| Product type | Cordless angle grinder (grinder) |
| Brand | Metabo |
| Model | WPBA 18 LTX BL 15-125 Quick DS |
| Power source | Li-Ion battery 18 V (CAS system) |
| Max. accessory diameter | 125 mm |
| No-load speed | Adjustable via dial (low to high speed) |
| Weight (with battery) | Varies depending on battery (approx. 2.2 kg) |
| Main functions | Grinding, sanding, wire brushing, cutting |
| Protective guard | Type B, C, D, E, F depending on accessory |
| Auxiliary handle | Screwable left or right, with vibration damping |
| Kickback stop | Present on paddle switch models |
| Electronic safety stop | Automatic shut-off in case of jamming or kickback |
| Rotatable battery | Rear rotation 270° (3 positions) |
| Quick system | Quick clamping nut for quick disc change |
| Dust filter | Installed in dusty environments, regular cleaning |
| Maintenance | Clean ventilation slots, battery contacts, filter |
| Compatible accessories | Grinding wheels, brushes, sanding pads, specific guards |
| Spare parts and repair | Lists at www.metabo.com, repair by electrician |
| Environmental protection | Do not dispose with household waste, WEEE recycling |
Frequently Asked Questions - WPBA 18 LTX BL 15-125 Quick DS METABO
How to change the disc on the WPBA 18 LTX BL 15-125 Quick DS?
Before any change, remove the battery. Lock the spindle with the button (5). For machines with Quick nut, place the nut (1) on the spindle and tighten by hand clockwise. To loosen, stop the machine, press the M-Quick button when the disc slows down: the nut automatically loosens by half a turn. For two-hole nuts (22), use the pin wrench (23).
How to clean the dust filter?
Remove the battery. Slightly lift the filter (13) at the top edges and pull it downwards. Clean it with compressed air. Reinstall by clipping it in. Regular cleaning is recommended, especially in dusty environments.
Which batteries can I use with this grinder?
Use only original Metabo or CAS (Cordless Alliance System) 18 V batteries, for example LiHD 5.5 Ah, 8.0 Ah, or 10.0 Ah models. Consult the accessories list for exact references.
How to adjust the rotation speed?
Turn the dial (15) on the machine. A low number corresponds to low speed, a high number to high speed. Use high speed for grinding/cutting, medium for brushes, low to medium for sanding with sanding pad.
How to mount the protective guard correctly?
Press and hold the lever (24), place the guard (21) in the indicated position, release the lever. Orient the guard so that the closed area faces you. Check that it is properly engaged and does not move. Always use the guard suitable for the accessory (type B, C, D, E or F).
What to do in case of disc jamming?
The machine stops automatically thanks to the electronic safety stop. Release the trigger or switch, then restart normally. Avoid jamming by not forcing the disc and following the recommended working angles.
How to safely transport Li-Ion batteries?
Li-Ion batteries are subject to dangerous goods legislation (UN 3480/3481). For shipping, use certified Metabo packaging, only transport intact and leak-free batteries, isolate contacts with adhesive tape to avoid short circuits.
Which accessories are recommended for cutting?
Use reinforced composite or diamond cutting discs (segment distance ≤ 10 mm). Mount a type C protective guard (grinding and cutting) or a type F extraction guard. Always work in the opposite direction of rotation to avoid kickback.
How to activate continuous operation?
On models with slide switch (6), slide the switch forward, then tilt it backward until it locks. To stop, press the rear of the switch. On paddle switch models, continuous operation is not possible: keep the paddle pressed.
How to dispose of the device at end of life?
Do not dispose of the device or batteries with household waste. According to the WEEE directive (2012/19/EU), take the device to a collection point for recycling. Used batteries must be returned to a Metabo dealer. Consult www.quefairedemesdechets.fr for collection points.
