will go back into place when Lid is lowered.

7. Press CARAFE ( ) button.

8. Place Carafe, with its lid attached, on

9. Press BREW STRENGTH button to change

strength to Bold, if desired.

10. Press BREW NOW I/ button to start

brewing. Brew indicator light will light up to show that Coffee Maker is on.

11. Press BREW NOW I/ button to turn off.

13. Brew Basket and Carafe should be rinsed

after every use. Automatic Shutoff: Automatic Shutoff feature shuts off Coffee Maker two hours after brew cycle begins. NOTE: Unit will only brew on one side at a time. Pause and Serve: To serve coffee during brewing cycle, remove Carafe and pour a cup. By removing Carafe, flow of coffee from bottom of Filter Basket will stop. w CAUTION Burn Hazard. The carafe must be replaced within 20 seconds of being removed to prevent overflow. NOTE: Bold mode will require additional time to complete a brewing cycle. Coffee Maker remembers last brew option selected. If unplugged, Coffee Maker defaults to Regular. Tips for Best-Tasting Coffee

• All coffees are made from either arabica beans or robusta beans, or some combination of both. Arabica beans are slightly more expensive, but tend to produce better-tasting coffee.

• Ground coffee will become stale much faster than whole beans. If buying preground coffee, choose a package with latest expiration date or a smaller quantity.

• If grinding whole beans, set your coffee grinder on a fine/medium grind. This will yield best-tasting grounds. Try to use freshly ground coffee within about a week of grinding.

• Using a water filter, filtered water, or bottled water will yield better-tasting coffee than tap water.

• Use approximately 1 tablespoon (5g) of grounds for each cup of coffee being made. To avoid overflow, use slightly less grounds (3/4 tablespoon [4 g]) when brewing decaf or flavored coffees. Also, be aware that using coffee that is ground too finely may also cause Filter Brew Basket to overflow.

• Make sure your Coffee Maker is clean. See “Care and Cleaning” section. w WARNING Burn Hazard. If filter basket overflow occurs, unplug coffee maker and allow coffee in filter basket to cool before removing filter basket. To avoid hot coffee overflowing:

• When using decaffeinated coffee, do not exceed the coffee manufacturer’s recommended serving amount. Use only the carafe supplied with your unit or its exact replacement.8 Delay Brew – For Carafe Side Only NOTE: Unit will only brew on one side at a time. Single-serve side cannot be used while Carafe side is programmed.

1. Time must be set before Coffee Maker can be programmed.

Press and pulse SET TIME ( ) button for correct hour in AM or PM. Wait 3 seconds. Pulse or hold to set minutes.

button. Start time is visible in display and 19:99 flashes as default.

3. While continuing to hold DELAY BREW

button, pulse SET TIME ( ) button to set desired brewing hour in AM or PM. Wait 3 seconds; minutes will flash. Pulse to set minutes. Release DELAY BREW

button. Press and release DELAY BREW

button again to activate automatic brew. DELAY BREW light will illuminate. TIP: To check start time, press and hold DELAY BREW

button. The time you set will be displayed and can be changed by repeating steps above. Press DELAY BREW

button to reactivate automatic brew and light will illuminate.9 Care and Cleaning w WARNING Shock Hazard. Do not immerse cord, plug, or coffee maker in any liquid. w WARNING Burn Hazard. Failure to allow coffee maker to cool down may cause hot water or coffee to spray from the piercing needle. Use caution when cleaning. w CAUTION Cut Hazard. Removable single-serve pod holder has a sharp needle. Piercing needle on underside of lid also is sharp. Use caution when handling. To Clean Carafe Side:

1. Plug into outlet.

BREW NOW I/ button again to stop brewing and allow vinegar to clean. After 30 minutes, press BREW NOW I/ button and allow it to finish brew cycle. When brew cycle is finished, empty Carafe and rinse. Run 2-3 additional cycles, using cold tap water. Carafe side is cleaned and ready to brew coffee.

1. Remove Single-Serve Water Reservoir and discard water. Add

1 1/2 cups (355 ml) plain white vinegar to Reservoir and return to place.

2. Plug into outlet.

3. Press CUP SIZE button and select a mug larger than 10 ounces.

solution starts dispensing, press BREW NOW I/ button again to stop brewing and allow vinegar to clean. After 30 minutes, press BREW NOW I/ button and allow it to finish brew cycle. Empty Reservoir and fill with cold tap water; run 2-3 additional cycles. Unit is cleaned and ready to brew coffee.

1. Unplug and allow to cool.

2. Hand wash all removable parts in hot, soapy water. Rinse and

dry or wash in top rack only of dishwasher. DO NOT use “SANI” setting when washing in dishwasher. “SANI” cycle temperatures could damage your product.

3. Wipe outside of Coffee Maker with a soft damp cloth.

1. Unplug and allow to cool.

2. Remove Gray Removable Needle Holder

in Lid by turning counterclockwise from locked icon ( ) to unlocked icon ( ).

3. Bend a small paper clip. Insert tip of

paper clip through hole of Piercing Needle and up into shaft of Piercing Needle to ensure grounds have been removed.

4. To replace Gray Removable Needle

Holder, insert tab between lock icon ( ) and unlock icon ( ) and turn clockwise to lock. All coffee makers should be cleaned at least once a month (once a week for areas with hard water). Routine Cleaning10 Troubleshooting – Single-Serve Side Coffee Maker will not brew/coffee not dispensing.

• Piercing Needle may be clogged. Always remove Gray Removable Needle Holder. Clean Piercing Needle in Lid of Coffee Maker as shown on page 9.

• Mineral deposits have formed. Clean Coffee Maker following directions in Care and Cleaning section.

• Too little water. Need 15 oz. (444 ml) or more. Coffee tastes bad.

• Too much water was added or too much or too little ground coffee was added. Change ratio of water to coffee grounds or use less water with coffee pods.

• Poor coffee quality and freshness.

• Poor water quality. Use filtered or bottled water.

• Soft water causes poor coffee extraction, which leads to poor tasting coffee. Use filtered, spring, or bottled water. Coffee sediment in cup.

• Try a coarser grind of coffee, or add a #1 paper cone coffee filter to Removable Brew Basket. Make sure hinged Lid is closed on Removable Brew Basket. Water on counter under unit.

• Overfilled Water Reservoir. Do not add more than 40 oz. (1.2 l) of water. Some mugs/cups do not pour cleanly and can dribble water down side of cup and onto counter. Bubbles in reservoir indicate high pressure. One of the following occurred.

• Lid opened during brew or after FIL H2O error. Don’t open lid during brewing and keep lid closed for 1minute after FIL H2O error.

• Needle clogged. Follow “Clogged Needle” instructions on page 9.

• Grounds basket loaded with too much fine grind coffee. Use a lesser amount of ground coffee. 3 tablespoons (44 ml) is maximum amount of grounds to brew.

Control Panel Notifications:

• CLOSE LId: Coffee Maker Lid is not closed properly. Push Lid down to lock into place.

• NEEDLE: Needle is clogged or grounds basket is overloaded. Do not fill grounds basket above MAX fill line. Always remove Gray Removable Needle Holder and follow “Clogged Needle” instructions on page 9.

• FIL H2O: Not enough water. Add water to Water Reservoir and press BREW NOW I/ button to clear Display. Press BREW NOW I/ button to restart brew cycle. Coffee overflows from Brew Basket.

• Use Removable Brew Basket with Lid for ground coffee.

• Use a lesser amount of ground coffee. 3 tablespoons (44 ml) is maximum amount of grounds to brew.

• When using whole bean coffee, a standard automatic drip coffee grind will yield best results. Be careful not to overgrind, since very finely ground coffee can cause overflow.

• Black Seal around Needle in Removable Needle Holder is missing. Carefully place seal around needle and push until in place. Coffee overflows from travel mug or regular mug.

• Empty mug after manually stopping brew cycle. Press BREW NOW I/ button to start a new brewing cycle. Coffee single-serve pod bursts.

• There is variability in single-serve pod manufacturing process which causes some types of single-serve pods to be weaker at seams so foil seal fails. Try a different brand.

• If you are using softened water or live in an area where your tap water is naturally soft, this can cause single serve pod issues and filter basket overflows. Use filtered, spring, or bottled water. Delay Brew feature does not work with Single-Serve side.

• Delay Brew feature is not designed to work with Single-Serve side. Program mode is for Carafe side only.11 Longer than normal brew time.

• Bold brewing cycle takes longer to brew to produce a rich, full bodied cup of coffee.

• Mineral deposits can build up in pump of your Coffee Maker. Periodic cleaning of inside of unit is recommended. More frequent cleaning may be necessary, depending on hardness of your water. See “Care and Cleaning” section. NOTE: Do not disassemble unit. Brew Basket overflows or coffee brews slowly.

• Excessive amounts of ground coffee.

• Decaffeinated and/or coffee ground too finely can cause overflow. Use slightly less grounds when brewing decaffeinated, flavored, or finely ground coffee. Or use medium ground coffee.

• Coffee Maker needs cleaning. See Care and Cleaning on page 9.

• Do not use soft water. Use filtered, spring, or bottled water. If using a paper filter:

• Coffee grounds between paper filter and Brew Basket.

• Paper filter not open and in proper position.

• Rinse Brew Basket before inserting paper filter so edges will remain pressed against sides of Basket.

• Poor-quality paper filter. Coffee leaks onto base.

• Carafe removed from Warming Plate for more than 20 seconds during brewing cycle. Coffee tastes bad.

• Coffee Maker needs cleaning. See Care and Cleaning on page 9.

• Coffee ground too coarsely or too finely. Use medium ground coffee.

• Coffee-to-water ratio unbalanced. Adjust for personal preference.

• Poor coffee quality and freshness.

• Poor water quality. Use filtered or bottled water.

• Soft water causes poor coffee extraction, which leads to poor tasting coffee. Use filtered, spring or bottle water. Coffee sediment in cup.

• Use a high-quality, basket-style paper filter. Coffee not brewing or unit will not turn on.

• Carafe not positioned on Warming Plate.

• Water Reservoir is empty.

• Power surge. Unplug; then plug unit back in.

• Clock requires reset after power outage.

• BREW NOW I/ button was not pressed. Press BREW NOW I/ button. Troubleshooting – Carafe Side12 This warranty applies to products purchased and used in the U.S. and Canada. This is the only express warranty for this product and is in lieu of any other warranty or condition. This product is warranted to be free from defects in material and workmanship for a period of five (5) years from the date of original purchase in Canada and one (1) year from the date of original purchase in the U.S. During this period, your exclusive remedy is repair or replacement of this product or any component found to be defective, at our option; however, you are responsible for all costs associated with returning the product to us and our returning a product or component under this warranty to you. If the product or component is no longer available, we will replace with a similar one of equal or greater value. This warranty does not cover glass, filters, wear from normal use, use not in conformity with the printed directions, or damage to the product resulting from accident, alteration, abuse, or misuse. This warranty extends only to the original consumer purchaser or gift recipient. Keep the original sales receipt, as proof of purchase is required to make a warranty claim. This warranty is void if the product is used for other than single-family household use or subjected to any voltage and waveform other than as specified on the rating label (e.g., 120V ~ 60 Hz). We exclude all claims for special, incidental, and consequential damages caused by breach of express or implied warranty. All liability is limited to the amount of the purchase price. Every implied warranty, including any statutory warranty or condition of merchantability or fitness for a particular purpose, is disclaimed except to the extent prohibited by law, in which case such warranty or condition is limited to the duration of this written warranty. This warranty gives you specific legal rights. You may have other legal rights that vary depending on where you live. Some states or provinces do not allow limitations on implied warranties or special, incidental, or consequential damages, so the foregoing limitations may not apply to you. To make warranty claim, do not return this appliance to the store. Please write Hamilton Beach Brands, Inc., Customer Service Department, 4421 Waterfront Dr., Glen Allen, VA 23060, or visit hamiltonbeach.com/customer-service in the U.S. or hamiltonbeach.ca/ customer-service in Canada. For faster service, locate the model, type, and series numbers on your appliance. Limited Warranty13
